SDO HMI 2014-11-24 08:16:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 219.80 | 1195.56 | 207.97 | 1120.70 | -15.47 | 243.89 | 55.83 | 250.32 | 0.8463 | -399.5 | -126.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-24 08:16:56 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.74 | 0.00 | 3.38 | -9.92 | 253.63 | 65.57 | 258.38 | 0.9174 | -433.0 | -271.0 | |
| 3.77 | 5.74 | 6.25 | 9.51 | -19.00 | 258.97 | 70.91 | 249.46 | 0.9555 | 308.4 | 213.9 | |
| 3.68 | 8.83 | 5.21 | 12.45 | -18.18 | 255.81 | 67.75 | 249.84 | 0.9382 | 465.1 | 303.9 | |
| 28.62 | 175.08 | 33.60 | 205.36 | -12.81 | 251.93 | 63.88 | 255.00 | 0.9082 | 880.7 | 216.0 | |
| 0.00 | 0.26 | 0.00 | 0.27 | -8.74 | 249.31 | 61.26 | 259.14 | 0.8843 | -265.0 | -248.7 | |
| 2.49 | 4.20 | 2.71 | 4.57 | -11.81 | 249.96 | 61.90 | 255.80 | 0.8926 | 416.0 | 272.2 | |
| 0.00 | 1.37 | 0.00 | 1.63 | -16.38 | 251.66 | 63.60 | 251.07 | 0.9103 | -215.0 | -143.7 | |
| 0.00 | 5.57 | 0.00 | 7.14 | -20.47 | 252.98 | 64.93 | 246.92 | 0.9241 | -541.0 | -373.5 | |
| 0.00 | 2.57 | 0.00 | 3.20 | -20.35 | 252.22 | 64.16 | 246.90 | 0.9192 | -563.0 | -431.6 | |
| 7.71 | 10.11 | 7.79 | 10.22 | -12.99 | 247.37 | 59.31 | 254.03 | 0.8736 | 541.5 | 343.4 | |
| 0.00 | 0.86 | 0.00 | 0.86 | -16.63 | 246.28 | 58.22 | 249.70 | 0.8705 | -147.0 | -146.4 | |
| 0.00 | 1.20 | 0.00 | 1.19 | -16.56 | 246.07 | 58.01 | 249.73 | 0.8687 | -362.0 | -309.6 | |
| 0.00 | 0.77 | 0.00 | 0.65 | -8.56 | 241.49 | 53.43 | 258.15 | 0.8137 | -373.0 | -334.1 | |
| 12.68 | 957.83 | 11.53 | 845.52 | -15.64 | 242.97 | 54.91 | 250.04 | 0.8405 | -503.6 | -209.7 | |
| 4.11 | -14.00 | 3.80 | -14.00 | -16.67 | 243.40 | 55.34 | 248.95 | 0.8465 | -215.0 | 999999 | |
| 2.06 | -14.00 | 1.88 | -14.00 | -16.47 | 242.93 | 54.88 | 249.06 | 0.8420 | -259.2 | 999999 | |
| 17.91 | -14.00 | 15.95 | -14.00 | -15.19 | 242.26 | 54.20 | 250.39 | 0.8332 | -810.7 | 999999 | |
| 3.26 | -14.00 | 2.92 | -14.00 | -15.68 | 242.40 | 54.34 | 249.84 | 0.8355 | -606.3 | 999999 | |
| 1.71 | -14.00 | 1.55 | -14.00 | -16.31 | 242.49 | 54.43 | 249.14 | 0.8377 | -542.6 | 999999 | |
| 5.74 | -14.00 | 5.11 | -14.00 | -15.77 | 242.11 | 54.06 | 249.67 | 0.8331 | -756.5 | 999999 | |
| 12.43 | -14.00 | 10.79 | -14.00 | -14.24 | 241.45 | 53.39 | 251.30 | 0.8237 | -985.6 | 999999 | |
| 0.26 | -14.00 | 0.23 | -14.00 | -16.43 | 242.27 | 54.22 | 248.94 | 0.8360 | -687.7 | 999999 | |
