SDO HMI 2014-12-03 15:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 33.97 | 109.28 | 24.21 | 77.50 | -19.39 | 107.63 | 41.87 | 241.65 | 0.7172 | -52.2 | -108.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-03 15:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 5.89 | 10.16 | 4.45 | 7.67 | -19.86 | 111.25 | 45.49 | 242.68 | 0.7572 | 595.8 | 447.9 | |
| 1.79 | 4.70 | 1.34 | 3.52 | -19.54 | 110.91 | 45.15 | 242.94 | 0.7526 | 652.9 | 465.7 | |
| 2.82 | 10.59 | 2.09 | 7.86 | -19.38 | 110.28 | 44.52 | 242.89 | 0.7454 | 848.9 | 572.5 | |
| 0.00 | 1.62 | 0.00 | 1.21 | -20.27 | 110.55 | 44.79 | 241.88 | 0.7517 | 284.0 | 300.4 | |
| 0.00 | 0.85 | 0.00 | 0.63 | -19.25 | 109.97 | 44.21 | 242.92 | 0.7417 | 481.0 | 451.5 | |
| 0.00 | 0.77 | 0.00 | 0.57 | -19.47 | 110.00 | 44.24 | 242.65 | 0.7429 | 501.0 | 512.0 | |
| 0.85 | 3.33 | 0.62 | 2.43 | -19.03 | 109.72 | 43.96 | 243.10 | 0.7382 | 716.3 | 539.6 | |
| 0.00 | 1.20 | 0.00 | 0.89 | -20.32 | 110.08 | 44.32 | 241.61 | 0.7471 | 753.0 | 646.4 | |
| 0.00 | 0.94 | 0.00 | 0.67 | -18.64 | 108.69 | 42.93 | 243.15 | 0.7257 | -449.0 | -332.5 | |
| 0.00 | 0.68 | 0.00 | 0.49 | -18.24 | 108.56 | 42.80 | 243.62 | 0.7227 | 527.0 | 488.5 | |
| 3.50 | 5.12 | 2.48 | 3.62 | -17.46 | 108.29 | 42.53 | 244.53 | 0.7166 | 724.7 | 478.7 | |
| 0.00 | 1.02 | 0.00 | 0.73 | -18.26 | 108.02 | 42.26 | 243.35 | 0.7169 | -334.0 | -249.5 | |
| 0.68 | 2.05 | 0.48 | 1.43 | -17.36 | 107.50 | 41.75 | 244.32 | 0.7075 | 743.1 | 631.5 | |
| 0.51 | 35.60 | 0.36 | 24.84 | -19.76 | 106.97 | 41.21 | 240.89 | 0.7120 | -357.7 | -471.0 | |
| 1.54 | -14.00 | 1.07 | -14.00 | -19.16 | 106.53 | 40.77 | 241.47 | 0.7045 | -612.5 | 999999 | |
| 7.00 | -14.00 | 4.89 | -14.00 | -19.66 | 106.56 | 40.80 | 240.82 | 0.7072 | -790.2 | 999999 | |
| 1.45 | -14.00 | 1.01 | -14.00 | -19.88 | 106.34 | 40.58 | 240.41 | 0.7058 | -746.0 | 999999 | |
| 0.00 | 0.26 | 0.00 | 0.18 | -19.15 | 106.08 | 40.32 | 241.24 | 0.6995 | -633.0 | -581.3 | |
| 0.00 | 1.20 | 0.00 | 0.82 | -18.90 | 105.71 | 39.96 | 241.40 | 0.6944 | -578.0 | -530.6 | |
| 0.00 | 0.85 | 0.00 | 0.59 | -19.78 | 105.73 | 39.97 | 240.23 | 0.6987 | -557.0 | -495.2 | |
| 0.00 | 2.82 | 0.00 | 1.91 | -18.14 | 105.18 | 39.42 | 242.15 | 0.6849 | 831.0 | 649.1 | |
| 0.00 | 2.39 | 0.00 | 1.63 | -18.74 | 105.26 | 39.50 | 241.38 | 0.6886 | -850.0 | -634.0 | |
| 0.51 | 15.45 | 0.35 | 10.59 | -19.84 | 105.50 | 39.74 | 240.03 | 0.6965 | -510.8 | -542.1 | |
| 3.16 | -23.00 | 2.16 | -23.00 | -19.78 | 105.24 | 39.48 | 239.98 | 0.6933 | -801.2 | 999999 | |
| 1.28 | -23.00 | 0.88 | -23.00 | -19.59 | 105.14 | 39.38 | 240.18 | 0.6913 | -728.0 | 999999 | |
| 2.99 | 7.68 | 2.03 | 5.22 | -19.46 | 104.78 | 39.02 | 240.16 | 0.6867 | -908.0 | -696.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
