SDO HMI 2014-11-14 12:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 14.19 | 30.61 | 7.82 | 16.92 | 16.38 | 294.87 | -22.97 | 57.68 | 0.4448 | -678.6 | -455.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-14 12:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.20 | 0.00 | 0.67 | 18.49 | 295.89 | -21.95 | 52.51 | 0.4487 | -621.0 | -471.1 | |
| 8.34 | 24.77 | 4.60 | 13.64 | 16.43 | 295.28 | -22.56 | 57.19 | 0.4397 | -966.4 | -656.2 | |
| 5.85 | -2.00 | 3.22 | -2.00 | 16.12 | 295.25 | -22.59 | 57.84 | 0.4378 | -1013.4 | 999999 | |
| 0.00 | 1.89 | 0.00 | 1.04 | 15.10 | 294.49 | -23.34 | 60.66 | 0.4407 | -833.0 | -664.6 | |
| 0.00 | 1.72 | 0.00 | 0.97 | 16.27 | 291.94 | -25.90 | 60.65 | 0.4830 | 648.0 | 476.0 | |
| 0.00 | 1.03 | 0.00 | 0.60 | 18.32 | 290.15 | -27.68 | 58.43 | 0.5197 | 494.0 | 376.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
