SDO HMI 2014-11-23 03:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 228.30 | 1370.34 | 154.45 | 926.24 | -13.39 | 163.71 | -40.41 | 112.14 | 0.6824 | 191.6 | -48.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-23 03:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.03 | 0.00 | 0.56 | -7.51 | 180.25 | -23.86 | 111.84 | 0.4339 | 830.0 | 702.8 | |
| 0.00 | 2.66 | 0.00 | 1.48 | -6.94 | 178.21 | -25.90 | 109.12 | 0.4609 | 390.0 | 373.4 | |
| 0.00 | 1.11 | 0.00 | 0.68 | -20.57 | 175.53 | -28.59 | 130.18 | 0.5887 | 666.0 | 506.1 | |
| 0.00 | 0.77 | 0.00 | 0.47 | -17.16 | 173.20 | -30.91 | 123.26 | 0.5893 | 714.0 | 584.9 | |
| 0.00 | 1.11 | 0.00 | 0.68 | -16.10 | 173.22 | -30.90 | 121.67 | 0.5820 | 586.0 | 464.5 | |
| 0.00 | 1.20 | 0.00 | 0.74 | -17.33 | 172.37 | -31.74 | 122.87 | 0.6003 | 934.0 | 742.6 | |
| 0.00 | 2.06 | 0.00 | 1.29 | -19.07 | 171.90 | -32.22 | 125.01 | 0.6175 | 599.0 | 535.5 | |
| 0.00 | 1.46 | 0.00 | 0.86 | -9.88 | 173.20 | -30.91 | 111.50 | 0.5462 | 716.0 | 567.1 | |
| 0.00 | 0.86 | 0.00 | 0.51 | -9.66 | 173.22 | -30.89 | 111.15 | 0.5448 | 680.0 | 521.9 | |
| 0.00 | 2.23 | 0.00 | 1.39 | -17.84 | 171.83 | -32.29 | 123.21 | 0.6100 | 663.0 | 424.6 | |
| 0.00 | 1.37 | 0.00 | 0.86 | -17.53 | 171.71 | -32.41 | 122.66 | 0.6094 | 456.0 | 389.1 | |
| 0.00 | 1.80 | 0.00 | 1.13 | -17.78 | 171.47 | -32.65 | 122.86 | 0.6138 | 728.0 | 553.6 | |
| 0.00 | 1.97 | 0.00 | 1.24 | -17.73 | 170.89 | -33.23 | 122.36 | 0.6202 | 583.0 | 464.5 | |
| 0.00 | 1.11 | 0.00 | 0.71 | -19.38 | 170.33 | -33.79 | 124.28 | 0.6372 | 687.0 | 516.0 | |
| 0.00 | 1.46 | 0.00 | 0.93 | -19.19 | 170.37 | -33.74 | 124.05 | 0.6355 | 555.0 | 464.8 | |
| 0.00 | 1.20 | 0.00 | 0.76 | -18.25 | 170.29 | -33.83 | 122.67 | 0.6304 | 434.0 | 403.0 | |
| 0.00 | 1.20 | 0.00 | 0.73 | -9.17 | 170.43 | -33.69 | 108.80 | 0.5806 | 762.0 | 596.6 | |
| 0.00 | 1.54 | 0.00 | 0.98 | -15.03 | 168.66 | -35.45 | 116.98 | 0.6309 | 551.0 | 428.0 | |
| 0.00 | 1.03 | 0.00 | 0.69 | -19.64 | 167.17 | -36.94 | 122.51 | 0.6736 | 531.0 | 388.5 | |
| 0.00 | 0.77 | 0.00 | 0.49 | -11.43 | 167.82 | -36.30 | 111.12 | 0.6243 | 768.0 | 619.2 | |
| 0.00 | 1.46 | 0.00 | 0.92 | -10.42 | 167.92 | -36.19 | 109.63 | 0.6189 | 619.0 | 528.4 | |
| 14.15 | 818.97 | 9.12 | 539.87 | -12.55 | 166.76 | -37.35 | 112.29 | 0.6424 | 1250.1 | 183.2 | |
| 0.00 | 1.03 | 0.00 | 0.68 | -15.28 | 165.49 | -38.62 | 115.58 | 0.6700 | -714.0 | -651.9 | |
