SDO HMI 2014-12-02 14:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 37.25 | 147.14 | 22.17 | 88.07 | -19.12 | 107.63 | 28.14 | 232.73 | 0.5616 | -77.8 | 148.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-02 14:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.54 | 5.04 | 0.96 | 3.14 | -19.77 | 111.49 | 32.00 | 235.08 | 0.6105 | 763.4 | 657.9 | |
| 0.60 | 2.56 | 0.37 | 1.58 | -19.80 | 110.57 | 31.08 | 234.33 | 0.6002 | 706.6 | 519.6 | |
| 0.00 | 2.73 | 0.00 | 1.68 | -19.39 | 110.48 | 31.00 | 234.86 | 0.5963 | 596.0 | 478.8 | |
| 0.00 | 2.65 | 0.00 | 1.63 | -19.67 | 110.33 | 30.84 | 234.32 | 0.5965 | 735.0 | 655.6 | |
| 0.00 | 1.28 | 0.00 | 0.78 | -18.91 | 110.13 | 30.64 | 235.27 | 0.5889 | 347.0 | 370.3 | |
| 0.00 | 1.28 | 0.00 | 0.78 | -18.50 | 109.87 | 30.38 | 235.67 | 0.5830 | 197.0 | 138.2 | |
| 0.00 | 1.28 | 0.00 | 0.78 | -18.25 | 109.60 | 30.11 | 235.84 | 0.5781 | -468.0 | -314.7 | |
| 0.51 | 1.71 | 0.31 | 1.05 | -19.95 | 109.84 | 30.35 | 233.52 | 0.5929 | 767.0 | 688.4 | |
| 6.49 | 27.76 | 3.95 | 16.96 | -18.88 | 109.58 | 30.09 | 234.88 | 0.5822 | 955.1 | 795.7 | |
| 0.00 | 4.44 | 0.00 | 2.68 | -18.62 | 109.13 | 29.65 | 234.89 | 0.5752 | 242.0 | 688.4 | |
| 0.77 | 33.22 | 0.46 | 19.90 | -18.43 | 108.78 | 29.29 | 234.88 | 0.5696 | 858.3 | 145.6 | |
| 0.00 | 0.77 | 0.00 | 0.47 | -20.61 | 109.10 | 29.61 | 231.95 | 0.5896 | 558.0 | 448.6 | |
| 1.88 | -11.00 | 1.13 | -11.00 | -18.71 | 108.51 | 29.02 | 234.23 | 0.5685 | -650.9 | 999999 | |
| 0.00 | 1.02 | 0.00 | 0.63 | -20.45 | 108.85 | 29.36 | 231.96 | 0.5856 | 533.0 | 556.2 | |
| 0.00 | 1.45 | 0.00 | 0.88 | -20.22 | 108.51 | 29.03 | 231.99 | 0.5801 | 552.0 | 572.5 | |
| 1.20 | -11.00 | 0.71 | -11.00 | -18.30 | 108.00 | 28.52 | 234.41 | 0.5595 | 757.6 | 999999 | |
| 5.64 | -11.00 | 3.37 | -11.00 | -18.61 | 107.92 | 28.43 | 233.86 | 0.5609 | -805.0 | 999999 | |
| 0.00 | 1.20 | 0.00 | 0.70 | -17.30 | 107.23 | 27.74 | 235.30 | 0.5428 | -765.0 | -710.0 | |
| 1.02 | 10.50 | 0.60 | 6.15 | -19.16 | 105.45 | 25.96 | 230.68 | 0.5366 | -899.8 | -725.2 | |
| 16.23 | 43.21 | 9.52 | 25.37 | -19.63 | 105.25 | 25.76 | 229.76 | 0.5384 | -1013.2 | -385.5 | |
| 0.00 | 0.77 | 0.00 | 0.45 | -19.19 | 105.10 | 25.62 | 230.28 | 0.5329 | -885.0 | -733.6 | |
| 1.37 | 2.65 | 0.79 | 1.53 | -18.55 | 104.38 | 24.89 | 230.51 | 0.5192 | 809.6 | 727.1 | |
| 0.00 | 1.62 | 0.00 | 0.93 | -18.14 | 103.94 | 24.45 | 230.68 | 0.5105 | 191.0 | 277.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
