SDO HMI 2014-11-10 00:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 221.78 | 936.83 | 112.42 | 475.49 | 14.75 | 12.72 | -4.42 | 13.66 | 0.2148 | -367.2 | -232.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-10 00:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.90 | 0.00 | 0.94 | 5.49 | 20.00 | 2.86 | 305.54 | 0.0614 | -951.0 | -724.7 | |
| 0.00 | 1.12 | 0.00 | 0.56 | 12.33 | 17.82 | 0.68 | 355.71 | 0.1553 | -639.0 | -612.2 | |
| 0.00 | 1.90 | 0.00 | 0.95 | 12.51 | 17.72 | 0.59 | 356.36 | 0.1584 | -963.0 | -761.3 | |
| 0.00 | 1.03 | 0.00 | 0.52 | 12.66 | 16.87 | -0.26 | 1.61 | 0.1607 | -755.0 | -591.7 | |
| 49.99 | 382.25 | 25.25 | 193.07 | 14.68 | 15.80 | -1.34 | 6.61 | 0.1969 | -1426.6 | -446.6 | |
| 4.74 | -5.00 | 2.39 | -5.00 | 13.41 | 15.32 | -1.82 | 10.13 | 0.1764 | -1045.0 | 999999 | |
| 0.00 | 2.59 | 0.00 | 1.29 | 11.31 | 15.24 | -1.90 | 13.37 | 0.1411 | -1246.0 | -946.9 | |
| 13.10 | -5.00 | 6.60 | -5.00 | 13.83 | 15.16 | -1.98 | 10.52 | 0.1841 | -1318.4 | 999999 | |
| 7.33 | -5.00 | 3.70 | -5.00 | 14.29 | 15.13 | -2.01 | 10.25 | 0.1919 | -1171.3 | 999999 | |
| 1.55 | -5.00 | 0.78 | -5.00 | 14.50 | 14.76 | -2.38 | 11.85 | 0.1966 | -1029.9 | 999999 | |
| 0.00 | 0.86 | 0.00 | 0.43 | 11.88 | 14.75 | -2.39 | 15.55 | 0.1528 | -1021.0 | -822.3 | |
| 0.00 | 1.81 | 0.00 | 0.93 | 19.41 | 14.45 | -2.69 | 9.14 | 0.2798 | -853.0 | -660.0 | |
| 0.00 | 1.03 | 0.00 | 0.54 | 20.50 | 14.43 | -2.71 | 8.58 | 0.2978 | -927.0 | -723.4 | |
| 0.00 | 1.47 | 0.00 | 0.74 | 15.68 | 14.38 | -2.76 | 12.35 | 0.2178 | -729.0 | -604.4 | |
| 0.00 | 2.59 | 0.00 | 1.31 | 15.47 | 14.32 | -2.82 | 12.83 | 0.2145 | -697.0 | -574.1 | |
| 0.00 | 2.33 | 0.00 | 1.17 | 11.91 | 14.17 | -2.96 | 18.99 | 0.1562 | -1151.0 | -843.4 | |
| 0.00 | 1.72 | 0.00 | 0.89 | 18.76 | 14.05 | -3.09 | 10.93 | 0.2702 | -795.0 | -659.5 | |
| 0.00 | 0.43 | 0.00 | 0.22 | 11.07 | 13.82 | -3.32 | 23.21 | 0.1449 | -846.0 | -637.4 | |
| 0.00 | 1.72 | 0.00 | 0.86 | 11.28 | 13.78 | -3.35 | 22.84 | 0.1484 | -1164.0 | -970.5 | |
| 0.00 | 3.71 | 0.00 | 1.88 | 14.83 | 13.68 | -3.46 | 16.47 | 0.2067 | -986.0 | -764.1 | |
