SDO HMI 2014-11-10 20:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 18.35 | 0.00 | 10.61 | -10.19 | 338.10 | -28.06 | 116.21 | 0.5178 | 20.4 | -87.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-10 20:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.21 | 0.00 | 0.67 | -10.02 | 342.58 | -23.58 | 119.91 | 0.4564 | 872.0 | 658.1 | |
| 0.00 | 1.21 | 0.00 | 0.66 | -5.36 | 342.50 | -23.66 | 110.18 | 0.4275 | 536.0 | 376.7 | |
| 0.00 | 1.03 | 0.00 | 0.58 | -9.57 | 342.09 | -24.08 | 118.55 | 0.4599 | 633.0 | 518.8 | |
| 0.00 | 1.03 | 0.00 | 0.58 | -9.96 | 341.03 | -25.14 | 118.28 | 0.4770 | 649.0 | 527.0 | |
| 0.00 | 0.95 | 0.00 | 0.53 | -6.77 | 340.36 | -25.80 | 111.48 | 0.4665 | 785.0 | 554.5 | |
| 0.00 | 0.78 | 0.00 | 0.44 | -11.46 | 339.95 | -26.21 | 120.00 | 0.5019 | 390.0 | 379.4 | |
| 0.00 | 2.07 | 0.00 | 1.18 | -11.22 | 339.77 | -26.39 | 119.41 | 0.5026 | 650.0 | 565.8 | |
| 0.00 | 3.10 | 0.00 | 1.84 | -12.08 | 336.16 | -30.00 | 117.88 | 0.5553 | -814.0 | -585.7 | |
| 0.00 | 2.41 | 0.00 | 1.42 | -10.09 | 336.35 | -29.81 | 114.69 | 0.5408 | -778.0 | -580.5 | |
| 0.00 | 1.12 | 0.00 | 0.66 | -10.08 | 335.52 | -30.65 | 114.10 | 0.5519 | -694.0 | -550.7 | |
| 0.00 | 1.29 | 0.00 | 0.77 | -10.88 | 335.21 | -30.95 | 115.23 | 0.5604 | -810.0 | -620.3 | |
| 0.00 | 1.03 | 0.00 | 0.61 | -10.18 | 335.29 | -30.87 | 114.11 | 0.5554 | -620.0 | -548.7 | |
| 0.00 | 1.12 | 0.00 | 0.67 | -10.29 | 334.82 | -31.34 | 113.98 | 0.5622 | -534.0 | -412.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
