SDO HMI 2014-12-03 09:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 42.88 | 112.67 | 40.92 | 105.93 | -16.06 | 125.49 | 56.44 | 250.50 | 0.8507 | 133.6 | 46.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-03 09:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.25 | 10.85 | 3.59 | 11.95 | -15.15 | 131.24 | 62.19 | 252.70 | 0.8961 | 394.2 | 362.3 | |
| 2.05 | -1.00 | 2.25 | -1.00 | -14.87 | 131.03 | 61.98 | 252.97 | 0.8943 | 556.5 | 999999 | |
| 0.00 | 1.20 | 0.00 | 1.24 | -14.69 | 129.16 | 60.12 | 252.86 | 0.8796 | 190.0 | 168.3 | |
| 0.00 | 0.77 | 0.00 | 0.78 | -15.18 | 128.40 | 59.36 | 252.18 | 0.8742 | -369.0 | -405.7 | |
| 4.61 | 52.19 | 4.47 | 49.93 | -15.41 | 126.85 | 57.80 | 251.62 | 0.8617 | -635.5 | -6.6 | |
| 8.11 | -5.00 | 7.78 | -5.00 | -15.00 | 126.50 | 57.45 | 252.02 | 0.8581 | 241.1 | 999999 | |
| 8.46 | -5.00 | 8.00 | -5.00 | -14.81 | 126.08 | 57.03 | 252.15 | 0.8542 | 688.2 | 999999 | |
| 2.73 | 4.36 | 2.54 | 4.05 | -15.24 | 125.36 | 56.31 | 251.52 | 0.8486 | 585.7 | 422.3 | |
| 6.92 | 10.08 | 6.45 | 9.39 | -17.24 | 125.00 | 55.96 | 249.12 | 0.8492 | 536.1 | 286.6 | |
| 0.00 | 1.62 | 0.00 | 1.45 | -15.31 | 123.86 | 54.81 | 251.10 | 0.8353 | -319.0 | -197.7 | |
| 0.00 | 1.11 | 0.00 | 0.97 | -14.88 | 123.11 | 54.06 | 251.45 | 0.8276 | -100.0 | -137.2 | |
| 0.00 | 0.85 | 0.00 | 0.76 | -15.86 | 123.27 | 54.23 | 250.32 | 0.8311 | -292.0 | -259.9 | |
| 0.00 | 1.28 | 0.00 | 1.12 | -15.76 | 122.71 | 53.67 | 250.30 | 0.8257 | -444.0 | -390.3 | |
| 0.00 | 2.48 | 0.00 | 2.25 | -19.66 | 123.42 | 54.38 | 245.91 | 0.8406 | 506.0 | 423.1 | |
| 0.00 | 1.62 | 0.00 | 1.42 | -17.52 | 122.38 | 53.33 | 248.13 | 0.8264 | -185.0 | -132.2 | |
| 1.02 | 2.39 | 0.91 | 2.12 | -18.49 | 122.70 | 53.66 | 247.08 | 0.8316 | 560.5 | 434.8 | |
| 0.00 | 0.68 | 0.00 | 0.62 | -19.69 | 123.22 | 54.17 | 245.82 | 0.8389 | 507.0 | 405.0 | |
| 0.00 | 0.94 | 0.00 | 0.86 | -20.65 | 123.66 | 54.61 | 244.85 | 0.8449 | 425.0 | 353.9 | |
| 0.00 | 0.94 | 0.00 | 0.81 | -17.12 | 121.95 | 52.90 | 248.50 | 0.8215 | -469.0 | -412.6 | |
| 3.42 | 8.71 | 2.95 | 7.51 | -17.58 | 121.88 | 52.84 | 247.93 | 0.8220 | -559.0 | -465.2 | |
| 2.31 | -20.00 | 1.98 | -20.00 | -17.39 | 121.65 | 52.61 | 248.09 | 0.8194 | -721.1 | 999999 | |
| 0.00 | 0.68 | 0.00 | 0.62 | -20.38 | 122.98 | 53.93 | 244.95 | 0.8385 | 417.0 | 339.2 | |
| 0.00 | 1.54 | 0.00 | 1.35 | -19.24 | 122.20 | 53.16 | 246.06 | 0.8289 | 598.0 | 508.2 | |
| 0.00 | 1.02 | 0.00 | 0.91 | -19.49 | 122.27 | 53.22 | 245.79 | 0.8301 | 539.0 | 435.9 | |
| 0.00 | 1.20 | 0.00 | 1.01 | -16.80 | 121.01 | 51.96 | 248.63 | 0.8119 | 512.0 | 380.6 | |
| 0.00 | 0.60 | 0.00 | 0.52 | -19.61 | 121.23 | 52.18 | 245.34 | 0.8211 | 556.0 | 468.7 | |
| 0.00 | 0.43 | 0.00 | 0.34 | -19.76 | 117.49 | 48.44 | 243.93 | 0.7863 | -379.0 | -335.2 | |
| 0.00 | 1.11 | 0.00 | 0.88 | -19.76 | 117.25 | 48.20 | 243.84 | 0.7840 | -479.0 | -412.2 | |
| 0.00 | 0.26 | 0.00 | 0.19 | -16.71 | 115.65 | 46.60 | 247.07 | 0.7580 | -582.0 | -542.3 | |
| 0.00 | 0.94 | 0.00 | 0.71 | -17.08 | 115.23 | 46.18 | 246.45 | 0.7547 | -490.0 | -457.7 | |
| 0.00 | 1.45 | 0.00 | 1.11 | -20.56 | 115.06 | 46.01 | 242.02 | 0.7652 | -158.0 | -206.5 | |
| 0.00 | 0.77 | 0.00 | 0.59 | -20.68 | 115.02 | 45.97 | 241.84 | 0.7652 | -499.0 | -392.8 | |
| 0.00 | 0.60 | 0.00 | 0.47 | -22.35 | 115.61 | 46.57 | 240.06 | 0.7774 | -528.0 | -387.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
