SDO HMI 2014-11-11 23:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.78 | 72.25 | 12.50 | 41.49 | -8.77 | 323.27 | -28.05 | 113.43 | 0.5086 | 963.0 | 524.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-11 23:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.72 | 0.00 | 1.00 | -11.09 | 323.48 | -27.84 | 117.74 | 0.5199 | 827.0 | 707.7 | |
| 7.23 | 62.86 | 4.14 | 36.05 | -8.74 | 323.59 | -27.73 | 113.63 | 0.5039 | 1252.5 | 508.2 | |
| 9.13 | -2.00 | 5.24 | -2.00 | -8.69 | 323.36 | -27.96 | 113.35 | 0.5069 | 1050.2 | 999999 | |
| 2.58 | -2.00 | 1.49 | -2.00 | -8.75 | 323.15 | -28.17 | 113.32 | 0.5101 | 886.3 | 999999 | |
| 2.84 | -2.00 | 1.63 | -2.00 | -8.60 | 323.10 | -28.22 | 113.01 | 0.5101 | 868.5 | 999999 | |
| 0.00 | 1.81 | 0.00 | 1.05 | -9.58 | 322.74 | -28.58 | 114.51 | 0.5206 | 864.0 | 668.0 | |
| 0.00 | 2.50 | 0.00 | 1.44 | -8.46 | 322.80 | -28.52 | 112.53 | 0.5134 | 572.0 | 470.9 | |
| 0.00 | 1.21 | 0.00 | 0.70 | -10.00 | 322.14 | -29.18 | 114.80 | 0.5310 | 684.0 | 530.1 | |
| 0.00 | 0.69 | 0.00 | 0.40 | -7.64 | 321.73 | -29.59 | 110.34 | 0.5240 | 711.0 | 543.1 | |
| 0.00 | 1.46 | 0.00 | 0.85 | -7.74 | 321.55 | -29.77 | 110.40 | 0.5270 | 732.0 | 652.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
