SDO HMI 2014-11-13 18:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 14.27 | 0.00 | 7.38 | -9.86 | 338.14 | 10.42 | 217.79 | 0.2914 | -291.7 | -121.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-13 18:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 3.01 | 0.00 | 1.57 | -7.82 | 342.86 | 15.15 | 234.24 | 0.3204 | 727.0 | 749.6 | |
| 0.00 | 0.86 | 0.00 | 0.45 | -9.75 | 342.54 | 14.82 | 228.95 | 0.3358 | 845.0 | 706.7 | |
| 0.00 | 1.63 | 0.00 | 0.85 | -10.67 | 340.56 | 12.84 | 222.84 | 0.3227 | 932.0 | 783.7 | |
| 0.00 | 1.46 | 0.00 | 0.75 | -9.90 | 337.52 | 9.80 | 216.94 | 0.2803 | -925.0 | -776.0 | |
| 0.00 | 1.12 | 0.00 | 0.58 | -10.05 | 337.40 | 9.68 | 216.28 | 0.2812 | -794.0 | -661.5 | |
| 0.00 | 1.89 | 0.00 | 0.98 | -10.77 | 336.23 | 8.51 | 211.43 | 0.2802 | -711.0 | -485.9 | |
| 0.00 | 1.20 | 0.00 | 0.61 | -9.24 | 334.68 | 6.96 | 209.42 | 0.2446 | -893.0 | -805.0 | |
| 0.00 | 1.81 | 0.00 | 0.93 | -11.28 | 334.29 | 6.58 | 204.47 | 0.2724 | -836.0 | -690.3 | |
| 0.00 | 1.29 | 0.00 | 0.66 | -10.78 | 333.58 | 5.87 | 202.83 | 0.2599 | -970.0 | -736.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
