SDO HMI 2014-11-03 08:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 130.65 | 602.14 | 66.29 | 305.73 | 12.09 | 114.66 | 9.60 | 311.71 | 0.2176 | -74.0 | -19.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-03 08:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.47 | 0.00 | 0.76 | 11.94 | 119.59 | 14.54 | 299.29 | 0.2829 | -861.0 | -671.4 | |
| 0.00 | 0.95 | 0.00 | 0.49 | 12.96 | 117.83 | 12.78 | 305.71 | 0.2666 | -617.0 | -526.2 | |
| 5.19 | 296.05 | 2.66 | 151.35 | 12.24 | 117.73 | 12.68 | 303.60 | 0.2586 | -1035.2 | -450.5 | |
| 3.98 | -3.00 | 2.04 | -3.00 | 12.19 | 117.51 | 12.46 | 303.86 | 0.2550 | -972.7 | 999999 | |
| 13.67 | -3.00 | 6.99 | -3.00 | 11.98 | 117.34 | 12.29 | 303.50 | 0.2508 | -1242.7 | 999999 | |
| 0.87 | -3.00 | 0.44 | -3.00 | 12.46 | 117.18 | 12.13 | 305.46 | 0.2530 | -584.2 | 999999 | |
| 31.66 | -3.00 | 16.16 | -3.00 | 11.93 | 116.84 | 11.79 | 304.38 | 0.2433 | -1505.7 | 999999 | |
| 0.00 | 1.30 | 0.00 | 0.66 | 11.40 | 116.32 | 11.27 | 303.63 | 0.2312 | -256.0 | -229.5 | |
| 2.34 | -3.00 | 1.19 | -3.00 | 11.88 | 116.25 | 11.20 | 305.54 | 0.2346 | -1183.6 | 999999 | |
| 2.60 | -3.00 | 1.32 | -3.00 | 12.27 | 116.21 | 11.15 | 307.01 | 0.2378 | -999.6 | 999999 | |
| 7.18 | 25.18 | 3.65 | 12.79 | 11.46 | 115.92 | 10.87 | 304.80 | 0.2262 | -1226.9 | -705.3 | |
| 4.07 | -11.00 | 2.07 | -11.00 | 11.19 | 115.88 | 10.83 | 303.89 | 0.2231 | -1163.0 | 999999 | |
| 0.00 | 1.04 | 0.00 | 0.53 | 12.75 | 115.86 | 10.80 | 309.52 | 0.2381 | -787.0 | -571.0 | |
| 0.00 | 1.99 | 0.00 | 1.01 | 12.46 | 115.50 | 10.45 | 309.43 | 0.2303 | -808.0 | -696.0 | |
| 0.00 | 3.63 | 0.00 | 1.84 | 11.41 | 115.27 | 10.22 | 306.23 | 0.2167 | -835.0 | -699.8 | |
| 0.00 | 5.54 | 0.00 | 2.81 | 12.59 | 114.61 | 9.56 | 312.35 | 0.2203 | 713.0 | 664.1 | |
| 0.00 | 1.04 | 0.00 | 0.53 | 11.39 | 114.35 | 9.30 | 308.72 | 0.2039 | 676.0 | 550.8 | |
| 4.07 | 14.45 | 2.06 | 7.31 | 12.09 | 114.16 | 9.11 | 311.91 | 0.2089 | 1009.8 | 754.5 | |
| 0.00 | 1.04 | 0.00 | 0.53 | 11.88 | 114.06 | 9.01 | 311.44 | 0.2053 | 460.0 | 172.2 | |
| 0.00 | 1.47 | 0.00 | 0.74 | 11.71 | 113.22 | 8.17 | 313.52 | 0.1928 | 813.0 | 577.7 | |
| 0.00 | 1.12 | 0.00 | 0.57 | 11.20 | 112.87 | 7.82 | 312.75 | 0.1826 | 935.0 | 722.3 | |
| 0.00 | 1.82 | 0.00 | 0.92 | 13.88 | 112.56 | 7.50 | 323.21 | 0.2127 | 794.0 | 615.4 | |
| 0.00 | 1.12 | 0.00 | 0.57 | 13.04 | 112.28 | 7.23 | 321.66 | 0.1986 | 732.0 | 543.1 | |
| 1.21 | 242.93 | 0.61 | 122.32 | 12.26 | 112.14 | 7.08 | 319.59 | 0.1868 | 894.9 | 528.9 | |
| 0.87 | -24.00 | 0.44 | -24.00 | 11.96 | 112.10 | 7.05 | 318.65 | 0.1825 | 835.1 | 999999 | |
| 0.78 | -24.00 | 0.39 | -24.00 | 11.15 | 112.05 | 6.99 | 315.68 | 0.1718 | 902.4 | 999999 | |
| 1.47 | -24.00 | 0.74 | -24.00 | 12.65 | 112.03 | 6.97 | 321.38 | 0.1907 | 704.8 | 999999 | |
| 0.26 | -24.00 | 0.13 | -24.00 | 12.59 | 111.87 | 6.82 | 321.81 | 0.1882 | 916.7 | 999999 | |
| 2.16 | -24.00 | 1.09 | -24.00 | 11.36 | 111.84 | 6.78 | 317.40 | 0.1719 | 1128.5 | 999999 | |
| 43.43 | -24.00 | 21.87 | -24.00 | 12.32 | 111.56 | 6.50 | 322.19 | 0.1813 | 1365.9 | 999999 | |
| 2.42 | -24.00 | 1.22 | -24.00 | 11.85 | 111.27 | 6.22 | 321.72 | 0.1719 | 1008.8 | 999999 | |
| 0.78 | -24.00 | 0.39 | -24.00 | 12.69 | 111.05 | 5.99 | 325.62 | 0.1812 | 871.6 | 999999 | |
| 1.64 | -24.00 | 0.83 | -24.00 | 12.42 | 110.98 | 5.92 | 325.04 | 0.1767 | 997.2 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
