SDO HMI 2014-11-25 21:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 134.88 | 911.58 | 69.17 | 468.29 | -13.27 | 165.00 | -2.88 | 169.54 | 0.2646 | 460.1 | 317.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-25 21:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.77 | 0.00 | 0.39 | -5.68 | 177.90 | 10.02 | 234.03 | 0.2150 | 766.0 | 618.0 | |
| 0.00 | 1.80 | 0.00 | 0.92 | -10.40 | 174.91 | 7.04 | 210.18 | 0.2408 | 963.0 | 818.9 | |
| 0.00 | 0.86 | 0.00 | 0.47 | -22.30 | 175.28 | 7.40 | 196.42 | 0.4235 | 717.0 | 483.9 | |
| 0.00 | 0.94 | 0.00 | 0.50 | -17.94 | 174.74 | 6.86 | 198.80 | 0.3541 | 662.0 | 528.7 | |
| 0.00 | 1.11 | 0.00 | 0.58 | -15.81 | 173.43 | 5.55 | 197.30 | 0.3141 | 685.0 | 582.8 | |
| 0.00 | 1.54 | 0.00 | 0.80 | -15.65 | 173.27 | 5.39 | 196.99 | 0.3109 | 847.0 | 735.3 | |
| 0.00 | 2.14 | 0.00 | 1.08 | -8.55 | 173.13 | 5.26 | 207.27 | 0.1986 | 894.0 | 780.0 | |
| 0.00 | 1.46 | 0.00 | 0.73 | -7.44 | 172.79 | 4.91 | 208.47 | 0.1789 | 901.0 | 664.1 | |
| 0.00 | 1.80 | 0.00 | 0.96 | -19.98 | 172.86 | 4.98 | 192.52 | 0.3778 | 789.0 | 663.5 | |
| 0.00 | 0.86 | 0.00 | 0.45 | -17.08 | 172.78 | 4.90 | 194.32 | 0.3315 | 798.0 | 634.8 | |
| 0.00 | 1.63 | 0.00 | 0.86 | -18.05 | 172.77 | 4.89 | 193.58 | 0.3469 | 633.0 | 499.7 | |
| 0.00 | 0.68 | 0.00 | 0.35 | -12.55 | 172.53 | 4.65 | 197.98 | 0.2575 | 763.0 | 612.9 | |
| 0.00 | 1.46 | 0.00 | 0.77 | -17.77 | 172.61 | 4.73 | 193.34 | 0.3418 | 908.0 | 669.5 | |
| 0.00 | 1.54 | 0.00 | 0.79 | -13.77 | 172.49 | 4.61 | 196.45 | 0.2770 | 952.0 | 751.7 | |
| 0.00 | 1.11 | 0.00 | 0.56 | -7.23 | 172.40 | 4.52 | 207.08 | 0.1726 | 899.0 | 725.8 | |
| 0.00 | 3.00 | 0.00 | 1.60 | -20.27 | 172.61 | 4.74 | 191.76 | 0.3815 | 778.0 | 690.5 | |
| 0.00 | 1.28 | 0.00 | 0.68 | -17.67 | 172.39 | 4.51 | 192.81 | 0.3394 | 797.0 | 719.3 | |
| 0.00 | 1.63 | 0.00 | 0.83 | -11.36 | 171.66 | 3.78 | 196.14 | 0.2339 | 1015.0 | 764.6 | |
| 0.00 | 1.11 | 0.00 | 0.58 | -17.02 | 171.63 | 3.75 | 191.10 | 0.3262 | 883.0 | 686.2 | |
| 0.00 | 0.77 | 0.00 | 0.39 | -7.86 | 170.91 | 3.03 | 197.74 | 0.1727 | 876.0 | 712.4 | |
| 0.00 | 0.94 | 0.00 | 0.48 | -10.93 | 170.75 | 2.87 | 192.82 | 0.2230 | 665.0 | 530.7 | |
| 0.00 | 0.77 | 0.00 | 0.39 | -6.90 | 170.04 | 2.16 | 194.27 | 0.1526 | 764.0 | 632.8 | |
| 0.00 | 1.28 | 0.00 | 0.66 | -13.30 | 167.89 | 0.01 | 180.03 | 0.2578 | 770.0 | 651.7 | |