| 2.40 | -22.00 | 1.56 | -22.00 | -12.44 | 165.98 | -38.14 | 111.76 | 0.6517 | 1299.5 | 999999 | |
| 0.00 | 1.46 | 0.00 | 0.97 | -15.28 | 165.25 | -38.86 | 115.47 | 0.6728 | -491.0 | -461.1 | |
| 101.50 | -22.00 | 66.59 | -22.00 | -13.03 | 165.64 | -38.48 | 112.45 | 0.6583 | 1226.9 | 999999 | |
| 0.00 | 1.20 | 0.00 | 0.80 | -14.88 | 165.26 | -38.85 | 114.91 | 0.6708 | 348.0 | 207.9 | |
| 4.03 | -22.00 | 2.68 | -22.00 | -13.78 | 165.02 | -39.09 | 113.24 | 0.6689 | 626.1 | 999999 | |
| 1.37 | -22.00 | 0.92 | -22.00 | -14.00 | 164.82 | -39.30 | 113.45 | 0.6722 | 134.8 | 999999 | |
| 6.09 | -22.00 | 4.05 | -22.00 | -13.48 | 164.77 | -39.35 | 112.69 | 0.6707 | 690.5 | 999999 | |
| 0.00 | 0.34 | 0.00 | 0.22 | -9.66 | 165.41 | -38.71 | 107.39 | 0.6483 | -368.0 | -406.2 | |
| 4.20 | -22.00 | 2.81 | -22.00 | -13.66 | 164.61 | -39.51 | 112.88 | 0.6733 | 582.1 | 999999 | |
| 0.86 | -22.00 | 0.57 | -22.00 | -13.17 | 164.67 | -39.45 | 112.21 | 0.6706 | 609.6 | 999999 | |
| 0.00 | 0.69 | 0.00 | 0.47 | -15.65 | 164.13 | -39.98 | 115.41 | 0.6874 | 450.0 | 325.9 | |
| 0.77 | -22.00 | 0.52 | -22.00 | -14.17 | 164.03 | -40.09 | 113.32 | 0.6823 | 257.2 | 999999 | |
| 0.00 | 1.03 | 0.00 | 0.68 | -11.19 | 164.59 | -39.52 | 109.33 | 0.6639 | 591.0 | 391.8 | |
| 0.00 | 1.03 | 0.00 | 0.66 | -6.21 | 165.19 | -38.93 | 102.08 | 0.6411 | 534.0 | 432.5 | |
| 0.00 | 1.11 | 0.00 | 0.74 | -10.80 | 164.42 | -39.69 | 108.69 | 0.6647 | 418.0 | 339.4 | |
| 0.00 | 2.31 | 0.00 | 1.59 | -15.48 | 163.48 | -40.63 | 114.87 | 0.6941 | -770.0 | -678.4 | |
| 0.00 | 1.97 | 0.00 | 1.35 | -14.89 | 163.18 | -40.94 | 113.93 | 0.6952 | -690.0 | -653.5 | |
| 6.17 | -22.00 | 4.15 | -22.00 | -12.00 | 163.70 | -40.42 | 110.13 | 0.6778 | -111.8 | 999999 | |
| 0.00 | 1.54 | 0.00 | 1.03 | -10.51 | 163.68 | -40.44 | 107.99 | 0.6729 | -799.0 | -670.6 | |
| 0.00 | 6.52 | 0.00 | 4.49 | -14.53 | 162.85 | -41.26 | 113.29 | 0.6974 | -253.0 | -250.9 | |
| 0.26 | -22.00 | 0.17 | -22.00 | -11.46 | 163.40 | -40.72 | 109.24 | 0.6795 | -1221.0 | 999999 | |
| 0.00 | 1.11 | 0.00 | 0.75 | -10.94 | 163.49 | -40.63 | 108.53 | 0.6766 | -451.0 | -414.5 | |
| 1.03 | -22.00 | 0.69 | -22.00 | -11.28 | 163.35 | -40.77 | 108.96 | 0.6795 | -1016.0 | 999999 | |
| 2.74 | -22.00 | 1.85 | -22.00 | -11.86 | 163.20 | -40.91 | 109.73 | 0.6832 | -758.7 | 999999 | |
| 0.00 | 1.71 | 0.00 | 1.15 | -10.58 | 163.43 | -40.69 | 107.99 | 0.6762 | -616.0 | -569.8 | |
