SDO HMI 2014-12-05 11:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 21.82 | 0.00 | 12.25 | 13.14 | 17.00 | -24.59 | 61.59 | 0.4644 | -611.8 | -490.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2014-12-05 11:00:25 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.19 | 0.00 | 0.65 | 13.98 | 22.07 | -19.53 | 53.93 | 0.4030 | -763.0 | -519.5 | |
| 0.00 | 0.85 | 0.00 | 0.47 | 16.58 | 20.63 | -20.96 | 50.76 | 0.4447 | -764.0 | -694.4 | |
| 0.00 | 1.79 | 0.00 | 0.96 | 8.29 | 20.96 | -20.63 | 68.29 | 0.3770 | -610.0 | -420.6 | |
| 0.00 | 1.11 | 0.00 | 0.59 | 7.58 | 20.27 | -21.33 | 70.67 | 0.3838 | -644.0 | -581.1 | |
| 0.00 | 1.02 | 0.00 | 0.55 | 7.82 | 20.13 | -21.47 | 70.20 | 0.3871 | -791.0 | -625.8 | |
| 0.00 | 1.96 | 0.00 | 1.09 | 13.74 | 18.60 | -23.00 | 58.54 | 0.4469 | -945.0 | -733.9 | |
| 0.00 | 1.02 | 0.00 | 0.57 | 13.46 | 17.80 | -23.80 | 59.89 | 0.4556 | -826.0 | -688.8 | |
| 0.00 | 1.02 | 0.00 | 0.57 | 13.46 | 17.46 | -24.13 | 60.21 | 0.4601 | -774.0 | -626.9 | |
| 0.00 | 1.28 | 0.00 | 0.70 | 8.95 | 17.56 | -24.04 | 69.52 | 0.4313 | -766.0 | -635.9 | |
| 0.00 | 1.45 | 0.00 | 0.80 | 9.10 | 17.39 | -24.21 | 69.32 | 0.4347 | -842.0 | -696.3 | |
| 0.00 | 1.02 | 0.00 | 0.58 | 15.53 | 16.24 | -25.36 | 57.51 | 0.4912 | -584.0 | -512.7 | |
| 0.00 | 2.39 | 0.00 | 1.37 | 15.78 | 15.60 | -26.00 | 57.69 | 0.5012 | -576.0 | -481.1 | |
| 0.00 | 2.05 | 0.00 | 1.16 | 13.31 | 15.53 | -26.07 | 62.24 | 0.4852 | -722.0 | -630.8 | |
| 0.00 | 1.11 | 0.00 | 0.64 | 14.43 | 13.65 | -27.95 | 61.72 | 0.5175 | -291.0 | -275.2 | |
| 0.00 | 1.19 | 0.00 | 0.70 | 16.95 | 13.10 | -28.50 | 57.88 | 0.5411 | -666.0 | -517.7 | |
| 0.00 | 1.37 | 0.00 | 0.85 | 19.24 | 9.19 | -32.41 | 57.30 | 0.6036 | 775.0 | 627.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
