SDO HMI 2014-11-07 13:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 217.57 | 1010.54 | 140.81 | 649.45 | 15.41 | 11.28 | -38.30 | 70.06 | 0.6366 | -130.5 | -23.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-07 13:00:28 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.95 | 0.00 | 0.59 | 19.98 | 15.79 | -33.79 | 60.93 | 0.6002 | -625.0 | -558.7 | |
| 0.00 | 0.86 | 0.00 | 0.54 | 19.91 | 15.46 | -34.12 | 61.23 | 0.6038 | -543.0 | -446.4 | |
| 0.00 | 1.04 | 0.00 | 0.62 | 11.77 | 16.47 | -33.10 | 74.28 | 0.5576 | -587.0 | -455.9 | |
| 41.24 | 371.37 | 25.03 | 226.71 | 15.03 | 15.63 | -33.95 | 69.00 | 0.5799 | -1096.4 | -319.7 | |
| 2.67 | -4.00 | 1.64 | -4.00 | 15.29 | 14.99 | -34.59 | 68.86 | 0.5894 | -543.3 | 999999 | |
| 0.00 | 1.55 | 0.00 | 0.94 | 13.38 | 15.17 | -34.41 | 71.96 | 0.5804 | -792.0 | -650.5 | |
| 0.00 | 1.38 | 0.00 | 0.87 | 19.73 | 13.81 | -35.77 | 62.41 | 0.6231 | -495.0 | -435.5 | |
| 0.00 | 2.07 | 0.00 | 1.32 | 21.09 | 13.36 | -36.21 | 60.62 | 0.6349 | -636.0 | -506.4 | |
| 0.00 | 1.21 | 0.00 | 0.73 | 11.94 | 15.21 | -34.37 | 74.41 | 0.5757 | -650.0 | -516.4 | |
| 0.00 | 1.29 | 0.00 | 0.79 | 13.67 | 14.86 | -34.72 | 71.59 | 0.5855 | -871.0 | -784.2 | |
| 0.00 | 0.95 | 0.00 | 0.60 | 19.66 | 13.59 | -35.98 | 62.63 | 0.6254 | -730.0 | -657.1 | |
| 0.00 | 1.21 | 0.00 | 0.77 | 19.65 | 13.40 | -36.18 | 62.74 | 0.6277 | -455.0 | -435.1 | |
| 4.23 | -4.00 | 2.60 | -4.00 | 14.75 | 14.41 | -35.17 | 69.98 | 0.5950 | -765.4 | 999999 | |
| 0.60 | -4.00 | 0.37 | -4.00 | 15.41 | 14.21 | -35.37 | 68.99 | 0.6000 | -562.9 | 999999 | |
| 6.13 | -4.00 | 3.75 | -4.00 | 13.69 | 14.48 | -35.09 | 71.70 | 0.5906 | -866.5 | 999999 | |
| 4.06 | -4.00 | 2.49 | -4.00 | 14.05 | 14.39 | -35.19 | 71.14 | 0.5930 | -746.7 | 999999 | |
| 0.00 | 1.47 | 0.00 | 0.93 | 19.61 | 13.13 | -36.44 | 62.93 | 0.6307 | -545.0 | -477.1 | |
| 0.00 | 1.38 | 0.00 | 0.84 | 13.12 | 14.47 | -35.11 | 72.66 | 0.5890 | -688.0 | -607.6 | |
| 0.00 | 1.12 | 0.00 | 0.71 | 19.14 | 13.06 | -36.52 | 63.67 | 0.6295 | -521.0 | -400.8 | |
| 0.00 | 0.86 | 0.00 | 0.55 | 18.87 | 13.05 | -36.52 | 64.10 | 0.6284 | -549.0 | -464.2 | |
| 0.00 | 1.38 | 0.00 | 0.86 | 15.91 | 13.58 | -36.00 | 68.46 | 0.6100 | -404.0 | -277.8 | |
| 0.00 | 0.86 | 0.00 | 0.54 | 16.24 | 13.43 | -36.15 | 68.00 | 0.6131 | -404.0 | -288.1 | |
| 0.00 | 0.78 | 0.00 | 0.50 | 20.67 | 12.33 | -37.25 | 61.76 | 0.6451 | -474.0 | -410.4 | |
