SDO HMI 2014-11-14 11:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 12.31 | 0.00 | 6.28 | -10.36 | 322.97 | 4.59 | 198.98 | 0.2439 | 925.3 | 720.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-14 11:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.03 | 0.00 | 0.52 | -8.69 | 323.28 | 4.90 | 202.76 | 0.2192 | 1105.0 | 948.2 | |
| 0.00 | 3.79 | 0.00 | 1.94 | -10.97 | 323.31 | 4.93 | 199.36 | 0.2556 | 885.0 | 773.5 | |
| 0.00 | 0.95 | 0.00 | 0.48 | -10.61 | 323.16 | 4.77 | 199.28 | 0.2488 | 953.0 | 793.5 | |
| 0.00 | 1.89 | 0.00 | 0.97 | -10.42 | 323.00 | 4.62 | 198.94 | 0.2450 | 1012.0 | 700.5 | |
| 0.00 | 1.81 | 0.00 | 0.93 | -12.53 | 323.00 | 4.62 | 196.44 | 0.2790 | 873.0 | 643.7 | |
| 0.00 | 0.69 | 0.00 | 0.35 | -9.84 | 322.75 | 4.37 | 198.77 | 0.2343 | 795.0 | 521.4 | |
| 0.00 | 2.15 | 0.00 | 1.09 | -8.23 | 322.16 | 3.78 | 198.64 | 0.2051 | 854.0 | 632.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
