SDO HMI 2014-11-18 03:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 31.95 | 74.12 | 23.57 | 54.39 | -13.25 | 224.85 | -45.17 | 110.61 | 0.7393 | -210.9 | -99.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-18 03:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.49 | 0.00 | 1.71 | -13.28 | 228.93 | -41.10 | 112.24 | 0.6935 | 669.0 | 518.8 | |
| 0.00 | 1.29 | 0.00 | 0.88 | -13.04 | 228.77 | -41.25 | 111.84 | 0.6943 | 785.0 | 553.4 | |
| 2.49 | 11.34 | 1.72 | 7.83 | -12.81 | 228.37 | -41.65 | 111.35 | 0.6981 | 805.0 | 498.7 | |
| 3.09 | -3.00 | 2.14 | -3.00 | -12.96 | 228.22 | -41.80 | 111.50 | 0.7005 | 652.4 | 999999 | |
| 0.00 | 1.37 | 0.00 | 0.96 | -12.85 | 227.75 | -42.27 | 111.16 | 0.7056 | 528.0 | 384.2 | |
| 0.00 | 0.86 | 0.00 | 0.61 | -13.82 | 226.40 | -43.62 | 111.90 | 0.7243 | -676.0 | -550.5 | |
| 0.00 | 0.86 | 0.00 | 0.62 | -14.91 | 226.09 | -43.93 | 113.21 | 0.7318 | -555.0 | -467.6 | |
| 6.96 | 10.05 | 5.06 | 7.31 | -15.22 | 225.96 | -44.06 | 113.56 | 0.7344 | -778.0 | -515.2 | |
| 2.49 | 4.12 | 1.79 | 2.96 | -12.51 | 225.81 | -44.21 | 109.95 | 0.7265 | 756.2 | 570.3 | |
| 1.20 | 4.38 | 0.87 | 3.16 | -12.76 | 225.67 | -44.35 | 110.23 | 0.7289 | 665.7 | 456.2 | |
| 2.49 | 4.38 | 1.80 | 3.17 | -12.71 | 225.38 | -44.64 | 110.05 | 0.7320 | 655.5 | 438.7 | |
| 0.00 | 1.20 | 0.00 | 0.87 | -12.69 | 225.22 | -44.80 | 109.96 | 0.7338 | 365.0 | 296.9 | |
| 0.00 | 1.20 | 0.00 | 0.88 | -12.74 | 224.51 | -45.51 | 109.77 | 0.7418 | -621.0 | -502.7 | |
| 0.00 | 0.77 | 0.00 | 0.58 | -13.00 | 223.97 | -46.05 | 109.93 | 0.7485 | -745.0 | -608.2 | |
| 0.00 | 1.80 | 0.00 | 1.34 | -12.75 | 223.98 | -46.04 | 109.61 | 0.7476 | -762.0 | -688.5 | |
| 2.66 | 7.39 | 2.02 | 5.61 | -13.37 | 223.08 | -46.94 | 110.09 | 0.7593 | -773.4 | -595.9 | |
| 0.00 | 1.20 | 0.00 | 0.92 | -12.83 | 222.67 | -47.35 | 109.27 | 0.7620 | -580.0 | -475.8 | |
| 0.00 | 0.52 | 0.00 | 0.39 | -12.58 | 222.69 | -47.33 | 108.96 | 0.7611 | -659.0 | -612.2 | |
| 0.00 | 1.29 | 0.00 | 0.98 | -12.86 | 222.48 | -47.54 | 109.25 | 0.7641 | -630.0 | -513.0 | |
| 10.57 | 17.61 | 8.17 | 13.61 | -12.88 | 221.89 | -48.13 | 109.09 | 0.7705 | -614.0 | -468.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
