SDO HMI 2014-11-26 06:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 131.28 | 890.90 | 67.27 | 457.22 | -13.25 | 165.10 | 2.16 | 188.30 | 0.2615 | 429.6 | 307.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-26 06:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.26 | 0.00 | 0.14 | -9.73 | 180.19 | 17.26 | 236.49 | 0.3522 | 848.0 | 814.0 | |
| 0.00 | 1.37 | 0.00 | 0.71 | -5.45 | 177.58 | 14.64 | 244.47 | 0.2801 | 820.0 | 609.5 | |
| 0.00 | 1.20 | 0.00 | 0.63 | -13.09 | 175.83 | 12.90 | 220.86 | 0.3338 | 866.0 | 727.6 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -9.18 | 175.60 | 12.66 | 229.52 | 0.2858 | 687.0 | 571.3 | |
| 0.00 | 0.86 | 0.00 | 0.47 | -21.41 | 175.32 | 12.39 | 207.19 | 0.4389 | 758.0 | 611.1 | |
| 0.00 | 0.77 | 0.00 | 0.41 | -17.73 | 174.79 | 11.85 | 210.75 | 0.3843 | 677.0 | 627.8 | |
| 0.00 | 1.37 | 0.00 | 0.72 | -15.66 | 173.19 | 10.25 | 210.19 | 0.3424 | 914.0 | 686.6 | |
| 0.00 | 0.94 | 0.00 | 0.50 | -15.23 | 173.11 | 10.17 | 210.66 | 0.3356 | 834.0 | 695.0 | |
| 0.00 | 1.63 | 0.00 | 0.87 | -17.68 | 173.01 | 10.08 | 206.93 | 0.3698 | 828.0 | 704.9 | |
| 0.00 | 0.77 | 0.00 | 0.41 | -17.81 | 172.83 | 9.90 | 206.35 | 0.3702 | 714.0 | 632.8 | |
| 0.00 | 1.11 | 0.00 | 0.59 | -15.60 | 172.66 | 9.72 | 208.98 | 0.3371 | 852.0 | 774.5 | |
| 0.00 | 1.80 | 0.00 | 0.91 | -6.07 | 172.30 | 9.36 | 230.91 | 0.2094 | 856.0 | 683.9 | |
| 0.00 | 1.71 | 0.00 | 0.91 | -17.68 | 172.63 | 9.70 | 206.06 | 0.3670 | 976.0 | 791.5 | |
| 0.00 | 1.03 | 0.00 | 0.56 | -20.53 | 172.64 | 9.71 | 202.85 | 0.4084 | 751.0 | 693.8 | |
| 0.00 | 3.51 | 0.00 | 1.90 | -20.69 | 172.46 | 9.52 | 202.31 | 0.4096 | 802.0 | 592.0 | |
| 0.00 | 2.57 | 0.00 | 1.36 | -16.93 | 171.59 | 8.66 | 204.51 | 0.3486 | 840.0 | 731.6 | |
| 0.00 | 1.03 | 0.00 | 0.55 | -17.80 | 171.51 | 8.57 | 203.26 | 0.3610 | 814.0 | 554.8 | |
| 0.00 | 0.94 | 0.00 | 0.48 | -6.78 | 170.08 | 7.15 | 220.67 | 0.1904 | 817.0 | 684.7 | |
| 0.00 | 1.54 | 0.00 | 0.78 | -8.82 | 169.84 | 6.91 | 213.60 | 0.2158 | 931.0 | 696.1 | |
| 0.00 | 1.63 | 0.00 | 0.82 | -5.58 | 169.08 | 6.14 | 220.87 | 0.1635 | 964.0 | 729.9 | |
| 0.00 | 0.51 | 0.00 | 0.26 | -13.60 | 167.81 | 4.88 | 197.60 | 0.2745 | 628.0 | 411.5 | |
| 9.59 | 728.17 | 4.89 | 373.20 | -11.80 | 166.90 | 3.96 | 196.40 | 0.2408 | 1286.6 | 469.5 | |
| 0.00 | 1.28 | 0.00 | 0.66 | -13.08 | 166.92 | 3.98 | 195.05 | 0.2618 | 483.0 | 210.7 | |
