SDO HMI 2014-11-05 16:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.06 | 25.82 | 2.01 | 12.83 | 5.97 | 71.85 | -2.45 | 268.43 | 0.0702 | 285.9 | -358.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-05 16:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.06 | 14.16 | 2.01 | 7.02 | 5.85 | 74.71 | 0.41 | 348.03 | 0.0345 | -1103.1 | -1036.1 | |
| 0.00 | 3.80 | 0.00 | 1.88 | 5.49 | 73.72 | -0.58 | 20.05 | 0.0293 | -511.0 | -765.0 | |
| 0.00 | 1.21 | 0.00 | 0.60 | 6.96 | 67.33 | -6.97 | 66.06 | 0.1323 | 710.0 | 529.4 | |
| 0.00 | 0.78 | 0.00 | 0.39 | 6.15 | 66.92 | -7.38 | 72.82 | 0.1342 | 911.0 | 725.1 | |
| 0.00 | 1.38 | 0.00 | 0.69 | 6.47 | 65.92 | -8.38 | 72.67 | 0.1524 | 1008.0 | 705.8 | |
| 0.00 | 1.12 | 0.00 | 0.56 | 6.55 | 65.50 | -8.80 | 72.91 | 0.1598 | 770.0 | 575.4 | |
| 0.00 | 1.04 | 0.00 | 0.52 | 5.75 | 65.33 | -8.97 | 78.08 | 0.1593 | 972.0 | 790.2 | |
| 0.00 | 2.33 | 0.00 | 1.17 | 6.46 | 65.10 | -9.19 | 74.11 | 0.1658 | 933.0 | 789.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
