SDO HMI 2014-11-29 20:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 146.14 | 596.12 | 103.23 | 423.97 | 3.91 | 161.34 | 45.62 | 274.51 | 0.7168 | -180.7 | -136.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-29 20:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.45 | 389.87 | 1.08 | 287.01 | 3.34 | 163.98 | 48.26 | 273.53 | 0.7487 | -191.6 | -301.9 | |
| 35.21 | -1.00 | 26.10 | -1.00 | 2.81 | 163.77 | 48.05 | 272.82 | 0.7461 | -954.6 | 999999 | |
| 15.21 | -1.00 | 11.23 | -1.00 | 3.41 | 163.54 | 47.82 | 273.63 | 0.7436 | -958.2 | 999999 | |
| 14.36 | -1.00 | 10.54 | -1.00 | 3.65 | 163.29 | 47.58 | 273.97 | 0.7408 | -1078.7 | 999999 | |
| 8.29 | -1.00 | 6.03 | -1.00 | 3.84 | 162.77 | 47.06 | 274.24 | 0.7348 | -947.0 | 999999 | |
| 0.00 | 1.62 | 0.00 | 1.18 | 4.70 | 162.45 | 46.74 | 275.44 | 0.7315 | -14.0 | -31.9 | |
| 1.71 | -1.00 | 1.23 | -1.00 | 3.72 | 162.33 | 46.62 | 274.11 | 0.7295 | -813.3 | 999999 | |
| 0.00 | 1.20 | 0.00 | 0.86 | 4.91 | 162.26 | 46.54 | 275.75 | 0.7292 | 141.0 | 118.7 | |
| 12.31 | -1.00 | 8.83 | -1.00 | 4.20 | 162.02 | 46.31 | 274.79 | 0.7260 | -876.1 | 999999 | |
| 0.00 | 2.39 | 0.00 | 1.71 | 4.62 | 161.80 | 46.09 | 275.38 | 0.7236 | -651.0 | -560.8 | |
| 0.00 | 2.14 | 0.00 | 1.52 | 4.06 | 161.50 | 45.78 | 274.62 | 0.7196 | -388.0 | -360.9 | |
| 0.34 | 1.62 | 0.24 | 1.14 | 3.65 | 161.04 | 45.33 | 274.08 | 0.7139 | -763.2 | -669.5 | |
| 0.00 | 1.20 | 0.00 | 0.84 | 4.48 | 160.93 | 45.22 | 275.25 | 0.7130 | -737.0 | -467.4 | |
| 0.00 | 1.97 | 0.00 | 1.38 | 4.31 | 160.63 | 44.91 | 275.03 | 0.7091 | -614.0 | -611.8 | |
| 0.00 | 0.77 | 0.00 | 0.54 | 4.49 | 160.30 | 44.59 | 275.31 | 0.7053 | -315.0 | -367.1 | |
| 0.00 | 1.28 | 0.00 | 0.89 | 3.99 | 160.18 | 44.47 | 274.60 | 0.7035 | 201.0 | 181.4 | |
| 3.16 | 9.49 | 2.19 | 6.59 | 3.25 | 160.09 | 44.38 | 273.55 | 0.7020 | 687.8 | 81.8 | |
| 0.00 | 1.20 | 0.00 | 0.83 | 3.70 | 160.08 | 44.37 | 274.19 | 0.7020 | 570.0 | 500.3 | |
| 0.00 | 0.85 | 0.00 | 0.59 | 4.67 | 160.07 | 44.36 | 275.59 | 0.7025 | 283.0 | 140.3 | |
| 0.00 | 0.85 | 0.00 | 0.59 | 4.05 | 159.90 | 44.18 | 274.71 | 0.6999 | 479.0 | 321.3 | |
| 0.00 | 0.51 | 0.00 | 0.35 | 5.18 | 159.90 | 44.19 | 276.32 | 0.7008 | 178.0 | 154.3 | |
| 0.94 | 2.05 | 0.65 | 1.41 | 5.30 | 159.67 | 43.95 | 276.52 | 0.6980 | 655.5 | 433.2 | |
| 7.69 | 11.11 | 5.28 | 7.63 | 4.51 | 159.47 | 43.76 | 275.39 | 0.6950 | 801.2 | 479.7 | |
| 0.00 | 0.85 | 0.00 | 0.58 | 5.46 | 159.14 | 43.43 | 276.80 | 0.6916 | -516.0 | -453.4 | |
| 4.44 | 21.11 | 3.01 | 14.27 | 4.72 | 158.67 | 42.96 | 275.77 | 0.6850 | 687.5 | -199.0 | |
