SDO HMI 2014-11-16 10:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 8.25 | 25.36 | 12.08 | 35.86 | -12.33 | 224.30 | -68.26 | 104.26 | 0.9369 | -103.8 | 81.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-16 10:00:27 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.72 | 0.00 | 2.05 | -13.06 | 228.45 | -64.12 | 105.66 | 0.9120 | 311.0 | 259.2 | |
| 1.12 | 2.75 | 1.35 | 3.33 | -12.95 | 228.15 | -64.42 | 105.49 | 0.9139 | 397.5 | 270.3 | |
| 0.00 | 1.55 | 0.00 | 1.85 | -11.56 | 228.29 | -64.28 | 104.01 | 0.9114 | 453.0 | 337.3 | |
| 0.00 | 1.63 | 0.00 | 1.97 | -11.52 | 227.95 | -64.61 | 103.91 | 0.9137 | 251.0 | 202.3 | |
| 0.60 | 1.81 | 0.76 | 2.29 | -11.30 | 226.66 | -65.90 | 103.48 | 0.9222 | 288.9 | 254.8 | |
| 1.89 | 15.90 | 2.85 | 24.37 | -12.20 | 222.86 | -69.70 | 103.91 | 0.9459 | -530.0 | -38.2 | |
| 4.64 | -6.00 | 7.12 | -6.00 | -12.49 | 222.51 | -70.06 | 104.17 | 0.9480 | -256.4 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
