SDO HMI 2014-11-07 12:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 22.78 | 98.80 | 28.10 | 126.39 | 13.40 | 117.50 | 67.38 | 282.96 | 0.9226 | -365.8 | -114.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-07 12:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 17.17 | 87.76 | 22.52 | 115.30 | 13.89 | 118.15 | 68.03 | 283.49 | 0.9275 | -586.3 | -121.0 | |
| 0.00 | 0.69 | 0.00 | 0.73 | 7.89 | 112.61 | 62.48 | 276.97 | 0.8869 | -387.0 | -357.6 | |
| 0.95 | 2.50 | 0.98 | 2.60 | 8.29 | 111.81 | 61.69 | 277.43 | 0.8805 | -486.2 | -426.6 | |
| 4.66 | 7.16 | 4.60 | 7.08 | 8.05 | 110.25 | 60.13 | 277.16 | 0.8674 | 567.1 | 283.3 | |
| 0.00 | 0.69 | 0.00 | 0.68 | 10.85 | 110.28 | 60.16 | 280.39 | 0.8681 | 447.0 | 402.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