| 0.86 | -4.00 | 0.53 | -4.00 | 14.02 | 13.67 | -35.90 | 71.44 | 0.6024 | -811.8 | 999999 | |
| 3.28 | -4.00 | 2.04 | -4.00 | 14.41 | 13.56 | -36.01 | 70.85 | 0.6051 | -623.3 | 999999 | |
| 0.00 | 13.55 | 0.00 | 8.50 | 16.01 | 13.09 | -36.48 | 68.49 | 0.6166 | 426.0 | 355.8 | |
| 3.02 | -4.00 | 1.88 | -4.00 | 14.17 | 13.38 | -36.20 | 71.32 | 0.6067 | -676.7 | 999999 | |
| 0.00 | 1.21 | 0.00 | 0.75 | 13.62 | 13.40 | -36.17 | 72.19 | 0.6048 | -674.0 | -467.7 | |
| 0.00 | 0.95 | 0.00 | 0.59 | 13.50 | 13.31 | -36.27 | 72.43 | 0.6056 | -446.0 | -421.7 | |
| 0.00 | 0.60 | 0.00 | 0.38 | 17.52 | 12.44 | -37.13 | 66.43 | 0.6304 | -515.0 | -414.6 | |
| 0.00 | 1.29 | 0.00 | 0.80 | 12.83 | 13.35 | -36.23 | 73.49 | 0.6033 | -578.0 | -488.1 | |
| 0.00 | 3.19 | 0.00 | 1.99 | 13.85 | 13.10 | -36.48 | 71.92 | 0.6095 | -420.0 | -421.6 | |
| 0.00 | 1.73 | 0.00 | 1.10 | 18.06 | 12.19 | -37.38 | 65.71 | 0.6356 | -543.0 | -405.1 | |
| 0.00 | 2.50 | 0.00 | 1.55 | 11.39 | 13.31 | -36.27 | 75.88 | 0.6002 | -680.0 | -497.3 | |
| 0.43 | 1.47 | 0.27 | 0.92 | 13.27 | 12.82 | -36.76 | 72.96 | 0.6115 | 586.8 | 524.3 | |
| 0.00 | 1.38 | 0.00 | 0.88 | 16.49 | 12.09 | -37.48 | 68.14 | 0.6310 | 772.0 | 631.1 | |
| 10.61 | 251.35 | 6.69 | 161.68 | 14.52 | 12.39 | -37.18 | 71.10 | 0.6207 | -699.0 | 205.2 | |
| 0.00 | 1.64 | 0.00 | 1.04 | 14.94 | 12.04 | -37.54 | 70.57 | 0.6265 | 612.0 | 525.7 | |
| 0.86 | 3.54 | 0.54 | 2.23 | 13.19 | 12.30 | -37.28 | 73.25 | 0.6182 | 633.4 | 540.1 | |
| 0.00 | 1.04 | 0.00 | 0.66 | 16.26 | 11.52 | -38.06 | 68.72 | 0.6374 | 459.0 | 328.3 | |
| 1.38 | -37.00 | 0.88 | -37.00 | 14.65 | 11.67 | -37.91 | 71.15 | 0.6304 | -72.6 | 999999 | |
| 0.00 | 2.59 | 0.00 | 1.64 | 13.26 | 11.82 | -37.76 | 73.27 | 0.6246 | 500.0 | 478.3 | |
| 0.00 | 0.43 | 0.00 | 0.28 | 17.79 | 10.75 | -38.83 | 66.71 | 0.6523 | 713.0 | 608.0 | |
| 9.66 | -37.00 | 6.16 | -37.00 | 14.37 | 11.49 | -38.08 | 71.64 | 0.6319 | -779.7 | 999999 | |
| 0.00 | 2.07 | 0.00 | 1.35 | 18.06 | 10.60 | -38.98 | 66.37 | 0.6551 | 731.0 | 581.6 | |
| 5.26 | -37.00 | 3.37 | -37.00 | 14.75 | 11.18 | -38.40 | 71.15 | 0.6370 | 933.5 | 999999 | |
| 0.00 | 1.64 | 0.00 | 1.08 | 18.14 | 10.21 | -39.36 | 66.41 | 0.6600 | 745.0 | 675.7 | |
| 2.76 | -37.00 | 1.77 | -37.00 | 14.35 | 11.03 | -38.55 | 71.82 | 0.6378 | -428.8 | 999999 | |
| 1.12 | -37.00 | 0.72 | -37.00 | 14.31 | 10.76 | -38.82 | 71.96 | 0.6411 | -546.2 | 999999 | |
