SDO HMI 2014-11-09 20:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 222.55 | 1047.64 | 113.28 | 534.01 | 14.87 | 12.55 | -6.79 | 28.69 | 0.2326 | -443.3 | -237.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-09 20:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.12 | 0.00 | 0.56 | 10.91 | 18.90 | -0.45 | 3.38 | 0.1302 | -868.0 | -707.8 | |
| 0.00 | 2.07 | 0.00 | 1.04 | 12.44 | 17.62 | -1.72 | 10.68 | 0.1592 | -1053.0 | -907.7 | |
| 0.00 | 4.31 | 0.00 | 2.16 | 12.29 | 17.38 | -1.97 | 12.34 | 0.1575 | -891.0 | -683.3 | |
| 0.00 | 1.38 | 0.00 | 0.69 | 12.41 | 16.83 | -2.51 | 15.42 | 0.1618 | -830.0 | -642.2 | |
| 0.00 | 0.95 | 0.00 | 0.49 | 20.92 | 15.87 | -3.48 | 10.70 | 0.3065 | -713.0 | -584.8 | |
| 47.82 | 428.42 | 24.19 | 216.76 | 14.70 | 15.80 | -3.55 | 17.10 | 0.2046 | -1476.7 | -448.5 | |
| 0.95 | -6.00 | 0.48 | -6.00 | 13.88 | 15.38 | -3.97 | 20.39 | 0.1936 | -1114.7 | 999999 | |
| 1.21 | -6.00 | 0.61 | -6.00 | 13.76 | 15.32 | -4.03 | 20.89 | 0.1921 | -1148.6 | 999999 | |
| 4.57 | -6.00 | 2.30 | -6.00 | 13.52 | 15.23 | -4.11 | 21.79 | 0.1888 | -1137.6 | 999999 | |
| 3.27 | -6.00 | 1.66 | -6.00 | 14.27 | 15.16 | -4.19 | 20.68 | 0.2013 | -1204.1 | 999999 | |
| 1.03 | 2.50 | 0.52 | 1.25 | 11.32 | 15.14 | -4.20 | 27.74 | 0.1551 | -1136.1 | -940.5 | |
| 10.08 | -6.00 | 5.09 | -6.00 | 13.97 | 15.07 | -4.27 | 21.65 | 0.1970 | -1374.3 | 999999 | |
| 1.90 | -6.00 | 0.96 | -6.00 | 14.48 | 15.03 | -4.31 | 20.87 | 0.2054 | -1107.5 | 999999 | |
| 1.55 | -6.00 | 0.79 | -6.00 | 14.63 | 15.00 | -4.35 | 20.74 | 0.2080 | -1039.4 | 999999 | |
| 0.00 | 1.21 | 0.00 | 0.61 | 12.13 | 14.80 | -4.55 | 27.23 | 0.1702 | -895.0 | -783.6 | |
| 3.88 | -6.00 | 1.96 | -6.00 | 14.48 | 14.73 | -4.62 | 22.21 | 0.2073 | -922.5 | 999999 | |
| 0.00 | 1.81 | 0.00 | 0.92 | 15.57 | 14.55 | -4.80 | 21.02 | 0.2257 | -863.0 | -660.6 | |
| 0.00 | 2.50 | 0.00 | 1.29 | 19.33 | 14.39 | -4.96 | 16.60 | 0.2866 | -1033.0 | -828.7 | |
| 0.00 | 0.78 | 0.00 | 0.39 | 15.39 | 14.31 | -5.04 | 22.30 | 0.2243 | -718.0 | -567.9 | |
| 0.00 | 1.90 | 0.00 | 0.95 | 11.86 | 14.22 | -5.12 | 30.90 | 0.1709 | -898.0 | -776.9 | |
| 0.00 | 1.21 | 0.00 | 0.62 | 16.36 | 13.97 | -5.37 | 21.94 | 0.2417 | -851.0 | -582.4 | |
| 0.00 | 2.50 | 0.00 | 1.26 | 11.35 | 13.81 | -5.54 | 34.60 | 0.1675 | -1119.0 | -920.4 | |
| 0.00 | 1.29 | 0.00 | 0.66 | 14.93 | 13.73 | -5.62 | 25.44 | 0.2212 | -957.0 | -779.9 | |
| 0.00 | 2.15 | 0.00 | 1.09 | 14.78 | 13.58 | -5.77 | 26.34 | 0.2200 | -1006.0 | -789.0 | |
| 0.00 | 2.93 | 0.00 | 1.49 | 15.11 | 13.54 | -5.81 | 25.81 | 0.2254 | -566.0 | -481.7 | |
