SDO HMI 2014-11-04 15:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 52.88 | 135.57 | 26.51 | 68.00 | -4.77 | 86.86 | -1.18 | 173.63 | 0.1585 | 538.6 | 164.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-04 15:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.12 | 0.00 | 0.57 | -6.29 | 90.24 | 2.20 | 192.05 | 0.1839 | 960.0 | 811.9 | |
| 0.00 | 0.86 | 0.00 | 0.43 | -2.95 | 89.49 | 1.45 | 191.78 | 0.1246 | 1028.0 | 822.7 | |
| 19.87 | 29.98 | 9.95 | 15.00 | -4.17 | 89.19 | 1.15 | 188.02 | 0.1447 | 1136.6 | 753.3 | |
| 0.00 | 3.89 | 0.00 | 1.95 | -4.98 | 88.59 | 0.56 | 183.55 | 0.1577 | 703.0 | 711.8 | |
| 0.00 | 1.56 | 0.00 | 0.78 | -4.62 | 88.00 | -0.04 | 179.75 | 0.1511 | 922.0 | 758.1 | |
| 12.18 | 23.67 | 6.10 | 11.85 | -4.17 | 87.79 | -0.25 | 178.28 | 0.1433 | 1226.7 | 792.8 | |
| 4.15 | -6.00 | 2.08 | -6.00 | -4.50 | 87.76 | -0.28 | 178.15 | 0.1491 | 1101.9 | 999999 | |
| 0.00 | 1.56 | 0.00 | 0.78 | -6.07 | 87.73 | -0.31 | 178.25 | 0.1762 | 853.0 | 704.5 | |
| 0.00 | 1.64 | 0.00 | 0.82 | -5.07 | 87.58 | -0.46 | 177.13 | 0.1591 | 945.0 | 751.4 | |
| 0.00 | 1.04 | 0.00 | 0.52 | -4.98 | 87.40 | -0.63 | 175.97 | 0.1577 | 816.0 | 695.5 | |
| 0.00 | 4.41 | 0.00 | 2.21 | -4.68 | 87.40 | -0.63 | 175.83 | 0.1525 | 1010.0 | 856.1 | |
| 3.46 | 14.86 | 1.73 | 7.44 | -4.29 | 87.25 | -0.78 | 174.62 | 0.1460 | 1115.3 | 716.7 | |
| 1.56 | -12.00 | 0.78 | -12.00 | -4.02 | 87.07 | -0.96 | 173.19 | 0.1417 | 1135.6 | 999999 | |
| 0.00 | 4.67 | 0.00 | 2.33 | -4.02 | 86.45 | -1.59 | 168.84 | 0.1434 | 675.0 | 549.4 | |
| 0.00 | 1.30 | 0.00 | 0.65 | -4.89 | 86.18 | -1.86 | 168.23 | 0.1591 | -619.0 | -486.3 | |
| 0.00 | 2.07 | 0.00 | 1.04 | -5.29 | 85.55 | -2.49 | 165.05 | 0.1682 | -945.0 | -682.5 | |
| 1.90 | 35.25 | 0.96 | 17.72 | -5.32 | 85.19 | -2.84 | 163.06 | 0.1704 | -1143.5 | -793.5 | |
| 0.00 | 0.26 | 0.00 | 0.13 | -4.35 | 85.08 | -2.96 | 160.54 | 0.1552 | 732.0 | 669.0 | |
| 5.87 | -17.00 | 2.96 | -17.00 | -5.56 | 84.95 | -3.09 | 162.16 | 0.1756 | -1049.5 | 999999 | |
| 3.89 | -17.00 | 1.95 | -17.00 | -5.17 | 84.83 | -3.20 | 160.79 | 0.1699 | -1234.7 | 999999 | |
| 0.00 | 1.99 | 0.00 | 1.00 | -5.56 | 83.27 | -4.76 | 153.59 | 0.1866 | 829.0 | 661.2 | |
| 0.00 | 1.12 | 0.00 | 0.57 | -5.17 | 83.25 | -4.79 | 152.49 | 0.1808 | 939.0 | 731.0 | |
| 0.00 | 1.38 | 0.00 | 0.70 | -7.27 | 81.39 | -6.65 | 149.56 | 0.2277 | -1051.0 | -829.0 | |
| 0.00 | 1.47 | 0.00 | 0.75 | -6.85 | 80.40 | -7.63 | 144.96 | 0.2308 | -985.0 | -813.1 | |
| 0.00 | 1.47 | 0.00 | 0.76 | -9.13 | 77.12 | -10.91 | 140.46 | 0.2950 | -665.0 | -634.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
