SDO HMI 2014-11-30 14:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 7.43 | 0.00 | 3.77 | -4.87 | 96.26 | -9.59 | 123.42 | 0.2008 | 560.0 | 314.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-30 14:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.60 | 0.00 | 0.30 | -4.85 | 99.99 | -5.85 | 134.89 | 0.1441 | 847.0 | 669.7 | |
| 0.00 | 0.85 | 0.00 | 0.43 | -4.91 | 99.90 | -5.94 | 134.75 | 0.1459 | 753.0 | 593.3 | |
| 0.00 | 1.11 | 0.00 | 0.56 | -7.26 | 99.40 | -6.45 | 142.06 | 0.1821 | 847.0 | 664.5 | |
| 0.00 | 1.28 | 0.00 | 0.64 | -2.86 | 99.06 | -6.79 | 119.44 | 0.1362 | 733.0 | 606.4 | |
| 0.00 | 0.94 | 0.00 | 0.47 | -2.66 | 99.06 | -6.79 | 118.10 | 0.1345 | 809.0 | 479.2 | |
| 0.00 | 1.03 | 0.00 | 0.53 | -9.94 | 92.43 | -13.42 | 129.55 | 0.2978 | 816.0 | 626.5 | |
| 0.00 | 1.62 | 0.00 | 0.84 | -2.82 | 89.69 | -16.16 | 103.24 | 0.2869 | -885.0 | -700.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