| 0.00 | 0.95 | 0.00 | 0.48 | 10.96 | 13.51 | -5.84 | 37.42 | 0.1651 | -914.0 | -761.5 | |
| 1.03 | 2.93 | 0.52 | 1.48 | 13.72 | 13.36 | -5.99 | 29.63 | 0.2059 | 805.0 | 336.7 | |
| 0.00 | 1.03 | 0.00 | 0.52 | 10.87 | 13.15 | -6.20 | 39.44 | 0.1677 | -842.0 | -723.8 | |
| 2.07 | 383.79 | 1.05 | 195.27 | 14.20 | 12.89 | -6.46 | 30.33 | 0.2170 | 384.4 | -224.8 | |
| 0.00 | 0.78 | 0.00 | 0.40 | 16.17 | 12.80 | -6.55 | 26.46 | 0.2470 | -627.0 | -544.2 | |
| 3.10 | -29.00 | 1.58 | -29.00 | 14.35 | 12.60 | -6.74 | 31.04 | 0.2216 | 638.0 | 999999 | |
| 20.77 | -29.00 | 10.52 | -29.00 | 13.69 | 12.56 | -6.79 | 32.87 | 0.2125 | -1236.4 | 999999 | |
| 14.39 | -29.00 | 7.32 | -29.00 | 14.53 | 11.89 | -7.46 | 33.18 | 0.2306 | -958.2 | 999999 | |
| 6.63 | -29.00 | 3.38 | -29.00 | 14.71 | 11.73 | -7.62 | 33.30 | 0.2347 | 666.2 | 999999 | |
| 0.00 | 2.33 | 0.00 | 1.18 | 13.20 | 11.59 | -7.76 | 37.80 | 0.2153 | -146.0 | -216.9 | |
| 11.37 | -29.00 | 5.79 | -29.00 | 14.10 | 11.50 | -7.85 | 35.60 | 0.2285 | -1283.1 | 999999 | |
| 2.58 | -29.00 | 1.31 | -29.00 | 13.74 | 11.36 | -7.99 | 37.07 | 0.2250 | -1094.5 | 999999 | |
| 0.00 | 2.58 | 0.00 | 1.31 | 13.34 | 11.25 | -8.10 | 38.56 | 0.2209 | -721.0 | -530.7 | |
| 12.32 | -29.00 | 6.28 | -29.00 | 14.67 | 11.17 | -8.18 | 35.24 | 0.2395 | 1144.0 | 999999 | |
| 4.31 | -29.00 | 2.19 | -29.00 | 13.95 | 11.17 | -8.18 | 37.14 | 0.2298 | -1224.8 | 999999 | |
| 18.78 | -29.00 | 9.58 | -29.00 | 14.25 | 10.78 | -8.56 | 37.58 | 0.2377 | -1042.6 | 999999 | |
| 0.00 | 0.86 | 0.00 | 0.45 | 17.89 | 10.44 | -8.91 | 30.55 | 0.2912 | 888.0 | 745.1 | |
| 0.00 | 1.29 | 0.00 | 0.67 | 16.76 | 10.46 | -8.88 | 32.68 | 0.2751 | -783.0 | -680.6 | |
| 20.51 | -29.00 | 10.47 | -29.00 | 14.55 | 10.49 | -8.85 | 37.71 | 0.2447 | 846.0 | 999999 | |
| 0.00 | 2.93 | 0.00 | 1.51 | 16.58 | 10.19 | -9.16 | 33.85 | 0.2751 | -931.0 | -673.9 | |
| 0.00 | 1.98 | 0.00 | 1.03 | 18.04 | 9.93 | -9.42 | 31.67 | 0.2978 | 968.0 | 770.3 | |
| 0.00 | 1.21 | 0.00 | 0.63 | 17.89 | 9.62 | -9.73 | 32.78 | 0.2983 | 694.0 | 542.4 | |
| 1.03 | 23.44 | 0.54 | 12.18 | 17.73 | 9.28 | -10.07 | 33.97 | 0.2993 | 1246.5 | 757.9 | |
| 0.00 | 2.41 | 0.00 | 1.25 | 17.39 | 9.08 | -10.27 | 35.17 | 0.2967 | 1128.0 | 946.7 | |
| 0.00 | 1.21 | 0.00 | 0.62 | 17.03 | 9.06 | -10.28 | 35.97 | 0.2919 | 1062.0 | 922.6 | |
| 3.53 | 14.56 | 1.81 | 7.48 | 14.81 | 9.15 | -10.20 | 40.94 | 0.2625 | 1043.5 | 849.4 | |
| 1.90 | 104.09 | 0.98 | 54.01 | 16.75 | 9.05 | -10.30 | 36.60 | 0.2885 | 1181.9 | -42.3 | |
