SDO HMI 2014-11-24 16:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 171.44 | 982.79 | 179.91 | 1034.75 | -15.34 | 243.74 | 59.91 | 251.40 | 0.8798 | -394.6 | -111.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-24 16:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.23 | 0.00 | 3.34 | -9.96 | 253.86 | 70.04 | 258.82 | 0.9451 | -193.0 | -196.4 | |
| 0.00 | 2.31 | 0.00 | 5.01 | -19.05 | 259.20 | 75.38 | 249.98 | 0.9745 | 373.0 | 242.3 | |
| 0.94 | 3.08 | 1.68 | 5.49 | -18.30 | 256.24 | 72.42 | 250.40 | 0.9620 | 349.8 | 292.0 | |
| 24.23 | 145.14 | 33.62 | 201.18 | -12.85 | 251.88 | 68.06 | 255.54 | 0.9355 | 730.0 | 177.5 | |
| 1.11 | 2.65 | 1.42 | 3.38 | -11.64 | 250.00 | 66.17 | 256.60 | 0.9227 | 242.4 | 155.1 | |
| 0.69 | 1.80 | 0.95 | 2.50 | -16.68 | 251.43 | 67.60 | 251.41 | 0.9360 | -217.0 | -118.8 | |
| 0.00 | 1.71 | 0.00 | 2.62 | -20.53 | 252.92 | 69.10 | 247.60 | 0.9477 | -388.0 | -320.6 | |
| 4.97 | 8.13 | 5.80 | 9.50 | -12.91 | 247.55 | 63.73 | 254.88 | 0.9072 | 473.4 | 251.6 | |
| 0.00 | 4.54 | 0.00 | 4.46 | -13.34 | 242.16 | 58.33 | 253.47 | 0.8659 | -11.0 | -67.8 | |
| 0.00 | 1.03 | 0.00 | 0.92 | -4.24 | 239.86 | 56.04 | 263.75 | 0.8342 | -342.0 | -289.8 | |
| 9.85 | 786.94 | 10.04 | 775.31 | -15.70 | 242.93 | 59.11 | 250.95 | 0.8760 | -394.9 | -191.9 | |
| 0.00 | 0.43 | 0.00 | 0.42 | -13.64 | 242.04 | 58.22 | 253.10 | 0.8654 | -361.0 | -307.2 | |
| 0.00 | 0.26 | 0.00 | 0.25 | -13.54 | 241.89 | 58.07 | 253.18 | 0.8640 | -461.0 | -451.0 | |
| 0.00 | 0.60 | 0.00 | 0.58 | -13.04 | 241.47 | 57.65 | 253.67 | 0.8597 | -378.0 | -428.1 | |
| 15.67 | -11.00 | 15.62 | -11.00 | -15.25 | 242.24 | 58.42 | 251.32 | 0.8697 | -734.8 | 999999 | |
| 0.00 | 1.54 | 0.00 | 1.37 | -6.17 | 239.58 | 55.76 | 261.41 | 0.8334 | -389.0 | -329.2 | |
| 2.40 | -11.00 | 2.40 | -11.00 | -15.74 | 242.35 | 58.53 | 250.78 | 0.8714 | -588.5 | 999999 | |
| 0.86 | -11.00 | 0.87 | -11.00 | -16.43 | 242.56 | 58.74 | 250.05 | 0.8742 | -400.3 | 999999 | |
| 2.06 | -11.00 | 2.05 | -11.00 | -15.52 | 242.13 | 58.31 | 250.98 | 0.8692 | -604.2 | 999999 | |
| 1.97 | -11.00 | 1.97 | -11.00 | -16.02 | 242.30 | 58.48 | 250.45 | 0.8715 | -671.2 | 999999 | |
| 11.30 | -11.00 | 10.96 | -11.00 | -14.36 | 241.46 | 57.64 | 252.16 | 0.8617 | -883.4 | 999999 | |
| 1.71 | -11.00 | 1.70 | -11.00 | -15.80 | 242.08 | 58.26 | 250.66 | 0.8693 | -738.7 | 999999 | |
| 2.83 | -11.00 | 2.83 | -11.00 | -16.52 | 242.30 | 58.48 | 249.90 | 0.8723 | -609.1 | 999999 | |