| 16.27 | -22.00 | 8.31 | -22.00 | -12.04 | 166.60 | 3.66 | 194.95 | 0.2434 | 1315.6 | 999999 | |
| 0.00 | 3.77 | 0.00 | 1.93 | -12.74 | 166.46 | 3.52 | 193.69 | 0.2543 | 651.0 | 638.8 | |
| 1.54 | -22.00 | 0.79 | -22.00 | -11.92 | 166.26 | 3.33 | 193.76 | 0.2399 | 1251.7 | 999999 | |
| 7.71 | -22.00 | 3.94 | -22.00 | -12.31 | 166.06 | 3.12 | 192.57 | 0.2457 | 1189.3 | 999999 | |
| 0.00 | 1.11 | 0.00 | 0.58 | -15.04 | 165.91 | 2.97 | 189.97 | 0.2903 | 698.0 | 480.7 | |
| 1.20 | -22.00 | 0.61 | -22.00 | -12.25 | 165.81 | 2.88 | 191.67 | 0.2438 | 1168.6 | 999999 | |
| 12.59 | -22.00 | 6.45 | -22.00 | -13.07 | 165.49 | 2.55 | 189.78 | 0.2565 | 1480.4 | 999999 | |
| 0.00 | 1.37 | 0.00 | 0.70 | -11.73 | 165.45 | 2.51 | 190.61 | 0.2339 | 1018.0 | 761.1 | |
| 0.26 | -22.00 | 0.13 | -22.00 | -12.77 | 165.24 | 2.31 | 189.05 | 0.2507 | 1204.3 | 999999 | |
| 0.00 | 2.48 | 0.00 | 1.26 | -11.79 | 165.20 | 2.27 | 189.57 | 0.2342 | 599.0 | 390.3 | |
| 64.91 | -22.00 | 33.32 | -22.00 | -13.59 | 165.13 | 2.19 | 188.12 | 0.2642 | 1596.2 | 999999 | |
| 4.28 | -22.00 | 2.20 | -22.00 | -14.24 | 164.83 | 1.89 | 186.73 | 0.2743 | 958.4 | 999999 | |
| 5.14 | -22.00 | 2.64 | -22.00 | -14.05 | 164.73 | 1.80 | 186.48 | 0.2711 | 1199.9 | 999999 | |
| 1.97 | -22.00 | 1.01 | -22.00 | -14.42 | 164.68 | 1.74 | 186.12 | 0.2771 | 927.0 | 999999 | |
| 0.00 | 0.94 | 0.00 | 0.50 | -19.76 | 164.31 | 1.38 | 183.56 | 0.3649 | -763.0 | -707.0 | |
| 0.69 | 13.02 | 0.35 | 6.61 | -10.94 | 163.72 | 0.79 | 183.58 | 0.2168 | -896.4 | -421.4 | |
| 0.51 | -39.00 | 0.26 | -39.00 | -10.91 | 163.60 | 0.67 | 183.04 | 0.2162 | -1135.2 | 999999 | |
| 0.00 | 1.20 | 0.00 | 0.62 | -14.14 | 163.30 | 0.37 | 181.31 | 0.2709 | 935.0 | 776.1 | |
| 0.86 | 4.20 | 0.43 | 2.13 | -11.00 | 163.18 | 0.24 | 181.11 | 0.2175 | -822.3 | -721.0 | |
| 0.00 | 1.11 | 0.00 | 0.57 | -14.30 | 163.12 | 0.18 | 180.65 | 0.2735 | 882.0 | 655.3 | |
| 0.00 | 2.74 | 0.00 | 1.41 | -14.17 | 162.84 | -0.09 | 179.67 | 0.2714 | 303.0 | 283.6 | |
| 0.00 | 1.11 | 0.00 | 0.57 | -12.64 | 162.78 | -0.15 | 179.40 | 0.2454 | -652.0 | -421.6 | |
| 0.00 | 4.28 | 0.00 | 2.17 | -10.39 | 162.79 | -0.15 | 179.30 | 0.2071 | -438.0 | -711.6 | |
| 0.00 | 3.43 | 0.00 | 1.74 | -11.33 | 162.70 | -0.24 | 178.95 | 0.2232 | -872.0 | -645.2 | |
| 0.00 | 3.34 | 0.00 | 1.73 | -15.65 | 162.69 | -0.25 | 179.19 | 0.2963 | -862.0 | -661.4 | |