| 0.00 | 0.86 | 0.00 | 0.45 | 20.50 | 8.56 | -10.79 | 30.82 | 0.3436 | 917.0 | 741.5 | |
| 0.00 | 1.81 | 0.00 | 0.94 | 18.43 | 8.63 | -10.71 | 34.24 | 0.3148 | 928.0 | 686.6 | |
| 1.90 | -52.00 | 0.98 | -52.00 | 16.41 | 8.72 | -10.63 | 38.19 | 0.2874 | -1001.1 | 999999 | |
| 3.96 | -52.00 | 2.06 | -52.00 | 17.36 | 8.64 | -10.71 | 36.37 | 0.3005 | 844.0 | 999999 | |
| 0.00 | 1.90 | 0.00 | 0.98 | 16.08 | 8.67 | -10.67 | 39.07 | 0.2836 | 863.0 | 584.5 | |
| 0.00 | 0.95 | 0.00 | 0.50 | 20.50 | 8.40 | -10.95 | 31.19 | 0.3449 | 787.0 | 638.8 | |
| 7.67 | -52.00 | 3.98 | -52.00 | 16.96 | 8.50 | -10.85 | 37.55 | 0.2967 | 1029.3 | 999999 | |
| 0.00 | 1.81 | 0.00 | 0.94 | 16.14 | 8.45 | -10.90 | 39.51 | 0.2867 | -957.0 | -689.5 | |
| 6.03 | -52.00 | 3.14 | -52.00 | 17.51 | 8.18 | -11.16 | 37.17 | 0.3070 | -1103.1 | 999999 | |
| 0.60 | -52.00 | 0.31 | -52.00 | 17.23 | 8.10 | -11.24 | 37.94 | 0.3042 | -1141.0 | 999999 | |
| 0.00 | 1.03 | 0.00 | 0.53 | 15.07 | 8.10 | -11.25 | 42.98 | 0.2775 | -789.0 | -637.5 | |
| 0.00 | 0.43 | 0.00 | 0.22 | 12.42 | 8.19 | -11.15 | 50.36 | 0.2464 | -340.0 | -427.8 | |
| 0.00 | 0.95 | 0.00 | 0.50 | 20.80 | 7.57 | -11.78 | 32.55 | 0.3562 | 772.0 | 608.5 | |
| 0.00 | 0.69 | 0.00 | 0.35 | 13.38 | 7.87 | -11.47 | 48.19 | 0.2608 | 941.0 | 730.5 | |
| 0.00 | 1.03 | 0.00 | 0.55 | 20.49 | 7.40 | -11.95 | 33.43 | 0.3536 | 859.0 | 689.2 | |
| 1.81 | 3.62 | 0.93 | 1.86 | 13.40 | 7.62 | -11.72 | 48.71 | 0.2643 | 1038.9 | 795.5 | |
| 0.00 | 1.12 | 0.00 | 0.59 | 17.90 | 7.30 | -12.05 | 38.44 | 0.3209 | 870.0 | 750.3 | |
| 0.00 | 2.15 | 0.00 | 1.14 | 20.11 | 6.98 | -12.37 | 34.98 | 0.3525 | 722.0 | 626.8 | |
| 0.00 | 0.78 | 0.00 | 0.41 | 19.99 | 6.86 | -12.49 | 35.45 | 0.3520 | 981.0 | 861.8 | |
| 0.00 | 6.55 | 0.00 | 3.46 | 19.61 | 6.59 | -12.75 | 36.67 | 0.3497 | 500.0 | 834.1 | |
| 0.00 | 1.21 | 0.00 | 0.64 | 19.41 | 5.48 | -13.87 | 39.30 | 0.3585 | 875.0 | 719.2 | |
| 0.00 | 0.52 | 0.00 | 0.28 | 19.81 | 5.05 | -14.29 | 39.38 | 0.3677 | 876.0 | 711.0 | |
| 0.00 | 1.81 | 0.00 | 0.96 | 16.76 | 2.76 | -16.58 | 49.64 | 0.3602 | 889.0 | 709.1 | |
| 0.00 | 0.86 | 0.00 | 0.46 | 19.23 | 1.67 | -17.68 | 46.27 | 0.3985 | 772.0 | 574.1 | |
| 0.00 | 2.84 | 0.00 | 1.55 | 19.90 | 0.93 | -18.42 | 46.12 | 0.4139 | -820.0 | -734.9 | |
| 0.00 | 1.46 | 0.00 | 0.79 | 17.22 | 0.67 | -18.68 | 51.81 | 0.3909 | 571.0 | 569.5 | |
| 0.00 | 1.21 | 0.00 | 0.65 | 14.10 | 358.32 | -21.02 | 61.57 | 0.3973 | 821.0 | 549.2 | |
| 0.00 | 4.65 | 0.00 | 2.56 | 14.37 | 355.38 | -23.97 | 63.75 | 0.4407 | 430.0 | 607.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