| 2.31 | -11.00 | 2.28 | -11.00 | -15.39 | 241.72 | 57.90 | 251.04 | 0.8656 | -775.8 | 999999 | |
| 0.00 | 1.20 | 0.00 | 1.12 | -12.16 | 240.49 | 56.66 | 254.49 | 0.8497 | -13.0 | -62.7 | |
| 2.31 | -11.00 | 2.25 | -11.00 | -15.04 | 241.40 | 57.57 | 251.37 | 0.8623 | -770.1 | 999999 | |
| 9.50 | -11.00 | 9.16 | -11.00 | -14.60 | 241.16 | 57.33 | 251.82 | 0.8595 | -1044.6 | 999999 | |
| 0.00 | 1.46 | 0.00 | 1.35 | -12.25 | 240.29 | 56.47 | 254.35 | 0.8481 | 308.0 | 275.7 | |
| 24.23 | -11.00 | 24.20 | -11.00 | -16.88 | 242.01 | 58.18 | 249.42 | 0.8706 | -656.0 | 999999 | |
| 0.43 | 1.63 | 0.40 | 1.50 | -12.58 | 240.07 | 56.25 | 253.92 | 0.8467 | 264.4 | 249.5 | |
| 0.00 | 1.54 | 0.00 | 1.58 | -18.33 | 242.46 | 58.64 | 247.90 | 0.8768 | 235.0 | 191.8 | |
| 7.71 | -11.00 | 7.32 | -11.00 | -15.38 | 240.46 | 56.64 | 250.76 | 0.8550 | 216.1 | 999999 | |
| 20.55 | -11.00 | 19.96 | -11.00 | -16.70 | 240.99 | 57.16 | 249.39 | 0.8619 | -963.6 | 999999 | |
| 0.00 | 1.20 | 0.00 | 1.21 | -18.60 | 241.89 | 58.06 | 247.46 | 0.8728 | -181.0 | -97.6 | |
| 19.61 | -11.00 | 18.54 | -11.00 | -16.70 | 240.03 | 56.20 | 249.15 | 0.8538 | -1082.5 | 999999 | |
| 0.00 | 0.43 | 0.00 | 0.41 | -18.15 | 240.49 | 56.67 | 247.61 | 0.8607 | -186.0 | -203.0 | |
| 4.20 | -11.00 | 3.89 | -11.00 | -16.62 | 239.27 | 55.45 | 249.05 | 0.8472 | -1082.6 | 999999 | |
| 0.00 | 0.86 | 0.00 | 0.77 | -17.76 | 237.61 | 53.79 | 247.28 | 0.8352 | -587.0 | -413.7 | |
| 0.00 | 1.28 | 0.00 | 1.01 | -7.11 | 234.09 | 50.27 | 259.41 | 0.7787 | -91.0 | -100.4 | |
| 0.00 | 0.94 | 0.00 | 0.83 | -18.66 | 236.90 | 53.08 | 246.03 | 0.8312 | 82.0 | 109.7 | |
| 0.00 | 1.46 | 0.00 | 1.25 | -18.00 | 235.90 | 52.07 | 246.49 | 0.8203 | -115.0 | -176.7 | |
| 0.00 | 0.86 | 0.00 | 0.74 | -18.53 | 235.71 | 51.89 | 245.81 | 0.8201 | -371.0 | -345.3 | |
| 0.00 | 1.46 | 0.00 | 1.15 | -12.78 | 233.44 | 49.62 | 252.10 | 0.7830 | -675.0 | -608.1 | |
| 0.00 | 1.54 | 0.00 | 1.46 | -23.68 | 238.00 | 54.17 | 240.65 | 0.8539 | -445.0 | -265.2 | |
| 0.00 | 1.28 | 0.00 | 1.13 | -20.91 | 235.94 | 52.12 | 243.10 | 0.8289 | -529.0 | -509.5 | |
| 0.00 | 0.69 | 0.00 | 0.60 | -20.72 | 235.84 | 52.02 | 243.30 | 0.8275 | -559.0 | -486.5 | |
| 0.00 | 1.03 | 0.00 | 0.94 | -23.48 | 236.57 | 52.74 | 240.39 | 0.8418 | -620.0 | -534.8 | |
| 0.00 | 0.94 | 0.00 | 0.90 | -27.53 | 236.72 | 52.90 | 235.95 | 0.8557 | -151.0 | -212.8 | |
| 0.00 | 0.60 | 0.00 | 0.47 | -22.62 | 229.51 | 45.68 | 238.56 | 0.7764 | -684.0 | -623.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
