SDO HMI 2014-11-09 01:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.82 | 21.38 | 5.59 | 22.69 | -5.47 | 91.21 | 61.44 | 261.78 | 0.8826 | 83.3 | 183.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-09 01:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.10 | 13.37 | 3.62 | 15.49 | -5.13 | 94.14 | 64.37 | 262.64 | 0.9073 | 285.6 | 384.2 | |
| 1.72 | -1.00 | 1.97 | -1.00 | -5.10 | 93.58 | 63.81 | 262.60 | 0.9031 | 629.0 | 999999 | |
| 0.00 | 1.64 | 0.00 | 1.70 | -5.65 | 90.63 | 60.86 | 261.60 | 0.8806 | 403.0 | 304.4 | |
| 0.00 | 1.03 | 0.00 | 1.01 | -3.05 | 89.03 | 59.25 | 264.36 | 0.8645 | 501.0 | 432.2 | |
| 0.00 | 1.12 | 0.00 | 1.08 | -6.13 | 88.27 | 58.50 | 260.70 | 0.8611 | -343.0 | -267.8 | |
| 0.00 | 1.03 | 0.00 | 0.84 | -6.89 | 81.06 | 51.29 | 258.45 | 0.7930 | -449.0 | -444.0 | |
| 0.00 | 1.55 | 0.00 | 1.26 | -7.67 | 80.99 | 51.22 | 257.46 | 0.7937 | -283.0 | -277.7 | |
| 0.00 | 0.52 | 0.00 | 0.42 | -6.88 | 80.87 | 51.10 | 258.42 | 0.7909 | -535.0 | -545.0 | |
| 0.00 | 1.12 | 0.00 | 0.89 | -8.10 | 79.73 | 49.96 | 256.63 | 0.7814 | -518.0 | -434.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