| 0.00 | 0.86 | 0.00 | 0.55 | 11.31 | 11.26 | -38.32 | 76.50 | 0.6275 | -399.0 | -380.2 | |
| 0.00 | 1.38 | 0.00 | 0.91 | 17.54 | 9.80 | -39.77 | 67.45 | 0.6628 | 759.0 | 634.2 | |
| 17.86 | -37.00 | 11.57 | -37.00 | 14.75 | 10.39 | -39.19 | 71.40 | 0.6470 | 955.1 | 999999 | |
| 5.09 | 11.91 | 3.35 | 7.84 | 16.99 | 9.79 | -39.79 | 68.27 | 0.6612 | 910.3 | 728.8 | |
| 1.47 | 6.90 | 0.95 | 4.45 | 13.42 | 10.50 | -39.08 | 73.40 | 0.6421 | -705.5 | -658.5 | |
| 4.23 | -37.00 | 2.74 | -37.00 | 14.35 | 10.27 | -39.30 | 72.04 | 0.6474 | -670.0 | 999999 | |
| 0.26 | -54.00 | 0.17 | -54.00 | 13.57 | 10.43 | -39.14 | 73.19 | 0.6434 | -824.0 | 999999 | |
| 8.97 | -37.00 | 5.84 | -37.00 | 14.43 | 10.06 | -39.52 | 71.98 | 0.6503 | -543.6 | 999999 | |
| 0.00 | 4.31 | 0.00 | 2.85 | 16.67 | 9.54 | -40.04 | 68.82 | 0.6632 | 821.0 | 634.2 | |
| 10.87 | -37.00 | 7.12 | -37.00 | 15.00 | 9.66 | -39.92 | 71.26 | 0.6569 | 925.7 | 999999 | |
| 0.00 | 1.81 | 0.00 | 1.20 | 16.42 | 9.32 | -40.26 | 69.26 | 0.6651 | 618.0 | 599.7 | |
| 6.64 | 21.40 | 4.33 | 13.93 | 13.85 | 9.78 | -39.80 | 72.95 | 0.6523 | -673.4 | -561.4 | |
| 0.00 | 0.78 | 0.00 | 0.52 | 17.10 | 8.82 | -40.76 | 68.44 | 0.6733 | 562.0 | 526.2 | |
| 0.00 | 3.28 | 0.00 | 2.16 | 15.19 | 9.29 | -40.29 | 71.08 | 0.6620 | 149.0 | 119.8 | |
| 0.00 | 14.15 | 0.00 | 9.42 | 16.43 | 8.91 | -40.67 | 69.38 | 0.6702 | 911.0 | 626.6 | |
| 1.64 | -37.00 | 1.08 | -37.00 | 15.01 | 9.21 | -40.37 | 71.38 | 0.6625 | -462.1 | 999999 | |
| 0.00 | 5.26 | 0.00 | 3.43 | 12.54 | 9.60 | -39.98 | 74.98 | 0.6517 | 242.0 | -36.1 | |
| 0.00 | 0.86 | 0.00 | 0.56 | 12.81 | 9.55 | -40.03 | 74.58 | 0.6529 | -336.0 | -321.2 | |
| 0.00 | 0.69 | 0.00 | 0.45 | 14.22 | 9.18 | -40.40 | 72.56 | 0.6608 | -370.0 | -306.9 | |
| 0.86 | 154.45 | 0.58 | 105.41 | 16.90 | 8.46 | -41.12 | 68.84 | 0.6771 | 825.4 | 181.7 | |
| 7.94 | 30.11 | 5.29 | 20.13 | 15.78 | 8.66 | -40.92 | 70.41 | 0.6713 | -715.3 | -112.6 | |
| 0.00 | 1.12 | 0.00 | 0.76 | 17.93 | 8.01 | -41.57 | 67.52 | 0.6856 | 723.0 | 618.8 | |
| 0.00 | 3.54 | 0.00 | 2.41 | 18.24 | 7.92 | -41.66 | 67.12 | 0.6876 | 698.0 | 488.2 | |
| 0.00 | 1.21 | 0.00 | 0.82 | 17.59 | 8.06 | -41.52 | 67.99 | 0.6839 | 653.0 | 539.7 | |
| 2.93 | -69.00 | 1.97 | -69.00 | 16.68 | 8.23 | -41.35 | 69.24 | 0.6792 | 15.2 | 999999 | |
