SDO HMI 2014-11-13 18:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 21.51 | 52.64 | 13.17 | 32.28 | 8.73 | 3.59 | 35.87 | 280.71 | 0.5916 | -0.7 | -141.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-13 18:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.81 | 3.35 | 1.14 | 2.12 | 8.29 | 6.00 | 38.29 | 279.54 | 0.6240 | -712.0 | -538.6 | |
| 1.46 | 3.53 | 0.92 | 2.21 | 8.32 | 5.32 | 37.60 | 279.68 | 0.6148 | -770.4 | -578.0 | |
| 0.00 | 2.24 | 0.00 | 1.39 | 7.97 | 4.87 | 37.15 | 279.20 | 0.6081 | -760.0 | -557.5 | |
| 0.00 | 0.77 | 0.00 | 0.48 | 8.36 | 4.80 | 37.08 | 279.85 | 0.6077 | -537.0 | -531.4 | |
| 0.00 | 1.03 | 0.00 | 0.64 | 8.10 | 4.73 | 37.01 | 279.42 | 0.6064 | -504.0 | -529.2 | |
| 4.56 | 19.61 | 2.82 | 12.12 | 8.17 | 4.29 | 36.57 | 279.62 | 0.6004 | -932.4 | -636.5 | |
| 4.47 | -6.00 | 2.76 | -6.00 | 8.38 | 4.16 | 36.45 | 279.99 | 0.5990 | -880.1 | 999999 | |
| 0.00 | 1.03 | 0.00 | 0.63 | 9.51 | 3.51 | 35.79 | 282.01 | 0.5920 | 500.0 | 440.9 | |
| 0.00 | 2.24 | 0.00 | 1.36 | 10.23 | 2.64 | 34.92 | 283.44 | 0.5815 | 511.0 | 362.5 | |
| 0.00 | 1.81 | 0.00 | 1.09 | 9.16 | 2.36 | 34.65 | 281.68 | 0.5753 | 371.0 | 267.7 | |
| 0.00 | 3.27 | 0.00 | 1.97 | 9.61 | 2.23 | 34.52 | 282.49 | 0.5744 | 779.0 | 617.6 | |
| 0.69 | 2.75 | 0.42 | 1.66 | 9.94 | 2.20 | 34.48 | 283.07 | 0.5747 | 936.0 | 648.5 | |
| 8.52 | 11.01 | 5.11 | 6.61 | 9.06 | 1.77 | 34.05 | 281.64 | 0.5668 | 953.9 | 671.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
