SDO HMI 2014-11-11 17:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 15.77 | 0.00 | 8.28 | -9.63 | 340.74 | -13.90 | 135.04 | 0.3267 | 59.7 | 9.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-11 17:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.24 | 0.00 | 1.12 | -4.61 | 351.32 | -3.32 | 157.13 | 0.1492 | 831.0 | 651.9 | |
| 0.00 | 1.12 | 0.00 | 0.57 | -5.13 | 343.75 | -10.89 | 127.60 | 0.2386 | 801.0 | 626.7 | |
| 0.00 | 1.03 | 0.00 | 0.54 | -9.30 | 342.90 | -11.73 | 137.15 | 0.2965 | 823.0 | 677.1 | |
| 0.00 | 0.95 | 0.00 | 0.48 | -5.47 | 342.86 | -11.78 | 126.54 | 0.2541 | 785.0 | 634.3 | |
| 0.00 | 1.03 | 0.00 | 0.54 | -11.22 | 340.87 | -13.76 | 136.79 | 0.3424 | 709.0 | 576.2 | |
| 0.00 | 1.81 | 0.00 | 0.95 | -11.25 | 340.62 | -14.02 | 136.35 | 0.3456 | 801.0 | 630.9 | |
| 0.00 | 0.95 | 0.00 | 0.50 | -8.44 | 337.26 | -17.38 | 124.12 | 0.3585 | -745.0 | -515.9 | |
| 0.00 | 0.95 | 0.00 | 0.51 | -12.32 | 336.99 | -17.64 | 131.94 | 0.3997 | -836.0 | -659.1 | |
| 0.00 | 2.50 | 0.00 | 1.35 | -12.51 | 336.95 | -17.69 | 132.22 | 0.4022 | -711.0 | -499.4 | |
| 0.00 | 2.07 | 0.00 | 1.12 | -12.23 | 336.78 | -17.86 | 131.42 | 0.4014 | -862.0 | -747.1 | |
| 0.00 | 1.12 | 0.00 | 0.60 | -10.22 | 336.53 | -18.11 | 126.97 | 0.3845 | -939.0 | -816.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