| 1.64 | -70.00 | 1.10 | -70.00 | 15.65 | 8.45 | -41.13 | 70.66 | 0.6736 | -649.6 | 999999 | |
| 0.00 | 2.93 | 0.00 | 1.99 | 17.68 | 7.83 | -41.75 | 67.95 | 0.6869 | 685.0 | 521.4 | |
| 11.13 | -69.00 | 7.53 | -69.00 | 17.07 | 7.96 | -41.62 | 68.77 | 0.6835 | 1020.0 | 999999 | |
| 6.64 | -69.00 | 4.54 | -69.00 | 17.54 | 7.49 | -42.09 | 68.25 | 0.6904 | 819.7 | 999999 | |
| 8.80 | -69.00 | 6.00 | -69.00 | 17.14 | 7.43 | -42.14 | 68.84 | 0.6899 | -405.8 | 999999 | |
| 0.00 | 1.12 | 0.00 | 0.78 | 19.51 | 6.54 | -43.04 | 65.83 | 0.7075 | 536.0 | 486.9 | |
| 3.11 | -69.00 | 2.12 | -69.00 | 16.82 | 7.23 | -42.35 | 69.35 | 0.6915 | -743.1 | 999999 | |
| 5.26 | -69.00 | 3.63 | -69.00 | 17.67 | 6.86 | -42.72 | 68.27 | 0.6982 | 549.8 | 999999 | |
| 0.00 | 0.69 | 0.00 | 0.47 | 15.05 | 7.18 | -42.39 | 71.89 | 0.6874 | -439.0 | -317.8 | |
| 0.00 | 1.29 | 0.00 | 0.88 | 15.19 | 6.98 | -42.60 | 71.74 | 0.6902 | -535.0 | -453.8 | |
| 0.00 | 0.35 | 0.00 | 0.24 | 19.35 | 5.59 | -43.98 | 66.37 | 0.7176 | 329.0 | 413.2 | |
| 1.98 | 14.75 | 1.37 | 10.24 | 15.74 | 6.16 | -43.41 | 71.18 | 0.7012 | 623.5 | -26.9 | |
| 0.00 | 1.12 | 0.00 | 0.76 | 12.07 | 6.84 | -42.73 | 76.27 | 0.6855 | -492.0 | -407.8 | |
| 1.21 | -86.00 | 0.84 | -86.00 | 15.85 | 5.92 | -43.66 | 71.09 | 0.7043 | -294.1 | 999999 | |
| 0.00 | 1.81 | 0.00 | 1.27 | 15.74 | 5.56 | -44.01 | 71.33 | 0.7083 | -628.0 | -584.7 | |
| 0.00 | 1.04 | 0.00 | 0.74 | 18.22 | 4.64 | -44.93 | 68.18 | 0.7250 | 517.0 | 478.2 | |
| 0.95 | 2.24 | 0.67 | 1.58 | 15.85 | 5.23 | -44.35 | 71.27 | 0.7124 | -517.3 | -402.3 | |
| 0.00 | 1.98 | 0.00 | 1.42 | 17.51 | 4.61 | -44.97 | 69.16 | 0.7235 | 660.0 | 552.7 | |
| 0.00 | 0.86 | 0.00 | 0.62 | 17.41 | 4.46 | -45.12 | 69.33 | 0.7249 | 597.0 | 561.5 | |
| 0.00 | 1.98 | 0.00 | 1.43 | 17.12 | 4.20 | -45.38 | 69.79 | 0.7272 | 595.0 | 551.2 | |
| 0.00 | 3.11 | 0.00 | 2.27 | 18.01 | 3.32 | -46.25 | 68.84 | 0.7390 | 577.0 | 469.1 | |
| 1.64 | 25.11 | 1.20 | 18.47 | 17.17 | 3.24 | -46.34 | 69.97 | 0.7380 | 843.9 | 287.9 | |
| 1.98 | -96.00 | 1.46 | -96.00 | 17.56 | 2.93 | -46.65 | 69.53 | 0.7423 | 539.6 | 999999 | |
| 0.95 | 2.24 | 0.70 | 1.66 | 17.83 | 2.84 | -46.74 | 69.20 | 0.7439 | 375.8 | 259.0 | |
| 2.24 | -96.00 | 1.65 | -96.00 | 17.28 | 2.98 | -46.60 | 69.89 | 0.7412 | 609.3 | 999999 | |
| 3.11 | -96.00 | 2.28 | -96.00 | 17.04 | 2.92 | -46.66 | 70.23 | 0.7412 | 660.2 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
