SDO HMI 2014-11-15 09:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 4.22 | 0.00 | 2.17 | 14.87 | 304.64 | -1.65 | 94.50 | 0.2593 | -330.2 | -291.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-15 09:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.03 | 0.00 | 0.53 | 11.09 | 319.80 | 13.51 | 302.37 | 0.2726 | -828.0 | -668.7 | |
| 0.00 | 0.95 | 0.00 | 0.47 | 7.66 | 302.72 | -3.57 | 36.10 | 0.1052 | 989.0 | 785.4 | |
| 0.00 | 1.12 | 0.00 | 0.58 | 18.06 | 299.45 | -6.84 | 23.28 | 0.2878 | -661.0 | -511.6 | |
| 0.00 | 1.12 | 0.00 | 0.59 | 20.87 | 297.67 | -8.62 | 24.29 | 0.3420 | -821.0 | -595.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