| 4.80 | -22.00 | 3.25 | -22.00 | -11.58 | 163.13 | -40.98 | 109.32 | 0.6831 | -1012.3 | 999999 | |
| 0.00 | 0.51 | 0.00 | 0.35 | -12.26 | 162.89 | -41.23 | 110.17 | 0.6885 | -472.0 | -460.0 | |
| 0.00 | 0.69 | 0.00 | 0.46 | -10.73 | 163.12 | -40.99 | 108.10 | 0.6804 | -752.0 | -559.4 | |
| 0.00 | 0.94 | 0.00 | 0.61 | -0.22 | 163.93 | -40.18 | 92.59 | 0.6482 | 558.0 | 495.5 | |
| 0.00 | 0.86 | 0.00 | 0.58 | -10.80 | 162.79 | -41.33 | 108.08 | 0.6847 | -789.0 | -689.9 | |
| 0.00 | 30.86 | 0.00 | 21.62 | -14.89 | 161.90 | -42.21 | 113.37 | 0.7097 | -129.0 | -169.8 | |
| 1.71 | 427.27 | 1.19 | 302.16 | -13.87 | 162.10 | -42.01 | 112.07 | 0.7035 | -547.7 | -427.6 | |
| 0.00 | 2.57 | 0.00 | 1.75 | -11.05 | 162.67 | -41.45 | 108.38 | 0.6870 | -663.0 | -604.6 | |
| 0.00 | 0.77 | 0.00 | 0.53 | -12.18 | 162.37 | -41.74 | 109.86 | 0.6943 | -405.0 | -307.0 | |
| 0.34 | 1.20 | 0.23 | 0.82 | -11.69 | 162.43 | -41.69 | 109.19 | 0.6920 | -827.8 | -747.0 | |
| 0.00 | 1.80 | 0.00 | 1.23 | -11.45 | 162.47 | -41.64 | 108.87 | 0.6906 | -509.0 | -403.6 | |
| 11.92 | -55.00 | 8.37 | -55.00 | -14.31 | 161.58 | -42.53 | 112.46 | 0.7111 | -850.9 | 999999 | |
| 0.00 | 1.29 | 0.00 | 0.88 | -11.73 | 162.14 | -41.98 | 109.14 | 0.6956 | -718.0 | -585.6 | |
| 0.77 | -55.00 | 0.54 | -55.00 | -13.92 | 161.30 | -42.81 | 111.81 | 0.7129 | -866.7 | 999999 | |
| 0.00 | 1.11 | 0.00 | 0.76 | -10.15 | 162.05 | -42.07 | 106.90 | 0.6916 | -592.0 | -525.3 | |
| 1.20 | -55.00 | 0.84 | -55.00 | -13.70 | 161.31 | -42.81 | 111.52 | 0.7120 | -1127.5 | 999999 | |
| 0.69 | 5.74 | 0.48 | 3.99 | -12.35 | 161.56 | -42.55 | 109.78 | 0.7044 | -885.2 | -773.7 | |
| 0.00 | 0.77 | 0.00 | 0.54 | -13.00 | 161.43 | -42.69 | 110.61 | 0.7082 | -807.0 | -684.6 | |
| 1.71 | -55.00 | 1.21 | -55.00 | -14.14 | 161.08 | -43.03 | 112.02 | 0.7162 | -855.3 | 999999 | |
| 3.77 | -55.00 | 2.67 | -55.00 | -13.81 | 160.91 | -43.21 | 111.50 | 0.7169 | -1001.6 | 999999 | |
| 9.26 | -55.00 | 6.53 | -55.00 | -13.43 | 161.00 | -43.12 | 111.04 | 0.7147 | -994.1 | 999999 | |
| 3.34 | -55.00 | 2.38 | -55.00 | -14.09 | 160.67 | -43.44 | 111.79 | 0.7206 | -920.9 | 999999 | |
| 0.00 | 1.11 | 0.00 | 0.83 | -17.81 | 159.59 | -44.52 | 116.18 | 0.7462 | -585.0 | -549.4 | |
| 0.00 | 1.11 | 0.00 | 0.78 | -12.73 | 160.94 | -43.17 | 110.07 | 0.7129 | -533.0 | -495.4 | |
| 0.00 | 1.03 | 0.00 | 0.73 | -12.98 | 160.85 | -43.27 | 110.37 | 0.7148 | -518.0 | -456.2 | |