| 0.00 | 1.46 | 0.00 | 0.75 | -13.56 | 162.63 | -0.30 | 178.86 | 0.2610 | 267.0 | 286.5 | |
| 0.00 | 2.31 | 0.00 | 1.20 | -15.37 | 162.53 | -0.40 | 178.67 | 0.2917 | -1028.0 | -824.9 | |
| 0.00 | 3.25 | 0.00 | 1.67 | -14.20 | 162.51 | -0.43 | 178.47 | 0.2720 | -353.0 | -236.7 | |
| 0.00 | 1.37 | 0.00 | 0.70 | -14.02 | 162.39 | -0.55 | 178.01 | 0.2689 | -821.0 | -705.6 | |
| 0.51 | 4.71 | 0.26 | 2.40 | -12.27 | 162.27 | -0.66 | 177.27 | 0.2395 | -892.8 | -650.6 | |
| 0.00 | 2.06 | 0.00 | 1.05 | -13.16 | 162.18 | -0.76 | 177.08 | 0.2546 | -880.0 | -739.9 | |
| 0.00 | 0.86 | 0.00 | 0.44 | -14.91 | 162.14 | -0.80 | 177.27 | 0.2841 | -740.0 | -618.7 | |
| 0.00 | 0.77 | 0.00 | 0.40 | -14.26 | 162.05 | -0.89 | 176.84 | 0.2733 | -639.0 | -495.6 | |
| 0.00 | 5.31 | 0.00 | 2.73 | -13.68 | 161.87 | -1.07 | 176.05 | 0.2637 | -879.0 | -614.0 | |
| 0.00 | 2.74 | 0.00 | 1.41 | -14.33 | 161.80 | -1.13 | 175.99 | 0.2746 | -875.0 | -725.2 | |
| 0.00 | 0.69 | 0.00 | 0.36 | -16.58 | 161.11 | -1.83 | 174.38 | 0.3133 | -807.0 | -687.9 | |
| 2.48 | 4.11 | 1.28 | 2.11 | -13.65 | 160.86 | -2.07 | 172.35 | 0.2649 | -1123.8 | -876.1 | |
| 0.00 | 1.11 | 0.00 | 0.57 | -12.73 | 160.78 | -2.15 | 171.52 | 0.2497 | -765.0 | -568.7 | |
| 0.00 | 0.86 | 0.00 | 0.45 | -18.71 | 160.40 | -2.54 | 173.08 | 0.3496 | -845.0 | -676.1 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -13.43 | 160.47 | -2.46 | 170.78 | 0.2623 | -765.0 | -587.9 | |
| 0.77 | 4.11 | 0.40 | 2.15 | -17.21 | 160.39 | -2.55 | 172.47 | 0.3249 | -964.1 | -787.8 | |
| 0.00 | 1.46 | 0.00 | 0.75 | -13.22 | 160.32 | -2.61 | 170.09 | 0.2591 | -973.0 | -749.4 | |
| 0.00 | 0.77 | 0.00 | 0.40 | -13.96 | 160.28 | -2.65 | 170.43 | 0.2715 | -816.0 | -584.7 | |
| 0.00 | 1.11 | 0.00 | 0.58 | -14.94 | 160.24 | -2.70 | 170.87 | 0.2879 | -786.0 | -615.0 | |
| 0.00 | 2.31 | 0.00 | 1.19 | -13.68 | 160.25 | -2.68 | 170.15 | 0.2669 | -1036.0 | -706.3 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -12.85 | 160.20 | -2.73 | 169.38 | 0.2533 | -783.0 | -678.8 | |
| 0.00 | 1.71 | 0.00 | 0.87 | -11.91 | 160.18 | -2.75 | 168.55 | 0.2377 | -1075.0 | -882.2 | |
| 0.00 | 1.37 | 0.00 | 0.71 | -14.45 | 160.12 | -2.81 | 170.19 | 0.2801 | -926.0 | -710.9 | |
| 0.00 | 0.86 | 0.00 | 0.44 | -14.05 | 160.13 | -2.81 | 169.95 | 0.2734 | -794.0 | -574.4 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -12.49 | 160.12 | -2.82 | 168.77 | 0.2475 | -828.0 | -648.0 | |