| 0.00 | 1.97 | 0.00 | 1.00 | -10.23 | 167.38 | -0.50 | 177.60 | 0.2056 | 778.0 | 792.2 | |
| 0.00 | 1.11 | 0.00 | 0.58 | -14.99 | 166.90 | -0.97 | 176.71 | 0.2868 | -618.0 | -445.9 | |
| 7.87 | 182.99 | 4.01 | 93.25 | -11.86 | 166.89 | -0.99 | 175.85 | 0.2340 | 1380.4 | 531.7 | |
| 13.61 | -26.00 | 6.94 | -26.00 | -12.05 | 166.56 | -1.32 | 174.53 | 0.2376 | 1348.3 | 999999 | |
| 0.00 | 1.11 | 0.00 | 0.57 | -12.66 | 166.52 | -1.35 | 174.64 | 0.2480 | 739.0 | 544.2 | |
| 4.62 | -26.00 | 2.35 | -26.00 | -11.86 | 166.23 | -1.65 | 173.08 | 0.2351 | 1210.2 | 999999 | |
| 10.44 | -26.00 | 5.33 | -26.00 | -12.29 | 166.07 | -1.81 | 172.67 | 0.2426 | 1193.2 | 999999 | |
| 0.00 | 1.11 | 0.00 | 0.58 | -15.54 | 165.77 | -2.11 | 173.12 | 0.2977 | 772.0 | 527.9 | |
| 0.00 | 1.46 | 0.00 | 0.76 | -16.79 | 165.66 | -2.22 | 173.28 | 0.3185 | -796.0 | -666.1 | |
| 13.27 | 531.69 | 6.79 | 273.13 | -12.99 | 165.49 | -2.39 | 170.82 | 0.2558 | 1587.3 | 476.8 | |
| 2.31 | -33.00 | 1.18 | -33.00 | -12.66 | 165.43 | -2.45 | 170.38 | 0.2504 | 1270.8 | 999999 | |
| 0.00 | 1.20 | 0.00 | 0.61 | -11.95 | 165.29 | -2.59 | 169.29 | 0.2391 | 781.0 | 628.1 | |
| 66.16 | -33.00 | 33.98 | -33.00 | -13.54 | 165.15 | -2.73 | 169.93 | 0.2660 | 1605.5 | 999999 | |
| 0.00 | 0.77 | 0.00 | 0.39 | -11.38 | 164.87 | -3.01 | 167.07 | 0.2309 | 927.0 | 794.2 | |
| 3.08 | -33.00 | 1.59 | -33.00 | -14.25 | 164.77 | -3.11 | 169.09 | 0.2788 | 907.0 | 999999 | |
| 0.26 | -33.00 | 0.13 | -33.00 | -13.97 | 164.62 | -3.26 | 168.38 | 0.2748 | 1138.3 | 999999 | |
| 0.00 | 1.11 | 0.00 | 0.56 | -10.59 | 164.64 | -3.24 | 165.23 | 0.2188 | 815.0 | 573.1 | |
| 1.80 | -33.00 | 0.93 | -33.00 | -13.79 | 164.05 | -3.83 | 166.23 | 0.2739 | 855.8 | 999999 | |
| 0.00 | 6.85 | 0.00 | 3.50 | -11.96 | 164.08 | -3.80 | 164.50 | 0.2438 | 29.0 | 15.6 | |
| 1.20 | 15.92 | 0.61 | 8.10 | -10.92 | 163.58 | -4.30 | 161.20 | 0.2295 | -1081.8 | -401.7 | |
| 0.00 | 1.54 | 0.00 | 0.78 | -10.17 | 163.44 | -4.44 | 159.46 | 0.2181 | -750.0 | -602.2 | |
| 0.00 | 1.20 | 0.00 | 0.61 | -10.32 | 163.23 | -4.65 | 158.82 | 0.2219 | -777.0 | -586.6 | |
| 0.00 | 1.63 | 0.00 | 0.83 | -10.95 | 163.19 | -4.69 | 159.67 | 0.2322 | -939.0 | -789.1 | |
| 0.00 | 7.10 | 0.00 | 3.69 | -15.24 | 163.04 | -4.84 | 164.26 | 0.3017 | 59.0 | 120.9 | |
| 0.00 | 14.64 | 0.00 | 7.55 | -13.94 | 163.00 | -4.87 | 162.86 | 0.2811 | 381.0 | 316.0 | |