| 1.29 | -55.00 | 0.92 | -55.00 | -14.46 | 160.46 | -43.66 | 112.20 | 0.7244 | -768.3 | 999999 | |
| 2.40 | -55.00 | 1.70 | -55.00 | -13.50 | 160.69 | -43.43 | 111.01 | 0.7184 | -856.5 | 999999 | |
| 6.43 | -55.00 | 4.59 | -55.00 | -13.72 | 160.47 | -43.65 | 111.22 | 0.7217 | -983.2 | 999999 | |
| 0.00 | 1.89 | 0.00 | 1.32 | -11.11 | 161.02 | -43.10 | 107.89 | 0.7069 | -671.0 | -445.5 | |
| 13.03 | -55.00 | 9.35 | -55.00 | -14.25 | 160.25 | -43.86 | 111.84 | 0.7259 | -846.1 | 999999 | |
| 0.26 | -55.00 | 0.19 | -55.00 | -14.87 | 160.05 | -44.06 | 112.58 | 0.7303 | -783.3 | 999999 | |
| 1.03 | -55.00 | 0.74 | -55.00 | -13.94 | 160.29 | -43.83 | 111.44 | 0.7244 | -934.6 | 999999 | |
| 0.00 | 0.86 | 0.00 | 0.60 | -10.75 | 160.96 | -43.16 | 107.37 | 0.7064 | -626.0 | -509.6 | |
| 2.74 | -55.00 | 1.98 | -55.00 | -14.50 | 160.06 | -44.05 | 112.10 | 0.7289 | -794.2 | 999999 | |
| 6.52 | -55.00 | 4.72 | -55.00 | -14.78 | 159.90 | -44.21 | 112.40 | 0.7316 | -739.9 | 999999 | |
| 0.26 | -55.00 | 0.18 | -55.00 | -13.85 | 160.14 | -43.98 | 111.27 | 0.7258 | -748.0 | 999999 | |
| 0.00 | 2.06 | 0.00 | 1.47 | -13.39 | 160.08 | -44.04 | 110.64 | 0.7250 | -374.0 | -367.7 | |
| 0.00 | 1.46 | 0.00 | 1.04 | -12.93 | 160.10 | -44.02 | 110.03 | 0.7232 | -625.0 | -510.5 | |
| 7.03 | -55.00 | 5.09 | -55.00 | -14.32 | 159.72 | -44.39 | 111.73 | 0.7321 | -567.3 | 999999 | |
| 1.03 | -55.00 | 0.75 | -55.00 | -14.02 | 159.63 | -44.49 | 111.30 | 0.7321 | -495.7 | 999999 | |
| 1.20 | 3.77 | 0.87 | 2.75 | -14.18 | 159.33 | -44.79 | 111.40 | 0.7359 | -399.1 | -242.5 | |
| 0.00 | 0.94 | 0.00 | 0.69 | -13.78 | 159.30 | -44.82 | 110.86 | 0.7349 | -293.0 | -261.8 | |
| 0.00 | 2.31 | 0.00 | 1.70 | -14.13 | 159.04 | -45.08 | 111.22 | 0.7389 | -396.0 | -286.8 | |
| 0.00 | 0.94 | 0.00 | 0.71 | -16.12 | 158.40 | -45.72 | 113.55 | 0.7526 | -471.0 | -420.4 | |
| 0.00 | 1.29 | 0.00 | 0.97 | -17.03 | 158.07 | -46.05 | 114.57 | 0.7592 | -533.0 | -396.2 | |
| 0.00 | 0.94 | 0.00 | 0.71 | -16.00 | 158.17 | -45.95 | 113.31 | 0.7546 | -318.0 | -280.9 | |
| 0.00 | 0.69 | 0.00 | 0.51 | -13.68 | 158.41 | -45.70 | 110.41 | 0.7444 | -470.0 | -384.9 | |
| 0.00 | 0.69 | 0.00 | 0.51 | -13.48 | 157.58 | -46.54 | 109.88 | 0.7529 | -514.0 | -425.2 | |
| 0.00 | 1.11 | 0.00 | 0.83 | -13.30 | 157.58 | -46.54 | 109.64 | 0.7523 | -512.0 | -381.1 | |
| 0.00 | 0.34 | 0.00 | 0.26 | -14.23 | 157.20 | -46.92 | 110.71 | 0.7592 | -384.0 | -439.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
