SDO HMI 2014-11-08 18:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.62 | 25.84 | 1.92 | 13.96 | -14.91 | 19.85 | -13.78 | 144.63 | 0.3925 | -87.1 | 10.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-08 18:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.03 | 0.00 | 0.53 | -11.69 | 28.24 | -5.40 | 160.71 | 0.2802 | 748.0 | 528.6 | |
| 0.00 | 2.24 | 0.00 | 1.18 | -13.64 | 23.85 | -9.79 | 150.77 | 0.3399 | 824.0 | 670.0 | |
| 0.00 | 0.86 | 0.00 | 0.46 | -14.61 | 23.09 | -10.55 | 150.36 | 0.3598 | 775.0 | 668.0 | |
| 1.64 | 5.00 | 0.86 | 2.63 | -12.94 | 22.45 | -11.18 | 146.29 | 0.3421 | 1119.4 | 875.9 | |
| 0.00 | 3.53 | 0.00 | 1.87 | -13.25 | 22.25 | -11.39 | 146.34 | 0.3482 | 926.0 | 753.4 | |
| 1.98 | 4.66 | 1.06 | 2.50 | -14.34 | 19.84 | -13.80 | 142.96 | 0.3852 | -997.0 | -746.7 | |
| 0.00 | 1.12 | 0.00 | 0.62 | -15.93 | 16.43 | -17.21 | 139.36 | 0.4387 | -653.0 | -585.9 | |
| 0.00 | 2.67 | 0.00 | 1.48 | -16.29 | 15.84 | -17.79 | 138.98 | 0.4488 | -920.0 | -739.5 | |
| 0.00 | 1.81 | 0.00 | 1.02 | -18.62 | 15.50 | -18.13 | 141.82 | 0.4791 | -754.0 | -713.0 | |
| 0.00 | 1.03 | 0.00 | 0.59 | -18.73 | 14.40 | -19.24 | 140.35 | 0.4911 | -880.0 | -699.2 | |
| 0.00 | 0.86 | 0.00 | 0.49 | -19.32 | 14.26 | -19.38 | 140.95 | 0.4990 | -363.0 | -457.7 | |
| 0.00 | 1.03 | 0.00 | 0.59 | -18.61 | 14.01 | -19.62 | 139.64 | 0.4935 | -647.0 | -536.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
