SDO HMI 2014-11-14 06:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 16.52 | 42.67 | 9.36 | 24.30 | 16.34 | 294.26 | -26.85 | 61.32 | 0.4959 | -450.7 | -125.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-14 06:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.72 | 32.27 | 5.51 | 18.28 | 16.45 | 294.87 | -26.24 | 60.65 | 0.4885 | -971.2 | -437.7 | |
| 2.07 | -1.00 | 1.17 | -1.00 | 16.11 | 294.92 | -26.19 | 61.24 | 0.4857 | -1066.2 | 999999 | |
| 4.73 | -1.00 | 2.68 | -1.00 | 16.01 | 294.66 | -26.45 | 61.64 | 0.4886 | -904.1 | 999999 | |
| 0.00 | 3.01 | 0.00 | 1.71 | 16.35 | 294.57 | -26.54 | 61.08 | 0.4918 | -380.0 | -344.5 | |
| 0.00 | 1.89 | 0.00 | 1.09 | 16.03 | 292.53 | -28.58 | 63.20 | 0.5172 | 707.0 | 545.5 | |
| 0.00 | 0.34 | 0.00 | 0.20 | 17.18 | 292.16 | -28.95 | 61.41 | 0.5287 | 777.0 | 639.2 | |
| 0.00 | 3.61 | 0.00 | 2.10 | 16.26 | 292.03 | -29.08 | 63.13 | 0.5251 | 690.0 | 619.8 | |
| 0.00 | 1.55 | 0.00 | 0.92 | 17.87 | 290.17 | -30.94 | 61.61 | 0.5584 | 755.0 | 644.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
