SDO HMI 2014-11-05 20:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.02 | 10.18 | 1.90 | 6.13 | -17.94 | 98.64 | 26.55 | 228.40 | 0.5668 | -230.9 | -134.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-05 20:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.02 | 5.35 | 1.90 | 3.36 | -17.01 | 104.14 | 32.05 | 235.62 | 0.6171 | 844.1 | 637.4 | |
| 0.00 | 0.69 | 0.00 | 0.41 | -18.43 | 97.33 | 25.24 | 227.25 | 0.5531 | -578.0 | -473.8 | |
| 0.00 | 1.12 | 0.00 | 0.64 | -18.67 | 92.26 | 20.17 | 220.68 | 0.5032 | -525.0 | -512.5 | |
| 0.00 | 1.73 | 0.00 | 0.98 | -18.63 | 90.79 | 18.70 | 218.64 | 0.4886 | -777.0 | -542.2 | |
| 0.00 | 0.69 | 0.00 | 0.39 | -18.37 | 90.63 | 18.54 | 218.76 | 0.4840 | -690.0 | -555.4 | |
| 0.00 | 0.60 | 0.00 | 0.35 | -22.57 | 90.00 | 17.92 | 212.68 | 0.5282 | -627.0 | -664.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