| 0.00 | 2.41 | 0.00 | 1.22 | 13.89 | 13.51 | -3.63 | 18.73 | 0.1922 | 152.0 | 130.9 | |
| 0.00 | 1.47 | 0.00 | 0.74 | 14.10 | 13.44 | -3.69 | 18.67 | 0.1960 | 771.0 | 528.6 | |
| 1.03 | 2.33 | 0.52 | 1.18 | 14.22 | 13.26 | -3.88 | 19.33 | 0.1990 | 617.6 | 410.7 | |
| 0.00 | 2.33 | 0.00 | 1.17 | 12.35 | 13.04 | -4.09 | 24.25 | 0.1706 | 1084.0 | 850.1 | |
| 0.00 | 1.03 | 0.00 | 0.53 | 18.48 | 12.74 | -4.40 | 15.66 | 0.2707 | -701.0 | -582.2 | |
| 19.05 | 54.13 | 9.61 | 27.31 | 13.68 | 12.78 | -4.36 | 22.58 | 0.1933 | -1197.5 | -531.4 | |
| 2.33 | 307.09 | 1.18 | 155.71 | 14.43 | 12.76 | -4.37 | 21.18 | 0.2053 | 574.7 | -130.5 | |
| 3.02 | -27.00 | 1.53 | -27.00 | 14.82 | 12.14 | -5.00 | 23.11 | 0.2155 | 634.3 | 999999 | |
| 15.69 | -27.00 | 7.95 | -27.00 | 14.61 | 12.02 | -5.12 | 24.01 | 0.2130 | -897.8 | 999999 | |
| 0.00 | 3.28 | 0.00 | 1.65 | 13.55 | 11.98 | -5.15 | 26.45 | 0.1970 | -404.0 | -334.4 | |
| 6.90 | -27.00 | 3.49 | -27.00 | 13.88 | 11.91 | -5.22 | 25.99 | 0.2026 | -1224.1 | 999999 | |
| 4.31 | -27.00 | 2.19 | -27.00 | 14.73 | 11.83 | -5.30 | 24.54 | 0.2162 | 541.3 | 999999 | |
| 0.00 | 5.86 | 0.00 | 2.96 | 13.46 | 11.65 | -5.49 | 28.13 | 0.1982 | -950.0 | -711.7 | |
| 11.38 | -27.00 | 5.76 | -27.00 | 14.13 | 11.60 | -5.54 | 26.77 | 0.2086 | -1292.6 | 999999 | |
| 3.10 | -27.00 | 1.57 | -27.00 | 13.79 | 11.49 | -5.65 | 28.02 | 0.2045 | -1102.8 | 999999 | |
| 0.00 | 1.81 | 0.00 | 0.91 | 12.92 | 11.48 | -5.66 | 30.28 | 0.1916 | -56.0 | 16.1 | |
| 0.00 | 1.12 | 0.00 | 0.58 | 17.86 | 11.25 | -5.89 | 21.40 | 0.2688 | 729.0 | 490.7 | |
| 0.00 | 0.78 | 0.00 | 0.39 | 13.49 | 11.37 | -5.77 | 29.24 | 0.2009 | -672.0 | -539.6 | |
| 3.71 | -27.00 | 1.88 | -27.00 | 13.97 | 11.27 | -5.87 | 28.50 | 0.2090 | -1198.8 | 999999 | |
| 12.58 | -27.00 | 6.39 | -27.00 | 14.70 | 11.13 | -6.01 | 27.42 | 0.2210 | 1103.4 | 999999 | |
| 0.00 | 1.12 | 0.00 | 0.58 | 18.02 | 10.77 | -6.36 | 22.72 | 0.2741 | 882.0 | 657.8 | |
| 16.72 | -27.00 | 8.48 | -27.00 | 14.24 | 10.86 | -6.28 | 29.48 | 0.2164 | -1097.9 | 999999 | |
