SDO HMI 2014-11-07 23:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.51 | 20.53 | 1.42 | 11.59 | 5.29 | 72.47 | 28.41 | 274.32 | 0.4765 | -360.1 | -289.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-07 23:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 4.92 | 0.00 | 2.86 | 5.59 | 75.77 | 31.71 | 274.68 | 0.5270 | -830.0 | -719.0 | |
| 0.86 | 2.16 | 0.50 | 1.24 | 5.30 | 74.84 | 30.78 | 274.17 | 0.5130 | -811.4 | -684.9 | |
| 0.00 | 1.55 | 0.00 | 0.89 | 4.57 | 74.46 | 30.40 | 272.75 | 0.5070 | -735.0 | -500.8 | |
| 0.00 | 0.86 | 0.00 | 0.49 | 5.31 | 73.63 | 29.57 | 274.27 | 0.4948 | -579.0 | -555.4 | |
| 0.78 | 2.07 | 0.44 | 1.18 | 5.23 | 73.35 | 29.29 | 274.12 | 0.4905 | -992.0 | -862.7 | |
| 0.52 | 1.55 | 0.29 | 0.88 | 5.11 | 73.18 | 29.12 | 273.90 | 0.4878 | -893.8 | -752.2 | |
| 0.35 | 2.50 | 0.19 | 1.40 | 5.93 | 71.66 | 27.60 | 275.77 | 0.4651 | 812.0 | 709.8 | |
| 0.00 | 0.95 | 0.00 | 0.53 | 4.40 | 71.31 | 27.26 | 272.46 | 0.4590 | -636.0 | -491.0 | |
| 0.00 | 2.33 | 0.00 | 1.25 | 6.35 | 66.37 | 22.31 | 277.74 | 0.3824 | 755.0 | 653.0 | |
| 0.00 | 1.12 | 0.00 | 0.59 | 2.38 | 64.48 | 20.42 | 266.94 | 0.3507 | 6.0 | 4.1 | |
| 0.00 | 0.26 | 0.00 | 0.14 | 5.18 | 64.46 | 20.40 | 274.95 | 0.3500 | 7.0 | 8.7 | |
| 0.00 | 0.26 | 0.00 | 0.14 | 5.27 | 64.46 | 20.40 | 275.21 | 0.3502 | 12.0 | 22.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
