SDO HMI 2014-11-30 04:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 12.40 | 0.00 | 7.14 | -23.45 | 92.43 | -18.88 | 144.27 | 0.5110 | -439.8 | -384.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-30 04:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.45 | 0.00 | 0.83 | -23.54 | 94.83 | -16.48 | 147.92 | 0.4916 | 743.0 | 613.4 | |
| 0.00 | 1.11 | 0.00 | 0.62 | -19.76 | 94.36 | -16.95 | 142.21 | 0.4497 | -711.0 | -526.1 | |
| 0.00 | 1.28 | 0.00 | 0.74 | -23.97 | 93.18 | -18.13 | 146.00 | 0.5106 | -837.0 | -738.9 | |
| 0.00 | 2.05 | 0.00 | 1.18 | -24.01 | 92.87 | -18.44 | 145.60 | 0.5136 | -797.0 | -558.6 | |
| 0.00 | 0.86 | 0.00 | 0.49 | -24.24 | 92.63 | -18.68 | 145.54 | 0.5184 | -802.0 | -662.7 | |
| 0.00 | 0.94 | 0.00 | 0.54 | -24.11 | 92.61 | -18.70 | 145.37 | 0.5169 | -904.0 | -748.5 | |
| 0.00 | 1.03 | 0.00 | 0.58 | -20.53 | 91.77 | -19.54 | 139.47 | 0.4839 | -546.0 | -502.1 | |
| 0.00 | 1.88 | 0.00 | 1.11 | -25.56 | 90.64 | -20.67 | 144.49 | 0.5505 | -794.0 | -633.2 | |
| 0.00 | 1.03 | 0.00 | 0.61 | -25.17 | 90.29 | -21.02 | 143.59 | 0.5491 | -629.0 | -538.2 | |
| 0.00 | 0.77 | 0.00 | 0.44 | -20.48 | 90.57 | -20.74 | 137.75 | 0.4954 | 879.0 | 763.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