| 0.00 | 0.78 | 0.00 | 0.40 | 17.86 | 10.40 | -6.73 | 24.13 | 0.2743 | 746.0 | 631.3 | |
| 21.38 | -27.00 | 10.86 | -27.00 | 14.54 | 10.48 | -6.66 | 30.21 | 0.2240 | 782.8 | 999999 | |
| 0.00 | 1.64 | 0.00 | 0.84 | 16.58 | 10.14 | -7.00 | 27.19 | 0.2568 | -909.0 | -569.6 | |
| 0.00 | 3.96 | 0.00 | 2.04 | 17.98 | 9.99 | -7.15 | 25.22 | 0.2790 | 723.0 | 598.4 | |
| 0.00 | 1.64 | 0.00 | 0.83 | 14.06 | 10.06 | -7.07 | 32.93 | 0.2207 | -880.0 | -755.4 | |
| 0.00 | 1.29 | 0.00 | 0.66 | 14.21 | 9.87 | -7.26 | 33.24 | 0.2246 | -348.0 | -275.7 | |
| 0.43 | 1.81 | 0.22 | 0.94 | 18.22 | 9.48 | -7.66 | 26.37 | 0.2864 | 780.6 | 745.4 | |
| 0.00 | 0.95 | 0.00 | 0.49 | 16.72 | 9.51 | -7.63 | 28.94 | 0.2640 | 702.0 | 516.8 | |
| 0.00 | 3.28 | 0.00 | 1.69 | 17.46 | 9.29 | -7.85 | 28.25 | 0.2765 | 898.0 | 871.3 | |
| 0.00 | 10.69 | 0.00 | 5.52 | 17.88 | 9.21 | -7.93 | 27.73 | 0.2834 | 1041.0 | 898.4 | |
| 0.00 | 3.79 | 0.00 | 1.96 | 18.28 | 9.16 | -7.98 | 27.20 | 0.2896 | 776.0 | 707.5 | |
| 0.00 | 4.40 | 0.00 | 2.26 | 16.75 | 9.16 | -7.98 | 29.96 | 0.2673 | 1130.0 | 900.9 | |
| 0.43 | 1.55 | 0.22 | 0.80 | 17.45 | 9.07 | -8.07 | 28.91 | 0.2782 | 1025.6 | 950.5 | |
| 0.00 | 0.95 | 0.00 | 0.49 | 17.00 | 9.06 | -8.08 | 29.80 | 0.2717 | 917.0 | 797.1 | |
| 3.62 | 5.60 | 1.85 | 2.86 | 14.78 | 9.08 | -8.06 | 34.54 | 0.2401 | 1031.3 | 708.1 | |
| 0.00 | 1.03 | 0.00 | 0.53 | 15.02 | 8.98 | -8.16 | 34.29 | 0.2444 | 779.0 | 651.7 | |
| 0.00 | 2.59 | 0.00 | 1.32 | 15.38 | 8.84 | -8.30 | 33.87 | 0.2507 | 646.0 | 554.5 | |
| 0.00 | 4.74 | 0.00 | 2.43 | 16.35 | 8.77 | -8.37 | 31.96 | 0.2650 | -673.0 | -610.9 | |
| 3.36 | 57.75 | 1.73 | 29.81 | 17.39 | 8.69 | -8.44 | 30.13 | 0.2804 | 844.7 | -153.3 | |
| 2.24 | 5.43 | 1.15 | 2.78 | 15.11 | 8.76 | -8.38 | 34.78 | 0.2477 | 1119.7 | 839.5 | |
| 6.21 | -61.00 | 3.20 | -61.00 | 16.99 | 8.49 | -8.64 | 31.49 | 0.2765 | 1043.8 | 999999 | |
| 0.00 | 1.12 | 0.00 | 0.57 | 13.35 | 8.54 | -8.59 | 40.12 | 0.2266 | 800.0 | 535.3 | |
| 5.77 | -61.00 | 2.98 | -61.00 | 17.51 | 8.25 | -8.89 | 31.18 | 0.2859 | -1146.3 | 999999 | |
