SDO HMI 2014-11-13 07:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.20 | 23.76 | 3.19 | 12.24 | -8.75 | 323.20 | -10.55 | 138.38 | 0.2739 | 981.2 | 806.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-13 07:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.12 | 0.00 | 0.58 | -10.74 | 323.95 | -9.80 | 144.86 | 0.2920 | 956.0 | 730.2 | |
| 2.50 | 17.74 | 1.28 | 9.13 | -8.67 | 323.46 | -10.29 | 138.91 | 0.2699 | 1316.7 | 897.5 | |
| 3.70 | -2.00 | 1.91 | -2.00 | -8.70 | 323.28 | -10.47 | 138.49 | 0.2723 | 1157.3 | 999999 | |
| 0.00 | 0.34 | 0.00 | 0.18 | -8.89 | 323.09 | -10.66 | 138.43 | 0.2767 | 622.0 | 497.2 | |
| 0.00 | 2.15 | 0.00 | 1.11 | -9.07 | 322.96 | -10.79 | 138.54 | 0.2804 | 780.0 | 632.7 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -7.44 | 322.09 | -11.66 | 132.13 | 0.2714 | 941.0 | 720.6 | |
| 0.00 | 1.38 | 0.00 | 0.71 | -8.29 | 321.91 | -11.84 | 133.96 | 0.2832 | 841.0 | 515.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
