SDO HMI 2014-11-21 14:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.60 | 42.09 | 0.31 | 21.58 | -12.43 | 225.38 | 0.91 | 183.29 | 0.2568 | -186.3 | -215.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-21 14:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.29 | 0.00 | 0.66 | -10.26 | 232.09 | 7.62 | 211.43 | 0.2514 | -802.0 | -658.7 | |
| 0.00 | 0.86 | 0.00 | 0.45 | -15.19 | 231.31 | 6.84 | 201.17 | 0.3197 | -795.0 | -675.3 | |
| 0.00 | 0.94 | 0.00 | 0.48 | -9.84 | 231.17 | 6.70 | 209.14 | 0.2373 | -953.0 | -836.2 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -13.27 | 228.83 | 4.37 | 195.65 | 0.2761 | 714.0 | 551.2 | |
| 0.00 | 3.77 | 0.00 | 1.94 | -13.02 | 228.71 | 4.24 | 195.47 | 0.2715 | 716.0 | 563.7 | |
| 0.00 | 1.11 | 0.00 | 0.57 | -12.01 | 228.30 | 3.83 | 195.03 | 0.2532 | 926.0 | 809.2 | |
| 0.00 | 1.46 | 0.00 | 0.75 | -13.14 | 227.49 | 3.03 | 191.08 | 0.2688 | 913.0 | 643.1 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -12.53 | 227.42 | 2.96 | 191.30 | 0.2584 | 671.0 | 712.0 | |
| 0.00 | 0.77 | 0.00 | 0.40 | -12.56 | 227.15 | 2.69 | 190.26 | 0.2580 | 1078.0 | 860.1 | |
| 0.00 | 3.94 | 0.00 | 2.03 | -13.29 | 227.13 | 2.66 | 189.68 | 0.2702 | 1046.0 | 902.5 | |
| 0.00 | 1.89 | 0.00 | 0.96 | -12.13 | 226.88 | 2.41 | 189.51 | 0.2500 | 1004.0 | 757.9 | |
| 0.00 | 1.11 | 0.00 | 0.58 | -15.26 | 223.80 | -0.66 | 177.86 | 0.2997 | -931.0 | -733.2 | |
| 0.00 | 1.37 | 0.00 | 0.70 | -11.42 | 223.31 | -1.16 | 175.14 | 0.2354 | -919.0 | -813.9 | |
| 0.00 | 1.63 | 0.00 | 0.83 | -10.69 | 223.28 | -1.19 | 174.74 | 0.2231 | -1074.0 | -911.1 | |
| 0.60 | 12.00 | 0.31 | 6.14 | -12.46 | 223.24 | -1.23 | 175.24 | 0.2531 | -881.9 | -766.2 | |
| 0.00 | 1.71 | 0.00 | 0.88 | -12.03 | 223.06 | -1.41 | 174.38 | 0.2462 | -1128.0 | -937.3 | |
| 0.00 | 1.89 | 0.00 | 0.96 | -11.48 | 223.06 | -1.40 | 174.16 | 0.2369 | -968.0 | -720.0 | |
| 0.00 | 0.86 | 0.00 | 0.44 | -14.24 | 222.37 | -2.09 | 172.82 | 0.2846 | -929.0 | -636.7 | |
| 0.00 | 1.20 | 0.00 | 0.61 | -11.60 | 222.40 | -2.07 | 171.50 | 0.2403 | -626.0 | -605.4 | |
| 0.00 | 2.23 | 0.00 | 1.14 | -11.75 | 222.28 | -2.19 | 171.11 | 0.2432 | -571.0 | -589.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