| 1.29 | -61.00 | 0.67 | -61.00 | 17.23 | 8.23 | -8.91 | 31.76 | 0.2822 | -1033.5 | 999999 | |
| 0.00 | 0.86 | 0.00 | 0.44 | 16.41 | 8.27 | -8.87 | 33.33 | 0.2704 | 661.0 | 457.8 | |
| 0.00 | 1.03 | 0.00 | 0.53 | 13.35 | 8.27 | -8.87 | 41.01 | 0.2297 | 926.0 | 760.6 | |
| 0.00 | 0.95 | 0.00 | 0.49 | 15.46 | 7.72 | -9.42 | 37.07 | 0.2629 | -749.0 | -621.0 | |
| 0.00 | 2.24 | 0.00 | 1.14 | 13.31 | 7.62 | -9.52 | 43.09 | 0.2366 | 1071.0 | 894.4 | |
| 0.00 | 1.29 | 0.00 | 0.67 | 17.87 | 7.28 | -9.85 | 33.11 | 0.2995 | 661.0 | 451.1 | |
| 0.00 | 1.21 | 0.00 | 0.63 | 20.18 | 6.98 | -10.15 | 29.82 | 0.3342 | 702.0 | 604.7 | |
| 0.00 | 1.03 | 0.00 | 0.54 | 19.99 | 6.93 | -10.20 | 30.25 | 0.3320 | 948.0 | 840.9 | |
| 0.00 | 1.03 | 0.00 | 0.54 | 19.56 | 6.80 | -10.34 | 31.28 | 0.3271 | 801.0 | 564.0 | |
| 0.00 | 1.21 | 0.00 | 0.63 | 20.14 | 6.60 | -10.54 | 30.79 | 0.3369 | 657.0 | 527.5 | |
| 0.00 | 0.95 | 0.00 | 0.50 | 19.56 | 6.58 | -10.56 | 31.83 | 0.3290 | 787.0 | 651.0 | |
| 0.52 | 2.93 | 0.27 | 1.54 | 19.80 | 6.53 | -10.61 | 31.52 | 0.3328 | 1058.7 | 815.1 | |
| 0.00 | 1.90 | 0.00 | 1.01 | 21.47 | 5.79 | -11.34 | 30.53 | 0.3619 | 809.0 | 667.4 | |
| 0.00 | 1.03 | 0.00 | 0.54 | 19.55 | 5.93 | -11.20 | 33.34 | 0.3346 | 907.0 | 696.1 | |
| 0.00 | 0.95 | 0.00 | 0.50 | 21.53 | 5.56 | -11.58 | 30.94 | 0.3647 | 673.0 | 484.1 | |
| 0.00 | 0.95 | 0.00 | 0.49 | 16.12 | 3.55 | -13.58 | 45.62 | 0.3171 | 843.0 | 664.5 | |
| 0.00 | 0.95 | 0.00 | 0.51 | 19.28 | 1.65 | -15.48 | 42.53 | 0.3744 | 654.0 | 488.1 | |
| 0.00 | 1.12 | 0.00 | 0.60 | 20.04 | 0.89 | -16.25 | 42.41 | 0.3914 | -810.0 | -725.2 | |
| 0.00 | 1.90 | 0.00 | 1.01 | 17.24 | 0.71 | -16.43 | 48.31 | 0.3633 | 699.0 | 660.4 | |
| 0.00 | 0.78 | 0.00 | 0.41 | 14.97 | 359.74 | -17.40 | 55.00 | 0.3542 | 803.0 | 699.6 | |
| 0.00 | 1.38 | 0.00 | 0.73 | 8.33 | 358.04 | -19.10 | 74.74 | 0.3370 | -811.0 | -596.2 | |
| 0.00 | 2.07 | 0.00 | 1.12 | 13.90 | 355.74 | -21.40 | 62.39 | 0.4014 | 720.0 | 713.4 | |
| 0.00 | 0.86 | 0.00 | 0.47 | 14.41 | 355.59 | -21.55 | 61.38 | 0.4070 | 688.0 | 535.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
