SDO HMI 2014-11-21 14:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 135.40 | 990.22 | 143.34 | 1049.82 | -13.38 | 163.86 | -60.60 | 106.37 | 0.8843 | 144.8 | -154.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-21 14:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.80 | 0.00 | 1.52 | -16.87 | 173.03 | -51.43 | 112.62 | 0.8128 | 121.0 | 216.9 | |
| 0.00 | 0.69 | 0.00 | 0.58 | -16.38 | 172.67 | -51.80 | 111.92 | 0.8149 | 482.0 | 484.6 | |
| 0.00 | 1.37 | 0.00 | 1.20 | -17.94 | 171.89 | -52.58 | 113.52 | 0.8262 | 476.0 | 370.9 | |
| 0.00 | 0.51 | 0.00 | 0.45 | -17.69 | 171.89 | -52.57 | 113.23 | 0.8255 | 560.0 | 513.5 | |
| 0.00 | 0.69 | 0.00 | 0.59 | -16.24 | 172.37 | -52.09 | 111.66 | 0.8173 | 484.0 | 425.6 | |
| 0.00 | 1.29 | 0.00 | 1.06 | -13.24 | 173.28 | -51.19 | 108.32 | 0.8012 | 291.0 | 327.2 | |
| 0.00 | 1.71 | 0.00 | 1.52 | -18.27 | 171.33 | -53.14 | 113.73 | 0.8321 | 502.0 | 407.2 | |
| 84.55 | 960.29 | 83.57 | 1017.08 | -13.00 | 166.02 | -58.44 | 106.34 | 0.8672 | 687.5 | -155.4 | |
| 0.26 | -8.00 | 0.26 | -8.00 | -13.46 | 165.01 | -59.46 | 106.66 | 0.8763 | 131.7 | 999999 | |
| 0.00 | 0.77 | 0.00 | 0.85 | -14.96 | 162.69 | -61.77 | 107.87 | 0.8963 | -286.0 | -284.2 | |
| 2.40 | -8.00 | 2.62 | -8.00 | -11.89 | 162.58 | -61.88 | 104.47 | 0.8932 | -830.2 | 999999 | |
| 11.66 | -8.00 | 13.42 | -8.00 | -14.07 | 161.40 | -63.06 | 106.67 | 0.9045 | -694.7 | 999999 | |
| 4.54 | -8.00 | 5.23 | -8.00 | -13.34 | 161.28 | -63.18 | 105.85 | 0.9045 | -838.4 | 999999 | |
| 1.46 | -8.00 | 1.64 | -8.00 | -12.17 | 161.68 | -62.79 | 104.63 | 0.9003 | -717.9 | 999999 | |
| 0.00 | 0.26 | 0.00 | 0.30 | -13.66 | 160.92 | -63.54 | 106.14 | 0.9074 | -479.0 | -476.0 | |
| 10.29 | -8.00 | 12.42 | -8.00 | -14.76 | 160.20 | -64.26 | 107.21 | 0.9137 | -414.8 | 999999 | |
| 4.89 | -8.00 | 5.83 | -8.00 | -14.11 | 160.42 | -64.05 | 106.54 | 0.9115 | -621.6 | 999999 | |
| 6.00 | -8.00 | 6.97 | -8.00 | -13.01 | 160.96 | -63.51 | 105.44 | 0.9065 | -748.7 | 999999 | |
| 0.00 | 2.57 | 0.00 | 2.91 | -11.77 | 161.51 | -62.96 | 104.17 | 0.9011 | -504.0 | -410.3 | |
| 0.00 | 1.63 | 0.00 | 1.86 | -11.96 | 161.29 | -63.17 | 104.34 | 0.9029 | -414.0 | -382.6 | |
| 5.49 | -8.00 | 6.65 | -8.00 | -14.27 | 160.04 | -64.42 | 106.66 | 0.9142 | -305.4 | 999999 | |
| 1.63 | 5.49 | 1.93 | 6.50 | -13.31 | 160.47 | -63.99 | 105.68 | 0.9102 | -507.7 | -478.5 | |
| 0.00 | 1.97 | 0.00 | 2.41 | -13.94 | 159.79 | -64.68 | 106.26 | 0.9156 | -293.0 | -233.7 | |
| 0.00 | 3.52 | 0.00 | 4.17 | -12.64 | 160.30 | -64.16 | 104.93 | 0.9107 | 150.0 | 129.6 | |
| 0.00 | 2.66 | 0.00 | 3.09 | -11.47 | 160.75 | -63.71 | 103.71 | 0.9063 | -518.0 | -416.7 | |
| 2.23 | -8.00 | 2.80 | -8.00 | -14.43 | 159.08 | -65.38 | 106.67 | 0.9208 | -128.1 | 999999 | |
| 0.00 | 1.03 | 0.00 | 1.30 | -14.04 | 158.78 | -65.68 | 106.21 | 0.9223 | -201.0 | -135.8 | |
| 0.00 | 1.97 | 0.00 | 2.43 | -12.82 | 159.43 | -65.04 | 104.99 | 0.9169 | -347.0 | -316.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
