SDO HMI 2014-11-30 16:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 9.92 | 0.00 | 4.99 | -4.89 | 97.98 | -6.77 | 135.92 | 0.1639 | 629.9 | 479.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-11-30 16:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.03 | 0.00 | 0.51 | -4.73 | 102.61 | -2.13 | 159.49 | 0.1064 | 757.0 | 692.6 | |
| 0.00 | 1.28 | 0.00 | 0.64 | -3.93 | 102.35 | -2.40 | 153.92 | 0.0954 | 858.0 | 717.1 | |
| 0.00 | 2.31 | 0.00 | 1.15 | -4.76 | 99.97 | -4.78 | 140.21 | 0.1303 | 924.0 | 661.7 | |
| 0.00 | 1.28 | 0.00 | 0.64 | -7.23 | 99.37 | -5.37 | 146.90 | 0.1708 | 850.0 | 704.8 | |
| 0.00 | 1.54 | 0.00 | 0.77 | -2.95 | 99.12 | -5.63 | 124.84 | 0.1199 | 985.0 | 797.1 | |
| 0.00 | 0.94 | 0.00 | 0.49 | -9.97 | 92.46 | -12.28 | 132.09 | 0.2836 | 786.0 | 610.0 | |
| 0.00 | 1.54 | 0.00 | 0.79 | -2.82 | 89.73 | -15.02 | 104.18 | 0.2682 | -751.0 | -688.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
