SDO HMI 2014-11-29 07:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.51 | 12.83 | 0.26 | 6.57 | 14.95 | 119.59 | -3.26 | 12.32 | 0.2500 | -541.4 | -584.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-29 07:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.74 | 0.00 | 1.39 | 14.17 | 122.69 | -0.17 | 0.71 | 0.2269 | -940.0 | -704.7 | |
| 0.00 | 1.45 | 0.00 | 0.74 | 15.72 | 122.35 | -0.50 | 1.92 | 0.2534 | 940.0 | 630.0 | |
| 0.51 | 1.63 | 0.26 | 0.83 | 14.07 | 122.29 | -0.56 | 2.43 | 0.2255 | -995.0 | -867.2 | |
| 0.00 | 5.90 | 0.00 | 3.03 | 14.99 | 117.26 | -5.59 | 21.43 | 0.2588 | -904.0 | -775.6 | |
| 0.00 | 1.11 | 0.00 | 0.58 | 16.89 | 116.93 | -5.92 | 19.96 | 0.2905 | -690.0 | -580.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
