SDO HMI 2014-11-12 05:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 13.18 | 0.00 | 6.73 | -8.10 | 341.66 | -6.37 | 155.38 | 0.2340 | 114.9 | 194.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-12 05:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.98 | 0.00 | 0.99 | -4.66 | 350.89 | 2.87 | 200.08 | 0.1460 | 896.0 | 707.6 | |
| 0.00 | 2.93 | 0.00 | 1.47 | -4.98 | 343.62 | -4.40 | 151.71 | 0.1621 | 743.0 | 751.5 | |
| 0.00 | 0.86 | 0.00 | 0.43 | -4.90 | 343.39 | -4.64 | 150.16 | 0.1627 | 807.0 | 667.7 | |
| 0.00 | 0.69 | 0.00 | 0.35 | -9.61 | 343.00 | -5.03 | 158.67 | 0.2386 | 787.0 | 555.9 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -10.80 | 341.82 | -6.20 | 156.28 | 0.2649 | 802.0 | 691.1 | |
| 0.00 | 1.12 | 0.00 | 0.57 | -8.79 | 341.08 | -6.95 | 150.03 | 0.2403 | 699.0 | 485.8 | |
| 0.00 | 0.43 | 0.00 | 0.23 | -12.25 | 337.00 | -11.03 | 144.82 | 0.3259 | -877.0 | -751.2 | |
| 0.00 | 1.81 | 0.00 | 0.94 | -10.41 | 336.98 | -11.05 | 141.17 | 0.3019 | -856.0 | -634.4 | |
| 0.00 | 1.12 | 0.00 | 0.59 | -12.13 | 336.82 | -11.21 | 144.16 | 0.3260 | -932.0 | -753.7 | |
| 0.00 | 1.21 | 0.00 | 0.63 | -10.53 | 334.22 | -13.80 | 135.13 | 0.3339 | -920.0 | -665.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
