SDO HMI 2014-11-14 09:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 7.74 | 0.00 | 4.33 | 12.21 | 295.27 | -24.21 | 66.71 | 0.4628 | -261.8 | -156.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-14 09:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.46 | 0.00 | 0.80 | 18.27 | 299.99 | -19.48 | 49.84 | 0.4162 | -842.0 | -529.6 | |
| 0.00 | 1.03 | 0.00 | 0.56 | 17.84 | 299.91 | -19.57 | 50.80 | 0.4132 | -863.0 | -669.4 | |
| 0.00 | 2.24 | 0.00 | 1.26 | 20.95 | 296.96 | -22.52 | 48.82 | 0.4772 | -920.0 | -600.0 | |
| 0.00 | 1.29 | 0.00 | 0.73 | 1.64 | 290.83 | -28.65 | 91.94 | 0.4815 | 596.0 | 445.5 | |
| 0.00 | 1.72 | 0.00 | 0.98 | 0.67 | 289.89 | -29.59 | 93.80 | 0.4969 | 720.0 | 561.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
