SDO HMI 2014-11-10 14:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.95 | 18.27 | 0.56 | 10.57 | 19.03 | 342.24 | -27.24 | 57.56 | 0.5150 | 2.8 | -149.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-10 14:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.69 | 0.00 | 0.39 | 17.98 | 344.69 | -24.78 | 57.17 | 0.4764 | -491.0 | -535.8 | |
| 0.00 | 1.12 | 0.00 | 0.64 | 18.98 | 344.19 | -25.28 | 55.81 | 0.4902 | -628.0 | -495.3 | |
| 0.00 | 1.90 | 0.00 | 1.08 | 19.26 | 344.08 | -25.40 | 55.43 | 0.4937 | -656.0 | -598.0 | |
| 0.00 | 7.24 | 0.00 | 4.08 | 16.49 | 343.77 | -25.70 | 60.80 | 0.4783 | -800.0 | -695.9 | |
| 0.00 | 1.29 | 0.00 | 0.77 | 21.76 | 340.75 | -28.73 | 54.18 | 0.5526 | 760.0 | 617.9 | |
| 0.95 | 3.96 | 0.56 | 2.35 | 21.95 | 340.63 | -28.84 | 53.98 | 0.5553 | 827.3 | 791.8 | |
| 0.00 | 0.95 | 0.00 | 0.57 | 20.60 | 339.39 | -30.08 | 57.10 | 0.5610 | 746.0 | 517.4 | |
| 0.00 | 1.12 | 0.00 | 0.69 | 20.08 | 336.57 | -32.90 | 59.85 | 0.5923 | 627.0 | 481.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
