SDO HMI 2014-12-03 14:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 49.77 | 286.18 | 35.30 | 202.60 | 16.60 | 109.66 | 43.35 | 292.97 | 0.7167 | -937.3 | -273.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-03 14:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 49.77 | 276.78 | 35.30 | 196.36 | 16.57 | 109.80 | 43.49 | 292.86 | 0.7182 | -1222.9 | -299.9 | |
| 0.00 | 1.37 | 0.00 | 0.94 | 18.35 | 107.58 | 41.27 | 296.16 | 0.6999 | -299.0 | -261.8 | |
| 0.00 | 1.71 | 0.00 | 1.16 | 18.27 | 106.61 | 40.30 | 296.49 | 0.6885 | 496.0 | 419.9 | |
| 0.00 | 1.62 | 0.00 | 1.10 | 18.30 | 106.37 | 40.06 | 296.64 | 0.6860 | 625.0 | 550.1 | |
| 0.00 | 1.28 | 0.00 | 0.85 | 17.04 | 104.99 | 38.68 | 295.53 | 0.6646 | 678.0 | 539.3 | |
| 0.00 | 0.94 | 0.00 | 0.62 | 17.19 | 104.83 | 38.52 | 295.83 | 0.6633 | 767.0 | 653.7 | |
| 0.00 | 1.28 | 0.00 | 0.82 | 17.64 | 102.44 | 36.13 | 297.72 | 0.6370 | 709.0 | 588.9 | |
| 0.00 | 1.20 | 0.00 | 0.75 | 15.77 | 101.65 | 35.34 | 295.35 | 0.6183 | 547.0 | 434.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
