SDO HMI 2014-12-04 22:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.33 | 23.71 | 1.74 | 12.48 | -15.13 | 36.82 | -11.89 | 143.74 | 0.3377 | -350.6 | -364.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-04 22:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.37 | 2.99 | 0.71 | 1.55 | -16.30 | 42.53 | -6.19 | 160.23 | 0.3071 | 1064.5 | 793.5 | |
| 0.00 | 2.30 | 0.00 | 1.21 | -16.24 | 39.67 | -9.04 | 152.24 | 0.3254 | 1062.0 | 898.6 | |
| 0.00 | 1.79 | 0.00 | 0.94 | -14.34 | 36.91 | -11.81 | 142.10 | 0.3241 | -908.0 | -716.1 | |
| 1.96 | 3.58 | 1.03 | 1.88 | -14.37 | 36.56 | -12.15 | 141.37 | 0.3281 | -1016.0 | -831.5 | |
| 0.00 | 1.19 | 0.00 | 0.62 | -12.60 | 36.62 | -12.09 | 137.78 | 0.3055 | -933.0 | -802.9 | |
| 0.00 | 0.60 | 0.00 | 0.31 | -12.57 | 36.41 | -12.30 | 137.21 | 0.3076 | -794.0 | -634.9 | |
| 0.00 | 1.45 | 0.00 | 0.77 | -15.62 | 35.98 | -12.73 | 142.47 | 0.3499 | 906.0 | 787.4 | |
| 0.00 | 0.85 | 0.00 | 0.45 | -15.35 | 35.62 | -13.09 | 141.20 | 0.3501 | -695.0 | -559.4 | |
| 0.00 | 1.54 | 0.00 | 0.81 | -15.23 | 34.97 | -13.74 | 139.63 | 0.3554 | -1108.0 | -887.1 | |
| 0.00 | 1.02 | 0.00 | 0.54 | -15.50 | 34.73 | -13.98 | 139.67 | 0.3613 | -680.0 | -582.7 | |
| 0.00 | 6.40 | 0.00 | 3.40 | -15.32 | 34.52 | -14.19 | 138.91 | 0.3613 | -325.0 | -854.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
