SDO HMI 2014-11-29 22:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 9.39 | 0.00 | 4.82 | 15.73 | 117.62 | 3.01 | 348.81 | 0.2604 | -657.4 | -689.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-29 22:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.85 | 0.00 | 0.44 | 15.70 | 122.11 | 7.50 | 333.58 | 0.2837 | 728.0 | 640.2 | |
| 0.00 | 2.22 | 0.00 | 1.14 | 15.41 | 117.42 | 2.81 | 349.21 | 0.2535 | -1010.0 | -813.5 | |
| 0.00 | 2.56 | 0.00 | 1.31 | 15.47 | 117.17 | 2.56 | 350.17 | 0.2538 | -1044.0 | -845.7 | |
| 0.00 | 1.71 | 0.00 | 0.88 | 15.78 | 117.08 | 2.48 | 350.70 | 0.2586 | -917.0 | -705.0 | |
| 0.00 | 2.05 | 0.00 | 1.05 | 16.36 | 116.97 | 2.36 | 351.48 | 0.2680 | -1044.0 | -904.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