| 0.00 | 1.28 | 0.00 | 0.67 | -15.70 | 162.81 | -5.07 | 164.00 | 0.3101 | -545.0 | -479.5 | |
| 0.00 | 1.80 | 0.00 | 0.94 | -15.58 | 162.72 | -5.16 | 163.62 | 0.3086 | -786.0 | -707.3 | |
| 0.00 | 1.03 | 0.00 | 0.54 | -15.79 | 162.65 | -5.23 | 163.63 | 0.3123 | -816.0 | -691.9 | |
| 0.00 | 11.73 | 0.00 | 6.06 | -14.00 | 162.64 | -5.24 | 161.72 | 0.2839 | -61.0 | -232.5 | |
| 0.00 | 1.46 | 0.00 | 0.75 | -12.66 | 162.64 | -5.24 | 160.06 | 0.2625 | -680.0 | -408.7 | |
| 0.00 | 1.63 | 0.00 | 0.84 | -13.51 | 162.59 | -5.29 | 160.98 | 0.2764 | 432.0 | 391.9 | |
| 0.00 | 1.28 | 0.00 | 0.66 | -11.59 | 162.60 | -5.28 | 158.39 | 0.2459 | -748.0 | -549.6 | |
| 0.00 | 1.46 | 0.00 | 0.74 | -11.93 | 162.44 | -5.44 | 158.32 | 0.2522 | -791.0 | -545.1 | |
| 0.00 | 0.60 | 0.00 | 0.31 | -14.01 | 162.27 | -5.61 | 160.54 | 0.2859 | -541.0 | -565.6 | |
| 0.60 | 2.23 | 0.31 | 1.15 | -14.22 | 161.68 | -6.20 | 158.95 | 0.2927 | -966.0 | -708.0 | |
| 0.00 | 2.40 | 0.00 | 1.25 | -15.73 | 161.45 | -6.43 | 160.07 | 0.3176 | -857.0 | -661.8 | |
| 0.00 | 2.74 | 0.00 | 1.42 | -14.25 | 161.22 | -6.66 | 157.58 | 0.2961 | -881.0 | -739.2 | |
| 0.51 | 4.45 | 0.27 | 2.31 | -14.04 | 161.04 | -6.84 | 156.75 | 0.2940 | -1113.7 | -804.0 | |
| 0.68 | 11.64 | 0.35 | 6.02 | -13.46 | 160.97 | -6.91 | 155.69 | 0.2856 | -1089.4 | -807.5 | |
| 0.00 | 0.86 | 0.00 | 0.45 | -16.54 | 160.83 | -7.05 | 159.26 | 0.3337 | -888.0 | -746.0 | |
| 0.00 | 1.03 | 0.00 | 0.54 | -18.11 | 160.74 | -7.14 | 160.65 | 0.3582 | -787.0 | -648.4 | |
| 4.62 | -62.00 | 2.39 | -62.00 | -13.67 | 160.81 | -7.07 | 155.52 | 0.2899 | -1102.3 | 999999 | |
| 0.00 | 2.05 | 0.00 | 1.08 | -17.07 | 160.44 | -7.44 | 158.81 | 0.3442 | -839.0 | -686.4 | |
| 0.00 | 1.28 | 0.00 | 0.66 | -13.12 | 160.55 | -7.33 | 153.88 | 0.2835 | -920.0 | -766.1 | |
| 1.11 | 4.62 | 0.59 | 2.43 | -16.89 | 160.32 | -7.56 | 158.30 | 0.3420 | -1011.9 | -857.8 | |
| 0.00 | 2.05 | 0.00 | 1.07 | -14.78 | 160.28 | -7.60 | 155.54 | 0.3104 | -882.0 | -734.6 | |
| 1.63 | 3.08 | 0.84 | 1.60 | -13.70 | 160.22 | -7.66 | 153.81 | 0.2946 | -1189.6 | -946.4 | |
| 0.00 | 2.05 | 0.00 | 1.07 | -13.95 | 160.21 | -7.66 | 154.16 | 0.2983 | -590.0 | -592.9 | |
| 0.00 | 1.63 | 0.00 | 0.86 | -16.98 | 160.06 | -7.81 | 157.76 | 0.3450 | -757.0 | -671.7 | |
| 0.00 | 2.31 | 0.00 | 1.19 | -11.93 | 160.25 | -7.63 | 150.88 | 0.2682 | -998.0 | -810.9 | |
