SDO HMI 2014-11-20 10:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 58.19 | 470.56 | 118.98 | 1014.63 | -13.37 | 164.70 | -75.14 | 104.37 | 0.9707 | 151.1 | -183.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-20 10:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.60 | 0.00 | 0.97 | -10.47 | 168.51 | -71.33 | 101.75 | 0.9529 | 177.0 | 197.1 | |
| 46.00 | 455.45 | 84.60 | 968.01 | -12.98 | 166.42 | -73.42 | 104.14 | 0.9643 | 312.4 | -194.4 | |
| 5.15 | -2.00 | 13.60 | -2.00 | -13.97 | 161.50 | -78.33 | 104.67 | 0.9833 | -522.5 | 999999 | |
| 6.01 | -2.00 | 17.70 | -2.00 | -14.66 | 160.42 | -79.42 | 105.28 | 0.9866 | -57.5 | 999999 | |
| 1.03 | 2.75 | 3.08 | 8.22 | -14.08 | 160.21 | -79.63 | 104.68 | 0.9870 | 258.1 | 195.0 | |
| 0.00 | 1.37 | 0.00 | 4.75 | -14.87 | 158.99 | -80.85 | 105.37 | 0.9903 | 380.0 | 354.0 | |
| 0.00 | 3.26 | 0.00 | 11.30 | -14.41 | 158.97 | -80.87 | 104.91 | 0.9902 | -204.0 | -17.3 | |
| 0.00 | 2.32 | 0.00 | 6.80 | -13.37 | 160.31 | -79.52 | 103.97 | 0.9866 | -366.0 | -332.9 | |
| 0.00 | 0.69 | 0.00 | 1.97 | -13.09 | 160.51 | -79.33 | 103.70 | 0.9860 | -294.0 | -315.9 | |
| 0.00 | 4.12 | 0.00 | 12.61 | -12.84 | 159.97 | -79.86 | 103.40 | 0.9874 | 86.0 | 116.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