| 4.10 | -25.00 | 2.77 | -25.00 | 5.00 | 158.33 | 42.62 | 276.20 | 0.6809 | -818.2 | 999999 | |
| 0.00 | 1.54 | 0.00 | 1.03 | 2.78 | 157.87 | 42.15 | 272.96 | 0.6736 | 551.0 | 409.5 | |
| 0.00 | 1.37 | 0.00 | 0.92 | 5.50 | 157.97 | 42.26 | 276.99 | 0.6767 | -509.0 | -350.4 | |
| 0.00 | 0.94 | 0.00 | 0.63 | 3.26 | 157.61 | 41.90 | 273.68 | 0.6704 | 584.0 | 505.5 | |
| 0.00 | 1.71 | 0.00 | 1.14 | 3.79 | 157.60 | 41.89 | 274.48 | 0.6706 | 314.0 | 302.1 | |
| 0.00 | 3.08 | 0.00 | 2.04 | 3.91 | 157.25 | 41.54 | 274.69 | 0.6661 | 596.0 | 525.1 | |
| 0.60 | 2.05 | 0.39 | 1.35 | 3.17 | 157.09 | 41.38 | 273.58 | 0.6636 | 633.3 | 534.9 | |
| 0.00 | 1.97 | 0.00 | 1.30 | 3.68 | 157.08 | 41.36 | 274.35 | 0.6637 | 724.0 | 598.7 | |
| 0.00 | 1.88 | 0.00 | 1.24 | 3.47 | 156.83 | 41.11 | 274.05 | 0.6603 | 839.0 | 707.5 | |
| 0.00 | 2.31 | 0.00 | 1.52 | 3.27 | 156.78 | 41.06 | 273.74 | 0.6596 | 773.0 | 728.3 | |
| 0.94 | 2.14 | 0.62 | 1.40 | 3.77 | 156.76 | 41.05 | 274.51 | 0.6597 | 807.5 | 748.2 | |
| 0.00 | 1.20 | 0.00 | 0.79 | 6.11 | 156.95 | 41.23 | 278.03 | 0.6642 | 112.0 | 136.0 | |
| 2.14 | 92.13 | 1.40 | 60.31 | 5.94 | 156.65 | 40.94 | 277.81 | 0.6602 | 362.8 | 215.0 | |
| 0.00 | 1.97 | 0.00 | 1.28 | 4.78 | 156.28 | 40.57 | 276.10 | 0.6541 | 717.0 | 578.7 | |
| 11.37 | -38.00 | 7.42 | -38.00 | 5.50 | 156.18 | 40.47 | 277.20 | 0.6535 | 958.4 | 999999 | |
| 17.01 | -38.00 | 11.09 | -38.00 | 5.94 | 156.10 | 40.39 | 277.89 | 0.6530 | 892.5 | 999999 | |
| 0.00 | 1.28 | 0.00 | 0.83 | 4.64 | 155.92 | 40.21 | 275.91 | 0.6492 | 572.0 | 551.2 | |
| 1.28 | -38.00 | 0.83 | -38.00 | 5.59 | 155.76 | 40.05 | 277.40 | 0.6481 | 961.3 | 999999 | |
| 0.43 | 5.30 | 0.28 | 3.44 | 6.31 | 155.75 | 40.03 | 278.50 | 0.6488 | 750.0 | 527.1 | |
| 0.00 | 1.54 | 0.00 | 1.00 | 5.77 | 155.58 | 39.87 | 277.70 | 0.6459 | 900.0 | 769.2 | |
| 1.88 | 7.95 | 1.21 | 5.12 | 3.88 | 155.37 | 39.65 | 274.78 | 0.6412 | 875.2 | 697.3 | |
| 0.00 | 1.03 | 0.00 | 0.66 | 5.57 | 155.41 | 39.70 | 277.41 | 0.6434 | 692.0 | 682.5 | |
| 0.00 | 2.91 | 0.00 | 1.87 | 6.16 | 155.19 | 39.48 | 278.37 | 0.6412 | 735.0 | 611.1 | |
| 0.00 | 1.28 | 0.00 | 0.82 | 5.46 | 154.78 | 39.07 | 277.32 | 0.6349 | 700.0 | 556.3 | |
| 0.60 | 7.18 | 0.38 | 4.57 | 5.46 | 154.55 | 38.84 | 277.36 | 0.6318 | 892.3 | 730.7 | |
| 0.68 | -50.00 | 0.43 | -50.00 | 5.43 | 154.40 | 38.69 | 277.33 | 0.6297 | 940.6 | 999999 | |
| 0.00 | 1.28 | 0.00 | 0.80 | 4.32 | 153.49 | 37.78 | 275.65 | 0.6161 | 679.0 | 534.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
