SDO HMI 2014-11-20 23:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 46.91 | 0.00 | 24.31 | -13.40 | 227.23 | -5.45 | 161.11 | 0.2896 | -379.4 | -141.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-20 23:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.37 | 0.00 | 0.70 | -10.05 | 232.21 | -0.47 | 177.81 | 0.2129 | -1051.0 | -781.8 | |
| 0.00 | 2.14 | 0.00 | 1.09 | -10.33 | 232.11 | -0.56 | 177.45 | 0.2176 | -1102.0 | -837.6 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -14.83 | 232.01 | -0.67 | 177.79 | 0.2940 | -963.0 | -875.9 | |
| 0.00 | 0.94 | 0.00 | 0.48 | -10.33 | 231.87 | -0.80 | 176.36 | 0.2179 | -938.0 | -750.6 | |
| 0.00 | 0.77 | 0.00 | 0.40 | -15.08 | 231.67 | -1.01 | 176.72 | 0.2984 | -699.0 | -554.1 | |
| 0.00 | 1.89 | 0.00 | 0.96 | -10.26 | 231.57 | -1.10 | 174.97 | 0.2172 | -764.0 | -684.6 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -15.11 | 231.33 | -1.35 | 175.64 | 0.2993 | -752.0 | -620.2 | |
| 0.00 | 1.63 | 0.00 | 0.88 | -20.50 | 228.40 | -4.27 | 169.73 | 0.3934 | -892.0 | -711.5 | |
| 0.00 | 0.77 | 0.00 | 0.42 | -20.95 | 228.26 | -4.41 | 169.63 | 0.4009 | -566.0 | -453.0 | |
| 0.00 | 0.94 | 0.00 | 0.49 | -13.81 | 228.23 | -4.45 | 164.69 | 0.2867 | 831.0 | 695.6 | |
| 0.00 | 4.72 | 0.00 | 2.44 | -14.03 | 227.85 | -4.82 | 163.70 | 0.2919 | 854.0 | 805.7 | |
| 0.00 | 1.97 | 0.00 | 1.06 | -20.66 | 227.48 | -5.20 | 167.67 | 0.3989 | -622.0 | -596.6 | |
| 0.00 | 6.09 | 0.00 | 3.15 | -14.00 | 227.52 | -5.16 | 162.60 | 0.2930 | 638.0 | 653.3 | |
| 0.00 | 2.32 | 0.00 | 1.20 | -13.54 | 227.53 | -5.15 | 162.13 | 0.2856 | 1005.0 | 753.3 | |
| 0.00 | 1.37 | 0.00 | 0.72 | -16.76 | 226.98 | -5.70 | 163.67 | 0.3395 | -904.0 | -726.1 | |
| 0.00 | 1.37 | 0.00 | 0.70 | -11.39 | 227.12 | -5.56 | 157.95 | 0.2541 | 1029.0 | 819.4 | |
| 0.00 | 1.63 | 0.00 | 0.84 | -13.14 | 227.02 | -5.66 | 160.01 | 0.2821 | 896.0 | 775.6 | |
| 0.00 | 2.14 | 0.00 | 1.10 | -12.43 | 226.82 | -5.85 | 158.43 | 0.2722 | 997.0 | 830.4 | |
| 0.00 | 1.12 | 0.00 | 0.58 | -12.87 | 225.47 | -7.21 | 154.73 | 0.2879 | -852.0 | -680.9 | |
| 0.00 | 1.37 | 0.00 | 0.71 | -10.83 | 223.45 | -9.22 | 144.96 | 0.2755 | -670.0 | -661.4 | |
| 0.00 | 1.46 | 0.00 | 0.76 | -12.35 | 223.37 | -9.31 | 147.75 | 0.2974 | -851.0 | -672.1 | |
| 0.00 | 2.66 | 0.00 | 1.37 | -10.74 | 223.24 | -9.44 | 144.16 | 0.2763 | -1103.0 | -919.9 | |
| 0.00 | 3.95 | 0.00 | 2.04 | -11.35 | 223.19 | -9.49 | 145.29 | 0.2851 | -1064.0 | -893.2 | |
| 0.00 | 1.29 | 0.00 | 0.67 | -11.56 | 222.78 | -9.89 | 144.61 | 0.2919 | -970.0 | -788.1 | |
| 0.00 | 0.94 | 0.00 | 0.49 | -11.78 | 222.04 | -10.64 | 143.08 | 0.3022 | -971.0 | -855.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
