SDO HMI 2014-11-05 06:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.64 | 10.20 | 1.97 | 11.25 | -14.72 | 18.69 | -61.09 | 108.64 | 0.8948 | -272.4 | 95.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-05 06:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 5.62 | 0.00 | 5.81 | -13.79 | 20.50 | -59.28 | 108.04 | 0.8800 | 546.0 | 383.8 | |
| 0.00 | 0.86 | 0.00 | 0.99 | -14.84 | 17.60 | -62.17 | 108.53 | 0.9034 | -178.0 | -119.2 | |
| 0.00 | 0.61 | 0.00 | 0.72 | -16.07 | 16.87 | -62.90 | 109.70 | 0.9104 | -561.0 | -498.7 | |
| 1.64 | 3.11 | 1.97 | 3.73 | -15.87 | 16.50 | -63.27 | 109.41 | 0.9126 | -589.4 | -492.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
