SDO HMI 2014-12-02 01:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 63.82 | 383.84 | 35.83 | 215.39 | 16.64 | 110.07 | 23.47 | 305.71 | 0.4720 | -1123.8 | -357.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-02 01:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 63.82 | 373.24 | 35.83 | 209.56 | 16.61 | 110.17 | 23.57 | 305.54 | 0.4730 | -1444.5 | -391.7 | |
| 0.00 | 1.20 | 0.00 | 0.66 | 16.68 | 107.44 | 20.85 | 308.87 | 0.4398 | 766.0 | 634.4 | |
| 0.00 | 1.28 | 0.00 | 0.71 | 18.23 | 107.27 | 20.67 | 311.88 | 0.4523 | 579.0 | 449.3 | |
| 0.00 | 1.71 | 0.00 | 0.94 | 17.21 | 106.78 | 20.18 | 310.71 | 0.4367 | 912.0 | 708.0 | |
| 0.00 | 3.16 | 0.00 | 1.75 | 17.92 | 106.80 | 20.20 | 311.97 | 0.4438 | 750.0 | 721.6 | |
| 0.00 | 1.88 | 0.00 | 1.03 | 17.49 | 106.61 | 20.02 | 311.44 | 0.4374 | 824.0 | 664.0 | |
| 0.00 | 1.37 | 0.00 | 0.74 | 17.38 | 104.34 | 17.75 | 314.54 | 0.4099 | 916.0 | 777.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