| 13.88 | -14.00 | 12.03 | -14.00 | -14.57 | 241.26 | 53.20 | 250.85 | 0.8226 | -1045.7 | 999999 | |
| 3.77 | -14.00 | 3.28 | -14.00 | -15.07 | 241.38 | 53.33 | 250.30 | 0.8248 | -827.2 | 999999 | |
| 28.19 | -14.00 | 25.20 | -14.00 | -16.82 | 242.01 | 53.96 | 248.41 | 0.8345 | -743.1 | 999999 | |
| 28.19 | -14.00 | 24.63 | -14.00 | -16.71 | 241.07 | 53.02 | 248.28 | 0.8258 | -994.6 | 999999 | |
| 9.17 | -14.00 | 7.83 | -14.00 | -15.33 | 240.50 | 52.45 | 249.76 | 0.8171 | 457.2 | 999999 | |
| 0.00 | 1.11 | 0.00 | 1.00 | -19.00 | 241.49 | 53.44 | 245.72 | 0.8353 | -85.0 | -87.9 | |
| 23.40 | -14.00 | 19.99 | -14.00 | -16.65 | 240.13 | 52.08 | 248.07 | 0.8169 | -1159.2 | 999999 | |
| 0.00 | 1.20 | 0.00 | 1.00 | -15.51 | 239.42 | 51.36 | 249.22 | 0.8072 | -443.0 | -425.1 | |
| 6.77 | -14.00 | 5.69 | -14.00 | -16.60 | 239.41 | 51.35 | 247.92 | 0.8100 | -1124.9 | 999999 | |
| 0.00 | 1.54 | 0.00 | 1.32 | -21.42 | 238.86 | 50.81 | 242.05 | 0.8190 | 494.0 | 324.4 | |
| 0.00 | 0.86 | 0.00 | 0.77 | -24.63 | 239.96 | 51.90 | 238.78 | 0.8386 | -533.0 | -381.7 | |
| 0.00 | 0.77 | 0.00 | 0.62 | -18.56 | 236.42 | 48.36 | 244.55 | 0.7869 | -431.0 | -425.0 | |
| 0.00 | 1.37 | 0.00 | 1.08 | -17.73 | 235.97 | 47.92 | 245.39 | 0.7798 | -467.0 | -440.1 | |
| 0.00 | 0.94 | 0.00 | 0.75 | -18.27 | 236.17 | 48.11 | 244.81 | 0.7835 | -560.0 | -492.1 | |
| 0.00 | 0.51 | 0.00 | 0.41 | -18.01 | 236.03 | 47.97 | 245.07 | 0.7813 | -447.0 | -470.3 | |
| 0.00 | 0.94 | 0.00 | 0.69 | -12.64 | 233.65 | 45.59 | 251.05 | 0.7393 | -542.0 | -387.3 | |
| 0.00 | 1.80 | 0.00 | 1.31 | -12.75 | 233.41 | 45.36 | 250.82 | 0.7371 | -625.0 | -514.0 | |
| 0.00 | 0.94 | 0.00 | 0.68 | -12.81 | 233.08 | 45.02 | 250.64 | 0.7335 | -618.0 | -535.5 | |
| 0.00 | 1.03 | 0.00 | 0.82 | -20.95 | 235.58 | 47.52 | 241.34 | 0.7873 | -624.0 | -532.4 | |
| 0.00 | 0.86 | 0.00 | 0.71 | -23.20 | 236.60 | 48.54 | 239.10 | 0.8050 | -579.0 | -558.9 | |
| 0.00 | 0.86 | 0.00 | 0.74 | -27.59 | 236.83 | 48.77 | 234.21 | 0.8239 | -543.0 | -434.5 | |
| 0.00 | 1.29 | 0.00 | 1.12 | -27.72 | 236.75 | 48.70 | 234.03 | 0.8239 | -469.0 | -389.7 | |
| 0.00 | 0.86 | 0.00 | 0.62 | -22.41 | 229.29 | 41.24 | 236.58 | 0.7325 | -604.0 | -462.4 | |
| 0.00 | 0.86 | 0.00 | 0.63 | -23.39 | 229.58 | 41.52 | 235.53 | 0.7403 | -376.0 | -348.3 | |
| 0.00 | 0.69 | 0.00 | 0.48 | -27.53 | 223.90 | 35.84 | 227.03 | 0.7120 | -309.0 | -353.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