| 0.51 | 2.91 | 0.27 | 1.51 | -14.44 | 160.13 | -7.74 | 154.66 | 0.3063 | -967.7 | -764.6 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -14.26 | 159.93 | -7.95 | 153.80 | 0.3050 | -756.0 | -670.6 | |
| 0.00 | 6.16 | 0.00 | 3.20 | -13.98 | 159.84 | -8.03 | 153.14 | 0.3016 | -763.0 | -882.0 | |
| 0.60 | 3.08 | 0.31 | 1.61 | -15.12 | 159.74 | -8.14 | 154.53 | 0.3192 | -1030.0 | -847.0 | |
| 0.00 | 1.71 | 0.00 | 0.88 | -12.69 | 159.83 | -8.05 | 150.96 | 0.2828 | -939.0 | -714.8 | |
| 0.00 | 1.20 | 0.00 | 0.62 | -14.69 | 159.76 | -8.12 | 153.96 | 0.3127 | -696.0 | -456.7 | |
| 0.00 | 1.80 | 0.00 | 0.93 | -14.23 | 159.71 | -8.17 | 153.14 | 0.3062 | -895.0 | -790.3 | |
| 0.00 | 1.28 | 0.00 | 0.67 | -15.21 | 159.52 | -8.36 | 154.06 | 0.3222 | -725.0 | -641.7 | |
| 0.00 | 2.31 | 0.00 | 1.18 | -10.99 | 159.64 | -8.24 | 147.06 | 0.2600 | -862.0 | -637.1 | |
| 0.00 | 1.20 | 0.00 | 0.61 | -10.81 | 159.49 | -8.39 | 146.21 | 0.2588 | -709.0 | -472.0 | |
| 0.00 | 1.54 | 0.00 | 0.82 | -16.92 | 158.79 | -9.09 | 154.49 | 0.3526 | -979.0 | -867.0 | |
| 0.00 | 0.86 | 0.00 | 0.45 | -16.61 | 158.80 | -9.08 | 154.13 | 0.3480 | -847.0 | -719.3 | |
| 0.00 | 0.94 | 0.00 | 0.49 | -14.75 | 158.61 | -9.27 | 150.97 | 0.3225 | -888.0 | -689.8 | |
| 0.00 | 1.28 | 0.00 | 0.67 | -14.91 | 158.45 | -9.43 | 150.79 | 0.3260 | -748.0 | -658.3 | |
| 0.00 | 1.03 | 0.00 | 0.55 | -18.05 | 158.13 | -9.75 | 154.36 | 0.3737 | -748.0 | -566.2 | |
| 0.00 | 0.86 | 0.00 | 0.44 | -13.04 | 157.94 | -9.94 | 146.27 | 0.3041 | -923.0 | -774.0 | |
| 0.00 | 1.37 | 0.00 | 0.71 | -13.07 | 157.32 | -10.56 | 144.72 | 0.3104 | -852.0 | -712.2 | |
| 0.00 | 0.77 | 0.00 | 0.40 | -13.25 | 156.94 | -10.94 | 144.13 | 0.3166 | -996.0 | -837.0 | |
| 0.00 | 1.20 | 0.00 | 0.63 | -13.47 | 156.93 | -10.95 | 144.51 | 0.3195 | -753.0 | -612.5 | |
| 0.00 | 1.54 | 0.00 | 0.80 | -12.86 | 156.74 | -11.13 | 142.87 | 0.3133 | -1005.0 | -811.1 | |
| 0.00 | 0.77 | 0.00 | 0.42 | -19.42 | 156.26 | -11.62 | 152.02 | 0.4067 | -762.0 | -562.8 | |
| 0.00 | 3.00 | 0.00 | 1.57 | -13.20 | 156.54 | -11.34 | 143.04 | 0.3197 | -790.0 | -602.9 | |
| 0.00 | 1.11 | 0.00 | 0.58 | -13.41 | 155.72 | -12.15 | 141.55 | 0.3308 | -750.0 | -599.1 | |
| 0.00 | 0.86 | 0.00 | 0.44 | -9.95 | 154.84 | -13.04 | 131.85 | 0.2997 | -845.0 | -667.9 | |
| 0.00 | 1.20 | 0.00 | 0.66 | -20.04 | 152.97 | -14.90 | 146.67 | 0.4416 | -855.0 | -712.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