| 0.00 | 1.28 | 0.00 | 0.67 | -16.68 | 159.93 | -3.00 | 170.87 | 0.3173 | -963.0 | -782.5 | |
| 0.00 | 4.20 | 0.00 | 2.16 | -14.02 | 159.88 | -3.05 | 169.07 | 0.2737 | -1046.0 | -911.7 | |
| 0.00 | 1.63 | 0.00 | 0.85 | -16.80 | 159.78 | -3.16 | 170.46 | 0.3198 | -947.0 | -759.7 | |
| 0.00 | 2.06 | 0.00 | 1.06 | -14.11 | 159.70 | -3.24 | 168.50 | 0.2758 | -940.0 | -786.6 | |
| 0.00 | 1.37 | 0.00 | 0.71 | -15.22 | 159.62 | -3.32 | 169.02 | 0.2943 | -972.0 | -783.4 | |
| 0.00 | 1.46 | 0.00 | 0.76 | -16.90 | 159.53 | -3.41 | 169.78 | 0.3220 | -927.0 | -761.0 | |
| 0.00 | 1.37 | 0.00 | 0.70 | -12.46 | 159.45 | -3.49 | 166.17 | 0.2495 | -913.0 | -748.6 | |
| 0.00 | 3.43 | 0.00 | 1.79 | -16.93 | 159.09 | -3.84 | 168.53 | 0.3239 | -903.0 | -721.0 | |
| 0.00 | 1.28 | 0.00 | 0.66 | -12.40 | 159.15 | -3.79 | 164.96 | 0.2498 | -964.0 | -806.9 | |
| 0.00 | 0.94 | 0.00 | 0.49 | -16.96 | 158.91 | -4.03 | 168.01 | 0.3251 | -1041.0 | -793.5 | |
| 0.00 | 2.14 | 0.00 | 1.12 | -17.15 | 158.90 | -4.03 | 168.13 | 0.3281 | -723.0 | -421.4 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -14.42 | 158.78 | -4.16 | 165.63 | 0.2843 | -853.0 | -672.5 | |
| 0.00 | 1.28 | 0.00 | 0.67 | -16.83 | 158.69 | -4.24 | 167.31 | 0.3238 | -860.0 | -757.9 | |
| 0.00 | 1.80 | 0.00 | 0.93 | -13.68 | 157.26 | -5.67 | 159.85 | 0.2801 | -1007.0 | -860.2 | |
| 0.00 | 0.94 | 0.00 | 0.48 | -13.07 | 157.16 | -5.78 | 158.69 | 0.2711 | -986.0 | -793.7 | |
| 0.00 | 1.71 | 0.00 | 0.88 | -13.65 | 156.93 | -6.01 | 158.72 | 0.2816 | -815.0 | -700.2 | |
| 0.00 | 2.06 | 0.00 | 1.06 | -13.10 | 156.79 | -6.15 | 157.51 | 0.2739 | -1090.0 | -922.7 | |
| 0.00 | 2.91 | 0.00 | 1.49 | -11.33 | 156.80 | -6.13 | 154.73 | 0.2466 | -908.0 | -760.1 | |
| 0.00 | 1.97 | 0.00 | 1.02 | -13.32 | 156.75 | -6.18 | 157.70 | 0.2775 | -1064.0 | -872.5 | |
| 0.00 | 0.94 | 0.00 | 0.49 | -13.25 | 156.54 | -6.40 | 156.92 | 0.2779 | -951.0 | -806.3 | |
| 0.00 | 1.46 | 0.00 | 0.74 | -11.00 | 156.60 | -6.34 | 153.39 | 0.2430 | -946.0 | -801.0 | |
| 0.00 | 1.37 | 0.00 | 0.71 | -13.47 | 156.44 | -6.49 | 156.92 | 0.2819 | -841.0 | -572.9 | |
| 0.00 | 1.11 | 0.00 | 0.56 | -8.71 | 156.16 | -6.77 | 146.63 | 0.2130 | -876.0 | -592.4 | |
| 0.00 | 1.63 | 0.00 | 0.88 | -20.25 | 153.04 | -9.90 | 156.46 | 0.4055 | -823.0 | -571.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
