SDO HMI 2014-11-27 02:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 55.97 | 344.68 | 38.14 | 235.82 | 15.98 | 110.35 | -41.59 | 68.00 | 0.6905 | -1010.8 | -282.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-27 02:00:26 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 55.46 | 334.57 | 37.73 | 228.05 | 15.98 | 110.58 | -41.36 | 67.93 | 0.6879 | -1274.6 | -308.6 | |
| 0.00 | 0.43 | 0.00 | 0.30 | 16.44 | 107.93 | -44.01 | 68.25 | 0.7198 | -375.0 | -300.6 | |
| 0.00 | 1.46 | 0.00 | 1.08 | 16.03 | 105.55 | -46.39 | 69.53 | 0.7452 | 289.0 | 368.6 | |
| 0.00 | 1.03 | 0.00 | 0.77 | 16.32 | 104.60 | -47.34 | 69.42 | 0.7562 | 205.0 | 277.7 | |
| 0.00 | 1.88 | 0.00 | 1.43 | 16.41 | 104.34 | -47.60 | 69.38 | 0.7592 | 527.0 | 461.1 | |
| 0.00 | 1.03 | 0.00 | 0.79 | 17.04 | 103.57 | -48.37 | 68.78 | 0.7689 | 557.0 | 455.2 | |
| 0.00 | 2.23 | 0.00 | 1.77 | 15.81 | 101.81 | -50.13 | 70.79 | 0.7843 | 636.0 | 483.9 | |
| 0.51 | 2.05 | 0.41 | 1.63 | 15.17 | 101.88 | -50.06 | 71.58 | 0.7823 | 443.2 | 438.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
